ABB IMHSS03 Hydraulic Servo Module: Specs, Compatible Models & Availability

Technical Dossier

Product Details And Specifications

ABB IMHSS03 & IMMFP Series Technical Notes

The Evolution of IMMFP Architecture

ABB's IMMFP (I/O Module Master Field Processor) architecture was introduced as part of the Advant OCS (Open Control System) platform in the late 1980s, succeeding the earlier MOD 300 and PROCONTIC systems. The AC450 controller, which hosts IMMFP I/O modules, operates on a proprietary MasterBus 300 fieldbus protocol, providing deterministic communication between the controller and distributed I/O stations. Early IMMFP generations (Rev A/B) supported basic analog and digital I/O with 12-bit resolution. Subsequent revisions introduced 16-bit analog resolution, enhanced diagnostics, and expanded servo control capability — culminating in specialized modules such as the IMHSS03 for hydraulic servo positioning loops.

Compatibility across IMMFP generations is constrained by backplane slot addressing and firmware revision alignment. Modules from different hardware revisions may require firmware parameter re-mapping when substituted. The AC450 platform reached end-of-active-development around 2005, transitioning to ABB's System 800xA as the strategic successor. However, the IMMFP installed base remains extensive, and ABB's long-term parts support program (LTPS) provides limited OEM availability. Third-party MRO suppliers such as DriveKNMS fill the gap for obsolete and hard-to-source IMMFP modules, including the IMHSS03.

IMMFP Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked modules within the ABB IMMFP / AC450 ecosystem. Each module is classified by functional category.

Hydraulic & Servo Control

• IMHSS03: Hydraulic servo positioning module, 4-channel, ±10V command output, LVDT feedback input
• IMHSS02: Hydraulic servo module, 2-channel variant, predecessor to IMHSS03
• IMHSS01: Single-channel hydraulic servo interface, early-generation IMMFP servo module

Analog Input Modules (AI)

• IMDSI02: 16-channel analog input, 4–20 mA, 16-bit resolution, HART-transparent
• IMDSI03: 8-channel analog input, high-speed scan, ±10V / 4–20 mA configurable
• IMASI02: 8-channel analog input, isolated, for thermocouple and RTD signals
• IMASI03: 16-channel analog input, isolated, millivolt-range inputs for thermocouples

Analog Output Modules (AO)

• IMDSO02: 8-channel analog output, 4–20 mA, 12-bit, loop-powered
• IMDSO03: 8-channel analog output, 16-bit, ±10V / 4–20 mA selectable

Digital Input Modules (DI)

• IMDSI22: 32-channel 24VDC digital input, sink/source configurable
• IMDSI23: 16-channel 120VAC digital input, optically isolated
• IMDSI24: 32-channel 48VDC digital input, high-density

Digital Output Modules (DO)

• IMDSO22: 16-channel 24VDC digital output, 0.5A per channel, short-circuit protected
• IMDSO23: 8-channel relay output, SPDT, 2A/channel, 120/240VAC rated

CPU / Controller Modules

• IMMFP12: Master Field Processor, AC450 primary CPU module, MasterBus 300 interface
• IMMFP02: Field Processor, redundant controller module for AC450 hot-standby configurations

Communication & Network Adapters

• IMCIS02: Communication Interface Slave, MasterBus 300 to PROFIBUS DP gateway
• IMCIS12: Communication Interface, Modbus RTU master/slave adapter for AC450

Power Supply Modules

• IMPS02: 24VDC IMMFP backplane power supply, 10A, redundancy-capable
• IMPS12: 48VDC power supply module for high-density I/O racks
