ABB FLON/FDNA/FPBA Fieldbus Adapter Modules

Technical Dossier

Product Details And Specifications

ABB FLON/FDNA/FPBA Fieldbus Adapter Series: Comprehensive Module Range and Technical Overview

ABB's fieldbus adapter module family — spanning the FLON, FDNA, FPBA, FCAN, FCNA, FENA, FEPL, FMBA, FMCA, FMNA, FPBA, FRSA, and FSCA series — represents the primary communication interface layer for ABB's industrial AC drive platforms, including the ACS550, ACS600, ACS800, ACS850, ACS880, and DCS800 series. These modules are installed in heavy-process industries worldwide: petrochemical refineries, pulp and paper mills, offshore platforms, steel rolling mills, and municipal water treatment facilities. The installed base across these sectors runs into the hundreds of thousands of units globally, many of which are embedded in control architectures that will not be replaced for another decade or more. The fieldbus adapter is not a peripheral accessory — it is the communication backbone that connects the drive to the plant's supervisory control network. A failed adapter module means a drive that cannot receive speed references or report fault states, which in a continuous-process environment translates directly to unplanned downtime.

The Evolution of ABB Fieldbus Adapter Architecture

ABB's fieldbus adapter strategy has tracked the evolution of industrial networking protocols across three distinct eras. In the 1990s, proprietary and early-standard protocols dominated: PROFIBUS-DP (FPBA-01), LonWorks (FLON-01), and Modbus RTU (FMBA-01) were the primary integration paths for ACS600 and early ACS800 drives. These modules used a dedicated option slot on the drive's control board and communicated via ABB's internal DDCS (Distributed Drive Control System) fiber-optic bus or direct backplane connection.

Through the 2000s, Ethernet-based fieldbus protocols began displacing serial networks. ABB responded with the FENA series (EtherNet/IP, Modbus TCP, PROFINET IO) and the FEPL-02 (EtherCAT). These modules introduced dual-port Ethernet topologies and supported line, ring, and star network configurations — a significant architectural shift from the point-to-point serial adapters of the prior generation. Compatibility between generations is not automatic: an FLON-01 designed for an ACS800 cannot be substituted with an FENA-21 without firmware reconfiguration and parameter mapping.

The current generation, anchored by the FENA-21 and FSCA-01, supports multi-protocol operation and is designed for ACS880 and ACS580 platforms. Legacy drives — ACS600, ACS800 first-generation, DCS800 — remain dependent on the original adapter families, many of which ABB has discontinued. Sourcing these discontinued adapters from the secondary market is the only viable alternative to a full drive replacement.

ABB Fieldbus Adapter Full Catalog & Functionalities (SKU List)

LonWorks / Serial Protocol Adapters (Legacy)

• FLON-01: LonWorks fieldbus adapter for ACS600/ACS800; FTT-10 transceiver, 78 kbps free topology
• FMBA-01: Modbus RTU adapter; RS-485 interface, up to 19.2 kbps, for ACS550/ACS800
• FCAN-01: CANopen adapter for ACS drives; DS301 v4.02 compliant, 1 Mbps max
• FCNA-01: ControlNet adapter for ACS800; coaxial media, 5 Mbps, NUT scheduling
• FDNA-01: DeviceNet adapter for ACS550/ACS800; Group 2 slave, 500 kbps
• FRSA-01: RS-232/RS-485 serial adapter; Modbus RTU/ASCII, point-to-point or multidrop

PROFIBUS Adapters

• FPBA-01: PROFIBUS-DP adapter for ACS550/ACS600/ACS800; 12 Mbps, GSD file-based configuration
• FPBA-02: PROFIBUS-DP V1 adapter with acyclic services; for ACS800/DCS800

Ethernet-Based Adapters

• FENA-01: EtherNet/IP + Modbus TCP adapter; single-port, for ACS800/ACS550
• FENA-11: EtherNet/IP + Modbus TCP + PROFINET IO; dual-port, ACS800/ACS850
• FENA-21: EtherNet/IP + Modbus TCP + PROFINET IO; dual-port, ACS880/ACS580/ACS480
• FEPL-02: EtherCAT adapter; CoE (CANopen over EtherCAT), for ACS880/ACS850
• FSCA-01: Modbus TCP + EtherNet/IP; compact form factor, ACS580/ACS380

PROFINET / Other Ethernet Adapters

• FPNO-01: PROFINET IO adapter; MRP ring redundancy, for ACS880/ACS850
• FMCA-01: Modbus TCP adapter; single-port, ACS550/ACS800 legacy Ethernet option
• FMNA-01: Modbus TCP + EtherNet/IP; for ACS800 with RMIO control board

Sourcing Hard-to-Find & Obsolete ABB Fieldbus Adapter Parts

ABB has formally discontinued several adapters in this family, including the FLON-01, FCNA-01, FRSA-01, and FMBA-01. For plants operating ACS600 or first-generation ACS800 drives, these modules are not interchangeable with current-generation equivalents without engineering intervention — protocol translation, parameter remapping, and in some cases PLC-side configuration changes are required. The cost of that engineering work, combined with drive downtime, frequently exceeds the cost of sourcing a replacement adapter from the secondary market by a factor of ten or more.

DriveKNMS maintains stock of discontinued ABB fieldbus adapters sourced through controlled channels: decommissioned plant inventories, authorized distributor closeouts, and factory-sealed warehouse lots. Each unit is individually logged with its source provenance. We do not commingle unknown-origin stock with verified inventory. For plants that require long-term spares coverage — particularly those with 5–10 year maintenance horizons — we can discuss bulk reservation arrangements.

Quality Control for the ABB Fieldbus Adapter Range

Fieldbus adapter modules present specific failure modes that differ from standard I/O cards. The communication PHY layer, onboard oscillators, and isolation transformers are the primary wear components. Our QC process for this product family covers:

• Visual inspection: PCB trace integrity, connector pin condition, conformal coating status, and capacitor inspection (electrolytic cap bulge or leakage is a primary failure indicator in units over 10 years old)
• Firmware version verification: Each adapter model has a minimum firmware revision required for compatibility with specific drive firmware. We verify and document the firmware version on every unit.
• Protocol communication test: Units are bench-tested on the target protocol (PROFIBUS, DeviceNet, LonWorks, etc.) using a live drive or protocol analyzer to confirm correct node addressing, data exchange, and fault reporting
• Isolation resistance test: Communication port isolation is verified to confirm no breakdown between the fieldbus interface and the drive's internal logic
• Burn-in cycle: Units are powered for a minimum of 24 hours under simulated load conditions before shipment

For sourcing inquiries on any ABB fieldbus adapter module — including discontinued models — contact DriveKNMS directly:

• Email: sale@driveknms.com
• WhatsApp: +86 18359293191
• Web: driveknms.com
