Name: Bihl+Wiedemann BWU1703 PROFIBUS Gateway
Brand: Bihl+Wiedemann

Products / Bihl+Wiedemann / BWU1703 PROFIBUS Gateway

Bihl+Wiedemann BWU1703 PROFIBUS Gateway

Model: BWU1703

Brand Bihl+Wiedemann

Series BWU1703 PROFIBUS Gateway

Model BWU1703

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Bihl+Wiedemann BWU Series Technical Notes

The Bihl+Wiedemann BWU series represents one of the most widely deployed AS-Interface (AS-i) gateway and master module families in global heavy industry. Installed across chemical processing plants, nuclear facilities, oil refineries, and large-scale manufacturing lines, BWU-series devices serve as the critical communication bridge between AS-Interface field networks and higher-level fieldbus or industrial Ethernet systems. Their deterministic cycle times, robust DIN-rail form factor, and compliance with AS-i Specification Rev. 3.0 have made them a default specification in safety-critical automation projects across Europe, Asia, and North America. The BWU1703 specifically functions as a PROFIBUS DP gateway, enabling AS-i network segments of up to 62 slaves to communicate with Siemens S7, ABB, and other PROFIBUS-based DCS/PLC architectures.

BWU Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly deployed models within the Bihl+Wiedemann BWU gateway and master series. Models are classified by primary fieldbus interface and functional role.

PROFIBUS DP Gateways

BWU1703: AS-i/PROFIBUS DP gateway, 62-slave Rev. 3.0, single AS-i channel, DIN-rail mount
BWU1704: AS-i/PROFIBUS DP gateway with integrated AS-i Safety Monitor, SIL 2 certified
BWU1705: Dual-channel AS-i/PROFIBUS DP gateway, 2 × 62 slaves, extended diagnostic
BWU1706: AS-i/PROFIBUS DP gateway, IP20, extended address range, DP V1 support
BWU2405: AS-i/PROFIBUS DP master, 62-slave, integrated power supply 29.5 V DC
BWU2406: AS-i/PROFIBUS DP master with safety monitor, dual AS-i power feed

DeviceNet Gateways

BWU1901: AS-i/DeviceNet gateway, 62-slave Rev. 3.0, single channel, 125–500 kbps
BWU1902: AS-i/DeviceNet gateway with integrated safety monitor, SIL 2

CANopen Gateways

BWU2101: AS-i/CANopen gateway, 62-slave, NMT master, PDO/SDO mapping
BWU2102: AS-i/CANopen gateway with safety monitor, dual-channel AS-i

EtherNet/IP & Modbus TCP Gateways

BWU3455: AS-i/EtherNet/IP gateway, 62-slave, dual-port switch, web diagnostics
BWU3456: AS-i/EtherNet/IP + Modbus TCP combo gateway, dual AS-i channel
BWU3457: AS-i/EtherNet/IP gateway with integrated safety monitor, SIL 2, ODVA certified

PROFINET Gateways

BWU3551: AS-i/PROFINET IO gateway, 62-slave, MRP ring redundancy, GSD file provided
BWU3552: AS-i/PROFINET IO gateway with safety monitor, PROFIsafe integration, SIL 2

Power Supply & Ancillary Modules

BWU1001: AS-i power supply unit, 2.4 A, 29.5 V DC, DIN-rail, for BWU gateway pairing
BWU1002: AS-i power supply unit, 4.0 A, 29.5 V DC, extended load capacity

Sourcing Hard-to-Find & Obsolete BWU Series Parts

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.
