Bently Nevada 330905 NSv Proximity Probe Modules: 330905-08-13-10-02-05

Technical Dossier

Product Details And Specifications

Bently Nevada 330905 Series Technical Notes

The Bently Nevada 330905 series defines the NSv (Non-contacting, Shaft-voltage-immune) proximity probe standard deployed across global heavy industry. These probes are integral to continuous vibration monitoring systems in petrochemical refineries, nuclear power stations, offshore platforms, and large-scale rotating machinery installations. The 330905 series operates within the 3300 XL and System 1 monitoring ecosystems, providing radial vibration, axial position, and differential expansion measurements on turbines, compressors, pumps, and generators. Their field-proven reliability under high-temperature, high-pressure, and chemically aggressive environments has made them the de facto standard for API 670-compliant machinery protection systems worldwide.

The Evolution of 330905 Architecture

The 330905 series represents the third-generation proximity probe platform from Bently Nevada, succeeding the 330100 and 330780 series. Early-generation probes (pre-2000) used a two-wire coaxial cable architecture with a fixed 5-meter or 9-meter integral cable, limiting field replaceability. The introduction of the NSv (Non-contacting Shaft Voltage) technology addressed a critical failure mode in earlier designs: shaft-induced voltage interference that corrupted vibration signals on large steam turbines with insulated bearings.

The 330905 architecture standardized on a 5 mm tip diameter eddy-current sensing element, a 200 mV/mil (7.87 V/mm) nominal scale factor, and a linear measurement range of 0–90 mils (0–2.29 mm). The series is fully compatible with the 3300 XL 8mm Extension Cable (330130 series) and the 3300 XL Proximitor Sensor (330180 series), forming a three-component measurement chain. Later variants introduced extended temperature ratings (up to 177°C tip temperature) and EMI-hardened cable jackets for nuclear-qualified installations. The 330905 series has entered the mature/end-of-life phase; Bently Nevada's current replacement recommendation is the 330980 series for new installations, though the 330905 remains the dominant installed base in brownfield facilities requiring direct drop-in replacement without recalibration.

330905 Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified 330905 series product matrix. Each model number encodes: probe body length, cable length, connector type, temperature rating, and approval class.

330905-08-13-10-02-05: 8mm probe, 13-inch cable, standard temp, 2m extension, 5m total — radial vibration measurement, API 670 compliant, NSv technology, 200 mV/mil scale factor.

330905-08-13-10-02-09: 8mm probe, 13-inch cable, standard temp, 2m extension, 9m total — extended reach radial vibration probe for deep-bearing housings.

330905-08-13-10-05-05: 8mm probe, 13-inch cable, high-temp rating (177°C), 5m extension, 5m total — designed for hot-section turbine bearing pedestals.

330905-08-13-10-05-09: 8mm probe, 13-inch cable, high-temp rating, 5m extension, 9m total — high-temperature variant with extended cable for large frame turbines.

330905-08-13-10-08-05: 8mm probe, 13-inch cable, standard temp, 8m extension, 5m total — used in axial position monitoring on compressor trains.

330905-08-13-10-08-09: 8mm probe, 13-inch cable, standard temp, 8m extension, 9m total — long-run axial position probe for remote junction box installations.

330905-08-13-10-11-05: 8mm probe, 13-inch cable, standard temp, 11m extension, 5m total — differential expansion measurement on large steam turbines.

330905-08-13-10-11-09: 8mm probe, 13-inch cable, standard temp, 11m extension, 9m total — differential expansion, extended total cable run for large turbine halls.

330905-08-13-10-14-05: 8mm probe, 13-inch cable, standard temp, 14m extension, 5m total — long-distance radial vibration monitoring in large compressor stations.

330905-08-13-10-14-09: 8mm probe, 13-inch cable, standard temp, 14m extension, 9m total — maximum standard cable run configuration for remote monitoring panels.

330905-08-13-10-02-05-CN: China-market variant, 8mm probe, 13-inch cable, 2m extension, 5m total — CCC-certified for PRC industrial installations.

330905-08-13-10-02-05-EX: ATEX/IECEx Zone 1 certified variant — intrinsically safe for explosive atmosphere installations in petrochemical plants.

330905-08-13-10-02-05-NE: Nuclear-qualified variant — seismically qualified per IEEE 344, for nuclear power plant safety-related systems.

330905-08-13-10-02-05-HT: High-temperature variant with Teflon-jacketed cable — rated for continuous operation at 177°C ambient.

330905-08-13-10-02-05-SS: Stainless steel body variant — for corrosive media environments including H2S-rich gas streams in refineries.

330905-08-13-10-02-05-FM: FM-approved variant — Factory Mutual certified for North American hazardous location installations (Class I, Division 1).

Sourcing Hard-to-Find & Obsolete 330905 Parts

All sourced units are subject to full dimensional inspection, impedance verification, and scale factor calibration before dispatch. DriveKNMS provides traceability documentation for each unit, including source origin, inspection date, and calibration certificate. For nuclear-qualified (NE suffix) and ATEX-certified (EX suffix) variants, original certification documentation is preserved and provided with each unit. Customers operating brownfield facilities with existing 330905 installations can extend asset life by 5–10 years through DriveKNMS's lifecycle support program without requiring system recalibration or Proximitor replacement.
