Bachmann BS Series Modules

Technical Dossier

Product Details And Specifications

Bachmann BS Series: Comprehensive Module Range and Technical Overview

The Bachmann BS Series represents the central processing and controller module family within the Bachmann M1 automation platform — a modular, real-time control system deployed extensively across global heavy industry. Installations span wind turbine nacelle controllers, combined-cycle power plant DCS architectures, offshore oil & gas process control, nuclear auxiliary systems, and chemical plant safety instrumentation. The M1 platform's deterministic execution model and IEC 61131-3 compliance have made BS Series CPUs a reference standard in applications where scan-cycle predictability and long-term hardware availability are non-negotiable procurement criteria. Installed base estimates place Bachmann M1 systems in service across more than 40 countries, with a significant proportion of units operating beyond their original 10-year design lifecycle — creating sustained demand for BS Series spare parts and lifecycle extension services.

The Evolution of BS Series Architecture

The Bachmann M1 platform was introduced in the mid-1990s as a successor to proprietary single-board controller designs. The initial BS200 generation established the rack-based backplane architecture using a proprietary high-speed bus (M1 Bus) operating at deterministic cycle times suitable for closed-loop control. Early BS200 and BS202 units were limited to single-core processing with onboard SRAM and battery-backed program retention. The BS204 and BS206 revisions introduced expanded memory addressing and improved Ethernet connectivity options, enabling integration with SCADA systems via OPC-DA.

The BS210 — the subject of this listing — represents a mid-generation refinement with enhanced processing throughput, dual Ethernet ports, and expanded I/O addressing capacity. It is compatible with the full range of M1 I/O modules and supports SolutionCenter programming environments. The BS212 and BS214 extended this architecture with redundancy-capable configurations, supporting hot-standby CPU pairing for high-availability applications. The BS220 and BS230 represent the current-generation controllers with multi-core architecture, expanded onboard storage, and native support for IEC 62443 cybersecurity frameworks. Backward compatibility with legacy M1 I/O modules is maintained across all generations, though firmware version alignment between CPU and I/O modules must be verified during any cross-generation replacement.

Bachmann BS Series Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified BS Series and closely integrated M1 platform modules. Each entry reflects the module's primary functional classification within the M1 system architecture.

CPU / Controller Modules

• BS200: First-generation M1 CPU; single Ethernet port; SRAM program storage; baseline scan-cycle controller.
• BS202: BS200 successor; expanded I/O addressing; improved battery-backed memory retention.
• BS204: Mid-range CPU with dual-port Ethernet; OPC-DA SCADA integration; enhanced diagnostic logging.
• BS206: BS204 variant with extended temperature range rating for harsh-environment enclosures.
• BS210: Current mid-generation CPU; dual Ethernet; expanded memory map; SolutionCenter 3.x compatible; primary replacement target for BS200/BS202 legacy systems.
• BS212: Redundancy-capable CPU; supports hot-standby pairing; synchronization via dedicated sync bus.
• BS214: High-availability variant of BS212; enhanced watchdog and failover diagnostics.
• BS220: Current-generation multi-core CPU; IEC 62443 cybersecurity support; expanded onboard flash storage.
• BS230: Top-tier M1 CPU; highest processing throughput; native OPC-UA server; recommended for new installations.

Digital I/O Modules (M1 Platform — BS Series Compatible)

• DI216: 16-channel digital input module; 24 VDC; M1 backplane bus interface; status LED per channel.
• DI232: 32-channel digital input module; high-density rack configuration; grouped common return.
• DO216: 16-channel digital output module; transistor output; 24 VDC / 0.5 A per channel.
• DIO216: 16-channel configurable digital I/O; mixed input/output assignment via SolutionCenter.

Analog I/O Modules (M1 Platform — BS Series Compatible)

• AIO288: 8-channel analog input / 8-channel analog output combination module; ±10 V / 4–20 mA; 16-bit resolution.
• AIC212: 12-channel analog input module; current/voltage selectable per channel; high-resolution ADC.

Communication & Network Modules

• GMP232: Grid measurement and protection module; power quality analysis; IEC 61850 GOOSE messaging support.
• NT255: Network time synchronization module; GPS/IRIG-B input; sub-millisecond timestamp accuracy for event logging.

Sourcing Hard-to-Find & Obsolete BS Series Parts

The BS200, BS202, and BS204 controller modules have reached end-of-manufacture status. Bachmann Electronic GmbH no longer produces replacement units, and authorized distributor stock has been exhausted in most regions. DriveKNMS maintains a dedicated inventory of tested, pull-from-service BS Series CPUs and I/O modules sourced through decommissioned plant equipment and controlled surplus channels. All units undergo functional verification prior to listing. For customers operating legacy M1 systems beyond the original support window, DriveKNMS provides lifecycle extension sourcing — including cross-reference analysis to identify compatible replacement SKUs where direct equivalents are unavailable. Customers requiring long-term maintenance agreements for BS Series hardware are encouraged to contact our technical team to discuss multi-unit reserve stock arrangements.

Quality Control for the BS Series Range

BS Series CPU modules incorporate a multi-layer backplane bus interface and proprietary M1 Bus protocol stack that requires specialized test procedures beyond standard power-on verification. DriveKNMS applies the following protocol to all BS Series units prior to dispatch:

• Backplane Bus Integrity Test: Each CPU is seated in a reference M1 rack and subjected to full backplane communication cycling with a known-good I/O module set. Bus error counters are monitored across a minimum 30-minute continuous run.
• Firmware Version Verification: Onboard firmware is read and documented. Units are supplied with firmware version data to allow customers to assess compatibility with their existing SolutionCenter project versions.
• Memory Retention Test: Battery-backed SRAM is verified for data retention across a simulated power-cycle sequence. Battery voltage is measured and reported; units with marginal battery voltage are flagged.
• Ethernet Port Functional Test: All Ethernet interfaces are tested for link establishment, packet throughput, and error-free communication at 100 Mbps.
• Thermal Stress Screening: Units are operated at elevated ambient temperature (55°C) for a minimum of 2 hours to screen for latent component failures.

For BS210 availability, cross-reference requests, or bulk BS Series procurement inquiries:

• Email: [email protected]
• WhatsApp: +86 18359293191
• Web: driveknms.com
