Emerson DeltaV KJ4006X1-BC1 12P4720X062: Fused 8-Channel Terminal Block

Technical Dossier

Product Details And Specifications

Emerson DeltaV KJ4006X1 Series Technical Notes

KJ4006X1 Full Catalog & Functionalities (SKU List)

Fused Terminal Blocks — 8-Channel AI/DI Interface

• KJ4006X1-BC1 12P4720X062: 8-ch fused terminal block, BC1 rev, standard analog input wiring interface
• KJ4006X1-BC2 12P4720X062: 8-ch fused terminal block, BC2 rev, updated fuse access and terminal marking
• KJ4006X1-BC3 12P4720X062: 8-ch fused terminal block, BC3 rev, revised UL/CE compliance markings
• KJ4006X1-BA1 12P4720X062: 8-ch fused terminal block, BA1 rev, early production variant for DeltaV v6–v8
• KJ4006X1-BB1 12P4720X062: 8-ch fused terminal block, BB1 rev, intermediate revision with ceramic fuse upgrade

Non-Fused Terminal Blocks — 8-Channel Interface

• KJ4001X1-BC1: 8-ch non-fused terminal block, standard AI wiring, no per-channel overcurrent protection
• KJ4001X1-BA1: 8-ch non-fused terminal block, early revision, DeltaV S-series compatible

16-Channel Terminal Blocks

• KJ4009X1-BC1: 16-ch fused terminal block, dual 8-ch fuse rows, high-density marshalling
• KJ4009X1-BA1: 16-ch fused terminal block, early revision, DeltaV M-series I/O card interface

Digital Output Terminal Blocks

• KJ4005X1-BC1: 8-ch DO terminal block, fused, 24 VDC discrete output field wiring interface
• KJ4005X1-BA1: 8-ch DO terminal block, early revision, compatible with KJ3222X1 DO card

Analog Output Terminal Blocks

• KJ4003X1-BC1: 8-ch AO terminal block, fused, 4–20 mA output field wiring interface
• KJ4003X1-BA1: 8-ch AO terminal block, early revision, DeltaV v6–v10 compatible

HART-Enabled Terminal Blocks

• KJ4007X1-BC1: 8-ch HART-enabled fused terminal block, supports HART pass-through to DeltaV HART multiplexer
• KJ4007X1-BA1: 8-ch HART-enabled terminal block, early revision, limited HART revision support

Associated I/O Cards (Compatible Pairing Reference)

• KJ3001X1-BA1: 8-ch AI card, 4–20 mA, pairs with KJ4006X1 fused terminal block
• KJ3002X1-BA1: 8-ch AI card, thermocouple/RTD, pairs with KJ4006X1 terminal block
• KJ3222X1-BA1: 8-ch DO card, 24 VDC, pairs with KJ4005X1 terminal block
