ABB NIB-02 3HNA024203-001/01 3HNA007026-001 3HNA007022-001 Spraying Controller

Name: ABB NIB-02 3HNA024203-001/01 3HNA007026-001 3HNA007022-001 Spraying Controller
Brand: ABB

Model: NIB-02 3HNA024203-001/01 3HNA007026-001 3HNA007022-001

Brand ABB

Series NIB Series

Model NIB-02 3HNA024203-001/01 3HNA007026-001 3HNA007022-001

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

ABB NIB Series Technical Notes

The Evolution of NIB Series Architecture

The NIB series emerged alongside ABB's transition from the S4 to S4C+ robot controller platform in the late 1990s. Early-generation NIB boards (NIB-01) used parallel bus communication and were tightly coupled to the M97A/M98A motion computer hardware. The NIB-02 introduced a more modular backplane interface, improved electrostatic high-voltage control logic, and enhanced diagnostics via the IRC5 teach pendant. With the rollout of the IRC5 controller (circa 2004–2006), NIB-02 became the standard spraying node, replacing NIB-01 in new installations while maintaining backward compatibility in mixed S4C+/IRC5 hybrid cells.

By the mid-2010s, ABB introduced the DSQC series of process interface boards as part of the IRC5 Compact and OmniCore platforms, gradually superseding NIB-02 in new robot orders. However, the NIB-02 remains the active spare part for the large installed base of IRC5 M2004 and S4C+ controllers that will remain in service through the 2030s. Compatibility issues arise primarily when mixing firmware revisions: NIB-02 boards require RobotWare 5.x or 6.x and are not natively compatible with OmniCore's RobotWare 7.x without a gateway adapter.

NIB Series Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified NIB and associated spraying interface module range for ABB IRC5 and S4C+ platforms. Each entry reflects a distinct functional role within the spraying cell architecture.

NIB-02 (3HNA024203-001/01): Primary node interface board for IRC5 spraying controller; manages atomizer, paint flow, and HV electrostatics.
NIB-02 (3HNA007026-001): Variant assembly of NIB-02 with alternate connector harness configuration for S4C+ backplane integration.
NIB-02 (3HNA007022-001): Sub-assembly board paired with NIB-02 main board; handles analog signal conditioning for spray process feedback.
NIB-01 (3HNA003931-001): First-generation node interface board for S4/S4C platforms; predecessor to NIB-02; parallel bus architecture.
NIB-03 (3HNA028971-001): Enhanced NIB variant with extended I/O capacity for multi-gun spray applications.
DSQC 662 (3HAC026254-001): IRC5 process interface board; successor platform to NIB-02 in new IRC5 installations post-2012.
DSQC 663 (3HAC031670-001): Dual-channel process I/O board; used alongside DSQC 662 in high-density spray cells.
DSQC 352 (3HAC17484-1): Analog I/O board for S4C+ controller; interfaces with NIB-02 for process signal routing.
DSQC 354 (3HAC4167-1): Digital I/O board; provides discrete signal interface between NIB-02 and spray gun solenoids.
DSQC 509 (3HAC14265-1): Serial measurement board for IRC5; used in conjunction with NIB-02 for encoder feedback in rotary atomizers.
DSQC 532 (3HAC025097-001): Fieldbus adapter board; enables DeviceNet communication between NIB-02 and plant-level DCS.
DSQC 679 (3HAC028357-001): IRC5 teach pendant interface board; indirectly supports NIB-02 parameter configuration via FlexPendant.
3HNA006149-001: NIB-02 replacement cable harness assembly; connects NIB-02 to IRC5 drive module backplane.
3HNA013747-001: High-voltage output module for electrostatic spray gun; controlled directly by NIB-02 HV logic.
3HNA015921-001: Atomizer speed control card; plug-in sub-module for NIB-02 rotary atomizer speed regulation.
3HNA019829-001: Paint flow control valve interface card; analog output sub-board for NIB-02 paint metering.
3HNA022684-001: Shaping air pressure control module; interfaces with NIB-02 for pneumatic spray pattern adjustment.

Quality Control for the NIB Series Range

NIB-02 boards present specific test challenges due to their integrated high-voltage electrostatic control circuitry, multi-channel analog outputs, and backplane bus communication logic. DriveKNMS applies a structured test protocol for each NIB-02 unit:

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
