Bently Nevada 3300 XL Modules: 330104-00-18-10-02-CN 8mm Proximity Probe

Technical Dossier

Product Details And Specifications

Bently Nevada 3300 XL Series Technical Notes

The Bently Nevada 3300 XL Series is a machinery protection and condition monitoring platform deployed across the global heavy-process industries, including petrochemical refineries, nuclear power stations, offshore oil & gas platforms, LNG terminals, and large-scale rotating equipment facilities. Originally developed by Bently Nevada Corporation (acquired by GE in 2002, subsequently integrated into Baker Hughes), the 3300 XL system established the de facto standard for continuous vibration, position, and speed monitoring on critical rotating machinery such as steam turbines, gas compressors, centrifugal pumps, and large electric motors. Its modular rack-based architecture allows plant engineers to configure monitoring channels precisely to machine train requirements, with each module performing a discrete measurement function within a 19-inch rack enclosure. The 3300 XL platform remains installed in thousands of facilities worldwide, many of which operate under long-term asset management strategies that extend equipment life well beyond original OEM support windows.

3300 XL Full Catalog & Functionalities (SKU List)

Proximity Probes (Eddy-Current Transducers)

• 330104-00-18-10-02-CN: 8mm proximity probe, 18-inch (457mm) armored extension cable, standard tip, metric thread, CE/ATEX rated — the subject of this listing.
• 330104-00-06-10-02-CN: 8mm proximity probe, 6-inch (152mm) extension cable, standard tip, metric thread.
• 330104-00-12-10-02-CN: 8mm proximity probe, 12-inch (305mm) extension cable, standard tip, metric thread.
• 330104-00-30-10-02-CN: 8mm proximity probe, 30-inch (762mm) extension cable, standard tip, metric thread.
• 330105-02-12-10-02-CN: 5mm proximity probe, 12-inch extension cable, standard tip, metric thread, high-temperature rated.
• 330130-040-00-00: 3300 XL 8mm proximity probe, 40-inch armored cable, standard configuration, UL/CSA listed.
• 330180-X1-05: 3300 XL 5mm proximity probe, 5-meter integral cable, stainless steel housing.

Extension Cables

• 330130-040-00-CN: 3300 XL 8mm extension cable, 40-inch, armored, CE marked.
• 330130-080-00-CN: 3300 XL 8mm extension cable, 80-inch, armored, CE marked.

Proximitor Sensors (Signal Conditioners)

• 330180-91-00: 3300 XL 8mm Proximitor sensor, 9-meter system, standard output -18 VDC.
• 330180-X1-00: 3300 XL 8mm Proximitor sensor, field-configurable, DIN rail mount.
• 330185-02-05: 3300 XL 5mm Proximitor sensor, 5-meter system, -24 VDC supply.

Monitor Modules

• 3300/16-13-01-01-00-00-00: 3300 XL Dual Vibration Monitor, 4–20 mA output, relay alarm, rack-mount.
• 3300/20-13-01-01-00-00-00: 3300 XL Thrust Position Monitor, dual-channel, 4–20 mA, configurable trip setpoints.
• 3300/25-13-01-01-00-00-00: 3300 XL Differential Expansion Monitor, single-channel, 4–20 mA output.
• 3300/46M-13-01-00-00-00: 3300 XL Speed Monitor, overspeed detection, relay output, tachometer input.
• 3300/50-13-01-01-00-00-00: 3300 XL Temperature Monitor, thermocouple/RTD input, 4–20 mA output.
• 3300/55-13-01-01-00-00-00: 3300 XL Dynamic Pressure Monitor, piezoelectric sensor input, RMS output.

Power Supplies & Rack Components

• 3300/05-01-01-00-00-00: 3300 XL Rack Power Supply, 115/230 VAC input, redundant configuration capable.
• 3300/10-01-01-00-00-00: 3300 XL Rack Interface Module, System 1 TDI communication, Ethernet output.
