ABB S800 I/O Modules GJR2332300R0200

Technical Dossier

Product Details And Specifications

ABB S800 I/O Series Technical Notes

The ABB S800 I/O series is a distributed I/O platform developed by ABB for use with the AC800M process controller, forming the backbone of ABB's Industrial IT and System 800xA automation architecture. Deployed across global heavy industry — including petrochemical complexes, nuclear power stations, offshore oil platforms, and large-scale refinery operations — the S800 I/O system represents one of the most widely installed distributed control system (DCS) I/O platforms in continuous process industries. The modular backplane architecture supports hot-swap capability, redundant fieldbus communication, and a wide operating temperature range, making it suitable for safety-critical and high-availability environments. GJR2332300R0200 is a digital output module within this platform, designed for direct integration into S800 I/O stations via the ModuleBus interface.

The Evolution of S800 I/O Architecture

The S800 I/O platform was introduced in the late 1990s as part of ABB's Industrial IT initiative, replacing earlier Advant I/O hardware (e.g., S100, S400 series). The system communicates via the proprietary ModuleBus protocol over optical fiber or electrical backplane, interfacing with the AC800M controller through CI801, CI810, CI820, and CI830 communication interface modules. Early revisions used parallel backplane addressing; later hardware revisions introduced enhanced diagnostics, HART pass-through on analog modules, and improved EMC shielding. The platform reached broad market maturity in the 2000s and remains in active production, though several early-revision modules (R0100, R0200 suffix variants) have transitioned to RFQ availability review. Compatibility between hardware revisions is generally maintained at the station level, but firmware dependencies on the AC800M controller version must be verified during replacement. For plants running System 800xA versions 5.x and below, original hardware revision modules are often required to maintain certified configurations.

S800 I/O Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly deployed modules within the ABB S800 I/O platform. Modules are classified by functional category.

Digital Output (DO) Modules

GJR2332300R0200: DO module, 8-channel, 24 VDC, 0.5 A per channel, ModuleBus interface, hot-swap capable.
GJR2332300R0100: DO module, 8-channel, 24 VDC, earlier hardware revision, functionally equivalent to R0200.
GJR2332200R0200: DO module, 16-channel, 24 VDC, 0.5 A per channel, high-density configuration.
GJR2332100R0200: DO module, relay output, 8-channel, 230 VAC/24 VDC, for high-voltage switching applications.

Digital Input (DI) Modules

GJR2331500R0200: DI module, 8-channel, 24 VDC, standard discrete input, ModuleBus interface.
GJR2331500R0100: DI module, 8-channel, 24 VDC, earlier hardware revision.
GJR2331600R0200: DI module, 16-channel, 24 VDC, high-density discrete input.
GJR2331700R0200: DI module, 8-channel, 120 VAC input, for legacy AC field device integration.

Analog Input (AI) Modules

GJR2391500R0200: AI module, 8-channel, 4–20 mA / 0–10 V, 12-bit resolution, HART pass-through support.
GJR2391500R0100: AI module, 8-channel, 4–20 mA, earlier revision without HART support.
GJR2391600R0200: AI module, 16-channel, 4–20 mA, high-density analog input with HART.
GJR2392100R0200: AI module, thermocouple/RTD input, 8-channel, supports J/K/T/PT100 sensor types.

Analog Output (AO) Modules

GJR2392500R0200: AO module, 8-channel, 4–20 mA output, 12-bit resolution, HART-capable.
GJR2392500R0100: AO module, 8-channel, 4–20 mA, earlier hardware revision.
GJR2392600R0200: AO module, 4-channel, 4–20 mA, high-accuracy output for precision control loops.

Communication Interface (CI) Modules

CI801: ModuleBus optical interface, connects AC800M to remote S800 I/O stations via fiber optic.
CI810B: PROFIBUS DP interface module, connects S800 I/O station to PROFIBUS master.
CI820V1: FOUNDATION Fieldbus HSE interface for S800 I/O integration into FF networks.
CI830: DeviceNet interface module for S800 I/O station connectivity.

Power Supply Modules

SA811: S800 I/O station power supply, 24 VDC input, supports up to 12 I/O modules per station.
SA812: Redundant power supply module for S800 I/O stations, hot-swap capable.

Quality Control for the S800 I/O Range

S800 I/O modules present specific testing challenges due to their ModuleBus backplane communication protocol and multi-channel I/O architecture. DriveKNMS applies the following verification procedures to all S800 I/O units: (1) Visual inspection of backplane connector pins, module housing, and label integrity; (2) Power-on functional test using an S800 I/O test station with AC800M controller running System 800xA firmware; (3) Channel-by-channel I/O verification — each digital channel is exercised through its full on/off cycle; analog channels are verified at 4 mA, 12 mA, and 20 mA reference points; (4) ModuleBus communication handshake verification to confirm the module is correctly enumerated by the controller; (5) HART communication test on applicable AI/AO modules using a HART communicator; (6) Burn-in period of 24 hours under load prior to shipment for critical or high-value units. Modules that fail any stage of this process are quarantined and not listed for sale.
