Model: 330102-40-70-10-02-CN
Product Overview
Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.
Datasheet Preview
Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.
Commercial Path
Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.
Technical Dossier
The Bently Nevada 330102 series is a family of eddy-current proximity probes manufactured by Baker Hughes (formerly GE Bently Nevada) and deployed globally in rotating machinery protection systems. These probes are integral components of the 3300 XL 8mm Proximity Transducer System, which is the de facto standard for continuous vibration, position, and speed monitoring in heavy industrial environments including petrochemical refineries, nuclear power stations, LNG processing facilities, offshore platforms, and large-scale turbomachinery installations. The 330102 probe interfaces directly with 330130 and 330180 extension cables and 3300 XL proximitor sensors to form a complete measurement chain compliant with API 670 machinery protection standards.
The following SKUs represent the verified 330102 proximity probe catalog, organized by cable length and connector configuration. Each unit is an 8mm eddy-current probe operating at a nominal gap voltage of −10.4 VDC (at 50 mil / 1.27 mm gap) within the 3300 XL measurement chain.
330102-00-06-10-02-00-00: 6 in. (152 mm) integral cable, standard temperature, no armor, bare lead termination.
330102-00-06-10-02-CN: 6 in. cable, standard temp, coaxial connector (CN) termination for extension cable interface.
330102-00-08-10-02-CN: 8 in. cable, standard temp, CN connector, general-purpose radial/axial mounting.
330102-00-12-10-02-CN: 12 in. cable, standard temp, CN connector, extended reach installations.
330102-00-18-10-02-CN: 18 in. cable, standard temp, CN connector, common in compressor train applications.
330102-00-30-10-02-CN: 30 in. cable, standard temp, CN connector, used where proximitor is remotely mounted.
330102-00-36-10-02-CN: 36 in. cable, standard temp, CN connector, standard for most OEM turbine packages.
330102-00-50-10-02-CN: 50 in. cable, standard temp, CN connector, extended cable run for large frame machines.
330102-40-06-10-02-CN: 6 in. cable, high-temperature rating (HT), CN connector, rated to +177°C continuous.
330102-40-18-10-02-CN: 18 in. cable, high-temp, CN connector, petrochemical hot-section applications.
330102-40-30-10-02-CN: 30 in. cable, high-temp, CN connector, refinery and power generation use.
330102-40-36-10-02-CN: 36 in. cable, high-temp, CN connector, most common HT variant in turbine OEM packages.
330102-40-50-10-02-CN: 50 in. cable, high-temp, CN connector, long-reach high-temperature installations.
330102-40-70-10-02-CN: 70 in. cable, high-temp, CN connector, used in large steam turbine and generator applications where the proximitor is mounted outside the bearing housing zone.
330102-40-90-10-02-CN: 90 in. cable, high-temp, CN connector, maximum standard cable length for 3300 XL 8mm system compliance.
330102-00-36-10-02-00-00: 36 in. integral cable, standard temp, bare lead, legacy installations without CN connector infrastructure.
330102-40-36-10-02-00-00: 36 in. integral cable, high-temp, bare lead, direct-wire legacy panel terminations.
