ComAp InteliGen IG-NTC Modules Gen-Set Controller InteliGen IG-NTC HW Version 1.3-TO

Technical Dossier

Product Details And Specifications

ComAp InteliGen Series Technical Notes

The Evolution of InteliGen Architecture

The InteliGen platform originated in the early 2000s as ComAp's response to the growing demand for networked, multi-genset control in industrial standby and prime power applications. The first-generation IG-NT controllers introduced a 32-bit processor core, a backlit LCD operator interface, and a proprietary CAN-based inter-module bus (IB-Lite). Hardware revision milestones are significant for compatibility: HW version 1.x units use a specific backplane connector pinout and firmware branch (FW 1.x) that is not forward-compatible with HW 2.x firmware. The IG-NTC variant (the C denoting the compact or cost-optimized configuration) was introduced to address mid-range applications where the full IG-NT feature set was not required, while retaining the same physical form factor and communication bus. The HW version 1.3-TO designation indicates a specific board revision with a terminal output (TO) configuration, relevant for replacement sourcing. Later generations — InteliGen 200, InteliGen 500, and the current InteliGen NT GPRS/4G variants — introduced Ethernet, USB, and cellular connectivity, but retain backward-compatible I/O expansion slots for IG-IOM and IG-BIO modules. Understanding hardware revision compatibility is critical when sourcing replacement units: a HW 2.x controller cannot directly substitute a HW 1.x unit without firmware reconfiguration and potential I/O remapping.

InteliGen Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified InteliGen series module range, classified by functional category.

Controllers (Base Units)

• IG-NTC HW 1.3-TO: Compact gen-set controller, terminal output, HW rev 1.3, single-unit operation.
• IG-NTC HW 1.4-TO: Compact controller, updated relay driver circuit, terminal output variant.
• IG-NTC HW 2.0: Revised compact controller, enhanced EMC compliance, updated CAN transceiver.
• IG-NT HW 2.x: Full-featured gen-set controller, parallel operation, CAN bus, LCD display.
• IG-NT GPRS: Gen-set controller with integrated GPRS modem for remote monitoring.
• IG-NT 4G: Gen-set controller with integrated 4G/LTE cellular modem, current production.
• IG-200: Second-generation InteliGen controller, Ethernet + USB, enhanced protection relay functions.
• IG-500: High-end InteliGen controller, dual Ethernet, extended I/O, IEC 61850 support.
• IG-NTC-BB: Compact controller variant with battery-backed RTC and extended temperature range.
• IG-NTC-SW: Software-only license variant for virtual controller deployment in SCADA environments.

I/O Expansion Modules

• IG-IOM: I/O expansion module, 8 DI / 8 DO / 4 AI, IB-Lite bus interface.
• IG-IOM-B: Extended I/O module, 16 DI / 8 DO, for high-density input applications.
• IG-BIO: Binary I/O module, 8 DI / 8 DO, plug-in to IG-NT backplane slot.
• IG-AIO: Analog I/O module, 4 AI (0-20 mA / 0-10 V) / 2 AO, for sensor integration.

Communication & Adapter Modules

• IG-COM: RS-232 / RS-485 communication module, Modbus RTU master/slave.
• IG-ETHERNET: Ethernet adapter module, 10/100 Mbps, Modbus TCP, SNMP support.
• IG-CANOPEN: CANopen gateway module, DS301 profile, for integration with CANopen field devices.
• IG-PROFIBUS: PROFIBUS DP slave adapter, for integration into Siemens and ABB DCS environments.

Power Supply Modules

• IG-PSU-24: 24 VDC auxiliary power supply module, 5 A output, DIN rail mount.
• IG-PSU-12: 12 VDC auxiliary power supply module, for battery-backed panel installations.
