BONITRON M3575R Modules | M3575R-H33BF Resistor Brake Module

Technical Dossier

Product Details And Specifications

BONITRON M3575R Series: Comprehensive Module Range and Technical Overview

The BONITRON M3575R series comprises dynamic braking resistor modules engineered for integration with AC variable frequency drives (VFDs) across heavy industrial sectors. These units are deployed in chemical processing plants, petroleum refineries, offshore platforms, nuclear auxiliary systems, and large-scale material handling facilities where controlled deceleration of high-inertia loads is a critical process requirement. The M3575R line is designed to dissipate regenerative energy produced during motor braking events, protecting drive DC bus capacitors from overvoltage faults. BONITRON, headquartered in Nashville, Tennessee (USA), has supplied braking and ride-through solutions to North American and international industrial markets for over four decades. The M3575R series is compatible with a broad range of drive platforms including Allen-Bradley PowerFlex, Siemens SINAMICS, ABB ACS, and Yaskawa A1000/G7 families when correctly sized to drive kW rating and duty cycle.

The Evolution of M3575R Architecture

BONITRON's braking resistor product line evolved from fixed-resistance wirewound assemblies used in early 1980s DC drive systems toward the thermally optimized, stainless-steel-housed resistor banks of the M3575R series. Early generations used open-frame construction with manual thermal cutouts; the M3575R introduced enclosed NEMA-rated housings, integrated thermal switches (normally-closed, wired in series with the drive's fault input), and standardized mounting footprints compatible with 19-inch rack and panel-mount configurations.

The H-suffix variants (e.g., M3575R-H33BF) denote high-duty-cycle ratings, typically 10% ED (10 seconds on / 90 seconds off) or higher, suitable for applications with frequent regenerative braking cycles such as crane hoists, centrifuges, and test stands. The BF suffix indicates a specific resistance-wattage combination optimized for mid-range drive kW classes. As VFD technology migrated toward integrated braking choppers (IGBT-based), the M3575R series transitioned from standalone resistor banks to companion units paired with BONITRON's M3575 braking chopper modules, forming a complete dynamic braking assembly. The series remains in active support status; however, several sub-variants have reached end-of-manufacture and are available exclusively through aftermarket channels.

M3575R Full Catalog & Functionalities (SKU List)

The following SKUs represent the documented M3575R series range. Units are classified by function and resistance/wattage specification. Each model is a discrete resistor brake module unless otherwise noted.

Resistor Brake Modules — Standard Duty

• M3575R-H33BF: High-duty resistor brake module, 33 Ω, optimized for mid-range VFD braking duty cycles.
• M3575R-H27BF: High-duty resistor brake module, 27 Ω, for higher-current drive platforms requiring lower resistance.
• M3575R-H20BF: High-duty resistor brake module, 20 Ω, suited for 15–30 HP drive classes with frequent braking.
• M3575R-H15BF: High-duty resistor brake module, 15 Ω, for 30–50 HP drive applications with sustained deceleration loads.
• M3575R-H10BF: High-duty resistor brake module, 10 Ω, for 50–75 HP class drives with high regenerative energy.
• M3575R-H8BF: High-duty resistor brake module, 8 Ω, for 75–100 HP drive platforms.
• M3575R-H6BF: High-duty resistor brake module, 6 Ω, for 100–150 HP class drives.
• M3575R-H5BF: High-duty resistor brake module, 5 Ω, for 150 HP and above drive systems.

Resistor Brake Modules — Extended Duty / Parallel Configuration

• M3575R-H33BF-2: Dual-unit parallel assembly, 33 Ω per unit, for extended duty cycle applications exceeding standard 10% ED rating.
• M3575R-H27BF-2: Dual-unit parallel assembly, 27 Ω per unit, for high-frequency braking in crane and hoist systems.
• M3575R-H20BF-2: Dual-unit parallel assembly, 20 Ω per unit, for continuous-duty braking in test stand applications.
• M3575R-H15BF-2: Dual-unit parallel assembly, 15 Ω per unit, for large centrifuge and compressor drive systems.

Companion Braking Chopper Modules (M3575 Series — paired with M3575R resistors)

• M3575-4A: IGBT braking chopper module, 480 VAC input class, pairs with M3575R resistor banks for complete dynamic braking assemblies.
• M3575-6A: IGBT braking chopper module, 600 VAC input class, for higher-voltage drive systems.
• M3575-4A-R: Replacement/retrofit braking chopper, 480 VAC, with updated IGBT gate driver for improved switching reliability.

Sourcing Hard-to-Find & Obsolete M3575R Parts

Several M3575R sub-variants have been discontinued by BONITRON as the installed base of legacy VFD systems ages. DriveKNMS maintains a dedicated inventory of new-surplus, reconditioned, and tested M3575R modules sourced from decommissioned plant equipment, OEM overstock, and authorized distributor liquidations. For end-users operating facilities with 10–30 year-old drive systems, the M3575R series represents a long-tail spare parts requirement: the resistor modules themselves have no firmware dependency and no obsolescence risk from software, making physical stock the sole constraint on continued operation.

DriveKNMS provides the following lifecycle support services for the M3575R range: verified stock confirmation with photographic evidence prior to shipment; resistance and thermal switch continuity testing on all units; original BONITRON datasheet and wiring diagram provision; and cross-reference matching for customers who know only the drive model (e.g., Allen-Bradley 1336 PLUS II, PowerFlex 700) and require assistance identifying the correct M3575R variant by resistance value and wattage.

Quality Control for the M3575R Range

Each M3575R unit processed by DriveKNMS undergoes a standardized inspection and test protocol prior to shipment. Resistance value is measured at four-wire Kelvin measurement to ±1% of rated value. Thermal switch continuity is verified at ambient temperature (normally-closed state confirmed) and thermal switch trip temperature is validated where test equipment permits. Housing integrity, terminal block condition, and mounting hardware completeness are inspected visually. Units exhibiting resistance drift exceeding ±5% of nameplate value, open or shorted thermal switches, or physical damage to the resistor element are quarantined and not offered for sale. Test records are retained per unit serial number where serialization is present.
