Bosch Rexroth CP6201 Industrial Panel PCs

Technical Dossier

Product Details And Specifications

Bosch Rexroth CP6201 Series: Comprehensive Module Range and Technical Overview

The Bosch Rexroth CP6201 series represents a line of fanless, panel-mounted industrial PCs engineered for deployment in demanding process environments including chemical plants, oil refineries, nuclear power facilities, and continuous-process manufacturing lines. Built on the Beckhoff-derived embedded PC platform and integrated into Rexroth's IndraControl and IndraWorks automation ecosystem, CP6201 units serve as operator interface terminals (OIT) and local control nodes in distributed control system (DCS) and SCADA architectures. Their compact, sealed enclosure design (IP65 front panel) and wide operating temperature tolerance make them a standard specification in heavy industrial HMI applications across Europe, Asia, and the Americas. The series has accumulated a significant installed base in process industries where long service life (10–20 years) and backward compatibility are primary procurement criteria.

The Evolution of CP6201 Architecture

The CP6201 platform was introduced as part of Bosch Rexroth's IndraControl HMI hardware generation, targeting panel PC applications that required a ruggedized, DIN-rail or panel-mount form factor with integrated display. Early variants shipped with Intel Celeron M and Pentium M processors running Windows XP Embedded or Windows CE, interfacing with Rexroth IndraWorks DS and IndraWorks MLD engineering environments via proprietary fieldbus adapters (SERCOS II, Profibus DP, CANopen).

Mid-generation revisions introduced Intel Core 2 Duo and Atom processors, expanded RAM ceilings to 2 GB DDR2, and added support for Windows Embedded Standard 7. Communication options broadened to include PROFINET IO and EtherCAT master capability, aligning the platform with IEC 61158 fieldbus standards increasingly mandated in new plant construction.

Later production runs addressed obsolescence pressure from the Windows XP end-of-life cycle by offering Windows 7 and Windows 10 IoT LTSB images. However, the underlying hardware architecture — passive backplane, CompactFlash primary storage, and fixed-resolution resistive touchscreen — remained largely unchanged, creating compatibility continuity for existing SCADA integrations but limiting performance headroom. The CP6201 series is now in the mature/end-of-life phase. Bosch Rexroth's current recommended migration path is toward the IndraControl XM or CP6606 platform. Consequently, CP6201 units in active plant service are primarily supported through spare parts procurement and third-party repair rather than OEM channel replenishment.

CP6201 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly traded configurations within the CP6201 product family. Each unit is a self-contained panel PC; functional differentiation is determined by display size, processor generation, memory configuration, and communication interface options encoded in the ordering suffix.

CP6201-0001-0060: 12.1-inch XGA panel PC, Celeron M 600 MHz, 256 MB RAM, CF storage, Windows XP Embedded, single Ethernet port — standard HMI node for IndraWorks DCS integration.
CP6201-0001-0070: 12.1-inch XGA panel PC, Pentium M 1.0 GHz, 512 MB RAM, CF storage, Windows XP Embedded — upgraded CPU variant for higher-throughput visualization tasks.
CP6201-0001-0080: 12.1-inch XGA panel PC, Intel Atom N270, 1 GB DDR2, CF storage, Windows Embedded Standard 2009 — transition-generation unit bridging XP and Win7 deployments.
CP6201-0001-0090: 12.1-inch XGA panel PC, Intel Atom D525 dual-core, 1 GB DDR2, CF/SSD storage option, Windows Embedded Standard 7 — primary Win7-era HMI configuration.
CP6201-0002-0060: 15-inch XGA panel PC, Celeron M 600 MHz, 256 MB RAM, CF storage, Windows XP Embedded — larger display variant for operator stations requiring wider field-of-view.
CP6201-0002-0070: 15-inch XGA panel PC, Pentium M 1.0 GHz, 512 MB RAM, CF storage, Windows XP Embedded — performance-tier 15-inch configuration.
CP6201-0002-0080: 15-inch XGA panel PC, Intel Atom N270, 1 GB DDR2, Windows Embedded Standard 2009 — mid-generation 15-inch transition unit.
CP6201-0002-0090: 15-inch XGA panel PC, Intel Atom D525 dual-core, 1 GB DDR2, Windows Embedded Standard 7 — Win7-era 15-inch standard configuration.
CP6201-0003-0060: 17-inch SXGA panel PC, Celeron M 600 MHz, 256 MB RAM, CF storage, Windows XP Embedded — large-format display for central control room operator consoles.
CP6201-0003-0070: 17-inch SXGA panel PC, Pentium M 1.0 GHz, 512 MB RAM, CF storage, Windows XP Embedded — performance 17-inch variant.
CP6201-0003-0080: 17-inch SXGA panel PC, Intel Atom N270, 1 GB DDR2, Windows Embedded Standard 2009 — 17-inch mid-generation unit.
CP6201-0003-0090: 17-inch SXGA panel PC, Intel Atom D525 dual-core, 1 GB DDR2, Windows Embedded Standard 7 — Win7-era 17-inch configuration.
CP6201-0004-0090: 19-inch SXGA panel PC, Intel Atom D525 dual-core, 2 GB DDR2, SSD storage, Windows Embedded Standard 7 — high-capacity display variant for multi-loop process visualization.
CP6201-0001-0100: 12.1-inch panel PC, Intel Core 2 Duo, 2 GB DDR2, SSD, Windows 7 Embedded — late-generation high-performance 12-inch unit with extended OS support lifecycle.
CP6201-0002-0100: 15-inch panel PC, Intel Core 2 Duo, 2 GB DDR2, SSD, Windows 7 Embedded — late-generation 15-inch unit; highest-specification standard catalog entry for this display class.
CP6201-0003-0100: 17-inch panel PC, Intel Core 2 Duo, 2 GB DDR2, SSD, Windows 7 Embedded — late-generation 17-inch unit; recommended for sites requiring Win7 LTSB support through 2023 extended agreements.

Sourcing Hard-to-Find & Obsolete CP6201 Parts

The CP6201 series has been formally discontinued by Bosch Rexroth. OEM new-stock availability through authorized distribution channels is exhausted for the majority of ordering codes, particularly those with XP Embedded and Atom-class processors. DriveKNMS maintains a dedicated inventory of CP6201 units sourced through decommissioned plant asset recovery, authorized surplus liquidation, and direct procurement from industrial equipment brokers operating in the EU, North America, and Southeast Asia.

For end-users operating CP6201 nodes in active DCS or SCADA environments, DriveKNMS provides the following lifecycle extension services: verified-functional exchange units with documented test records; CompactFlash and SSD storage cloning with original OS image preservation; touchscreen digitizer and backlight replacement for units with display degradation; and BIOS battery replacement with full POST verification. All units are shipped with a 12-month return-to-base warranty covering hardware failure under normal operating conditions. Customers requiring long-term supply agreements (LTA) for multi-unit plant fleets are accommodated with reserved stock allocation and priority fulfillment SLAs.

Quality Control for the CP6201 Range

CP6201 units undergo a structured incoming inspection and functional verification protocol at DriveKNMS before dispatch. The process addresses the specific failure modes documented in this platform: backlight inverter degradation, CompactFlash controller errors, resistive touchscreen calibration drift, and Ethernet PHY faults caused by electrostatic discharge in industrial environments.

Inspection stages include: visual inspection for physical damage to the front bezel, rear I/O panel, and mounting flanges; power-on self-test (POST) verification with BIOS version logging; OS boot verification to Windows desktop with all device drivers confirmed loaded; touchscreen calibration test across a 9-point grid; Ethernet port link and throughput test at 10/100 Mbps; serial port (COM1/COM2) loopback test; USB port enumeration test; and 48-hour burn-in under simulated load with thermal monitoring. Units that fail any stage are quarantined for component-level repair or parts recovery. Test records are retained for 24 months and are available to customers on request.
