Bürkert Type 2030 Series: Comprehensive Module Range and Technical Overview

The Bürkert Type 2030 is a piston-operated diaphragm valve engineered for demanding process control applications across global heavy industry. It is a standard reference component in chemical processing plants, pharmaceutical manufacturing, food and beverage production, water treatment facilities, and petrochemical refineries. The Type 2030 design separates the actuator from the fluid path via a diaphragm, eliminating contamination risk and enabling use with aggressive, ultrapure, or hygienic media. Its global installed base spans facilities in Europe, Asia-Pacific, and the Americas, where it is specified as a primary shut-off and control element in both new installations and long-term maintenance programs.

The series operates across a defined pressure range (typically 0–10 bar depending on body size and material), with pneumatic actuation via piston mechanism providing fast, repeatable stroke response. Body materials include PVC, PP, PVDF, and stainless steel, making the Type 2030 adaptable to corrosive and high-purity environments. Diaphragm materials (EPDM, PTFE, FKM) are selected based on media compatibility. The valve is available in normally closed (NC) and normally open (NO) configurations, with 2/2-way function as standard.

The Evolution of Type 2030 Architecture

The Bürkert Type 2030 was introduced as a successor to earlier pneumatically actuated diaphragm designs, consolidating the actuator and valve body into a compact, modular assembly. Early variants used NBR diaphragms and were limited to neutral media. Subsequent generations introduced PTFE-lined diaphragms and PVDF bodies, extending chemical compatibility to strong acids and alkalis. The integration of the F-MFC_AI_4 flow measurement and control interface (as present in the current SKU: TYPE 2030, 5,5-7BAR 95763693 TTLA08-11 F-MFC_AI_4, 3808-020005-11 3881-020010-12) represents a later-generation configuration combining valve actuation with analog input signal processing for mass flow control applications.

Compatibility across generations is maintained at the body connection level (DIN, ANSI, SMS, RJT flange standards), but actuator top-works and positioner interfaces differ between early and current variants. Replacement of legacy Type 2030 units requires verification of body size (DN 8–DN 50), actuator size code (e.g., TTLA08-11), pressure rating, and diaphragm material code before ordering. Bürkert's modular design philosophy allows actuator replacement without body removal in most configurations, reducing downtime in critical process lines.

Type 2030 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked configurations within the Bürkert Type 2030 series. Units are classified by function and actuator/body specification:

Piston-Actuated Shut-Off Valves (NC/NO, Standard Pressure)

• Type 2030 DN8 EPDM NC PVC: DN8 body, EPDM diaphragm, normally closed, PVC body, 0–10 bar
• Type 2030 DN10 PTFE NC PVDF: DN10, PTFE diaphragm, normally closed, PVDF body, chemical-resistant
• Type 2030 DN15 EPDM NO PP: DN15, EPDM diaphragm, normally open, polypropylene body
• Type 2030 DN20 FKM NC SS316: DN20, FKM diaphragm, normally closed, 316L stainless steel body
• Type 2030 DN25 PTFE NO PVDF: DN25, PTFE diaphragm, normally open, PVDF body, ultrapure media
• Type 2030 DN32 EPDM NC PVC: DN32, EPDM diaphragm, normally closed, PVC body, water/wastewater
• Type 2030 DN40 PTFE NC SS316: DN40, PTFE diaphragm, normally closed, stainless steel, high-purity
• Type 2030 DN50 EPDM NO PP: DN50, EPDM diaphragm, normally open, PP body, large-bore process lines

Flow Control & MFC-Integrated Configurations

• TYPE 2030 95763693 TTLA08-11 F-MFC_AI_4 3808-020005-11 3881-020010-12: Current page SKU. Piston actuator TTLA08-11, analog input interface F-MFC_AI_4, pressure range 5.5–7 bar, with associated cable assembly 3808-020005-11 and sensor module 3881-020010-12
• Type 2030 F-MFC_AI_2 DN15 PVDF: 2-channel analog input MFC variant, DN15, PVDF body
• Type 2030 F-MFC_DI DN10 PVC: Digital input MFC interface, DN10, PVC body, on/off control
• Type 2030 Positioner 1067 DN20: Integrated with Bürkert Type 1067 positioner for proportional control

Actuator & Accessory Modules

• 3808-020005-11: Cable assembly for Type 2030 MFC integration, 5-pin M12 connector, 1m length
• 3881-020010-12: Sensor/transmitter module for Type 2030 flow measurement, analog output 4–20 mA
• TTLA08-11: Piston actuator top-work, size 08, stroke 11 mm, for Type 2030 DN8–DN15 bodies
• Type 2030 Repair Kit EPDM DN15: OEM diaphragm and seal replacement kit, DN15, EPDM
• Type 2030 Repair Kit PTFE DN25: OEM diaphragm and seal replacement kit, DN25, PTFE

Sourcing Hard-to-Find & Obsolete Type 2030 Parts

The Bürkert Type 2030 series spans multiple production generations. Certain body/actuator combinations, particularly those with legacy analog interfaces (pre-F-MFC_AI_4 signal conditioning) or discontinued body materials, are no longer available through standard distribution channels. DriveKNMS maintains a dedicated inventory of new-old-stock (NOS), tested-used, and reconditioned Type 2030 assemblies and sub-components to support facilities operating legacy installations.

For MFC-integrated variants such as the TYPE 2030 95763693 TTLA08-11 F-MFC_AI_4, sourcing requires matching not only the valve body and actuator but also the associated cable harness (3808-020005-11) and sensor module (3881-020010-12). DriveKNMS cross-references all three components against the original system BOM to ensure functional compatibility before dispatch. Customers operating Bürkert EDIP (Electronic Direct Interface Platform) systems or Type 8635/8636 mass flow controllers that interface with Type 2030 valves can submit full BOM lists for consolidated sourcing.

Lead times for obsolete configurations are quoted within 24 hours of inquiry. Emergency same-day dispatch is available for in-stock units. All units are shipped with full traceability documentation.

Quality Control for the Type 2030 Range

Each Type 2030 unit processed by DriveKNMS undergoes a structured inspection and functional test protocol prior to dispatch:

• Visual inspection: Body integrity, diaphragm condition, actuator housing, connector pins, and label legibility
• Pressure leak test: Seat leakage test per IEC 60534-4 / EN 12266-1 at rated pressure (5.5–7 bar for 95763693 variant)
• Actuation cycle test: Minimum 10 open/close cycles under rated pilot pressure to verify piston travel and return spring function
• Electrical interface verification: For F-MFC_AI_4 variants, analog input signal continuity and impedance check on M12 connector (3808-020005-11)
• Sensor module output check: 4–20 mA output linearity verification for 3881-020010-12 sensor modules
• Diaphragm integrity test: Pneumatic hold test to confirm no cross-contamination path between actuator and fluid chamber

Test records are retained per unit serial number and available upon request for regulated industries (pharmaceutical GMP, nuclear QA programs).
