ABB UNC4672A Modules: HIEE205012R1 V1

Name: ABB UNC4672A Modules: HIEE205012R1 V1
Brand: ABB

Model: HIEE205012R1 UNC4672A V1

Brand ABB

Series UNC4672A

Model HIEE205012R1 UNC4672A V1

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

ABB UNC4672A Series Technical Notes

The ABB UNC4672A (HIEE205012R1) is a network communication controller module deployed within ABB's INSUM (Intelligent Network Supervision and Management) and UNITROL excitation control architectures. This module class occupies a critical position in heavy industrial installations including petrochemical refineries, nuclear power auxiliary systems, offshore platforms, and large-scale hydroelectric generation facilities. The UNC series provides the communication backbone between field-level I/O, drive systems, and supervisory SCADA layers, making it a non-substitutable component in long-lifecycle plant environments where system replacement is economically or operationally prohibitive.

The Evolution of UNC4672A Architecture

The UNC (Universal Network Controller) module lineage within ABB's industrial automation portfolio traces its origin to the late 1990s INSUM platform, designed to integrate medium-voltage drive systems and motor control centers via a proprietary fieldbus. Early hardware revisions (V1, V2) used parallel backplane communication with HIEE-series board identifiers, establishing the HIEE205012R1 part number as the primary procurement reference for the UNC4672A function block.

Subsequent hardware revisions introduced improved EMC shielding, extended temperature tolerance, and enhanced PROFIBUS-DP compatibility. The V1 revision (HIEE205012R1) remains the most widely installed variant across plants commissioned between 2000 and 2012. Compatibility between hardware revisions requires firmware alignment; cross-revision substitution without firmware verification is not supported by ABB field service documentation. As the INSUM platform has entered its end-of-active-development phase, spare parts sourcing has shifted from OEM channels to specialist industrial distributors capable of providing tested, pull-from-service, and refurbished units.

UNC4672A Full Catalog & Functionalities (SKU List)

The following SKUs represent verified components within the ABB UNC / INSUM / UNITROL ecosystem. Each entry reflects a distinct functional role within the control architecture:

HIEE205012R1 (UNC4672A V1): Network controller, INSUM primary communication node, V1 hardware
HIEE205012R2 (UNC4672A V2): Network controller, revised EMC shielding, extended temp range
HIEE300024R0001 (UFC760BE101): Fieldbus communication module, PROFIBUS-DP master interface
HIEE300024R0002 (UFC760BE102): Fieldbus module, redundant DP configuration variant
HIEE205089R1 (UNS0881A-P): Power supply board, 24VDC regulated output for UNC rack
HIEE205089R2 (UNS0881A-P V2): Power supply board, enhanced ripple suppression revision
HIEE300015R1 (UNS3020A): Digital I/O module, 16DI/16DO, 24VDC logic level
HIEE300015R2 (UNS3020A V2): Digital I/O module, extended diagnostic register set
HIEE300016R1 (UNS3030A): Analog input module, 8-channel, 4–20mA / 0–10V selectable
HIEE300017R1 (UNS3040A): Analog output module, 4-channel, 4–20mA isolated
HIEE300018R1 (UNS3050A): RTD/thermocouple input module, 8-channel, PT100 compatible
HIEE205091R1 (UNC4673A): Redundant network controller, hot-standby pair configuration
HIEE205091R2 (UNC4673A V2): Redundant controller, firmware 3.x compatible revision
HIEE300022R1 (UFC718AE01): Ethernet gateway module, Modbus TCP / INSUM bridge
HIEE300022R2 (UFC718AE02): Ethernet gateway, dual-port, VLAN-capable revision
HIEE205093R1 (UNC4675A): CPU module, INSUM rack master processor, 32-bit architecture
HIEE205094R1 (UNS0882A): Backplane termination board, 8-slot INSUM rack
HIEE205095R1 (UNS0883A): Rack extender module, inter-rack INSUM bus coupler

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
