ABB AC500 Modules: DDO01

Technical Dossier

Product Details And Specifications

ABB AC500 Series Technical Notes

The ABB AC500 is a modular programmable logic controller platform deployed across heavy industrial sectors including petrochemical processing, nuclear power generation, offshore oil & gas, pulp and paper, and water treatment infrastructure. Introduced in the early 2000s as a successor to the ABB Advant and 07KT series, the AC500 established itself as ABB's primary mid-to-high-range PLC platform for process automation and discrete manufacturing. Its distributed I/O architecture, IEC 61131-3 compliance, and broad communication protocol support have made it a standard specification in engineering procurement documents globally. The platform supports CPU modules ranging from compact entry-level controllers to high-availability redundant configurations, with I/O expansion via the S500 local bus and field-level communication via PROFIBUS, PROFINET, EtherNet/IP, Modbus TCP, and CANopen.

AC500 Full Catalog & Functionalities – SKU List (DDO01 and Related Modules)

Digital Output Modules

• DDO01: 16-channel 24 VDC digital output module, 0.5 A per channel, S500 bus interface
• DDO02: 16-channel relay output module, 2 A per channel, NO contacts, S500 bus
• DDO11: 8-channel high-current digital output, 2 A per channel, diagnostic per channel
• DDO12: 8-channel relay output with LED status indication, S500 local bus

Digital Input Modules

• DDI01: 16-channel 24 VDC digital input module, S500 bus, sink/source configurable
• DDI02: 32-channel 24 VDC digital input, high-density, S500 bus interface
• DDI11: 8-channel digital input with diagnostics, short-circuit detection per channel

Analog Output Modules

• DAI01: 8-channel analog input, 0–10 V / 0–20 mA / 4–20 mA, 12-bit resolution
• DAI02: 4-channel analog input, high-resolution 16-bit, thermocouple/RTD compatible
• DAO01: 4-channel analog output, 0–10 V / 4–20 mA, 12-bit, S500 bus

CPU Modules

• PM554-T: Entry-level AC500 CPU, 256 KB program memory, onboard Ethernet
• PM564-T: Mid-range CPU, 1 MB program memory, dual Ethernet, SD card slot
• PM573-ETH: High-performance CPU, 4 MB memory, redundancy-capable
• PM591-ETH: Advanced CPU with extended I/O capacity, 8 MB program memory
• PM5650-2ETH: AC500 V3 CPU, 16 MB memory, IEC 62443 security, dual Ethernet

Communication Modules

• CM572-DP: PROFIBUS DP master/slave communication module, S500 bus
• CM574-RS: Serial communication module, RS-232/RS-485, Modbus RTU master/slave
• CM577-ETH: EtherNet/IP adapter module for AC500 distributed I/O

Power Supply Modules

• PS501-PROG: Programming and configuration cable/adapter for AC500 CPUs
• TB521-ETH: Terminal base for S500 I/O modules with Ethernet field bus coupler
