GE DS200TBQDG1AFF Extension Terminal Board – Mark VI DS200 Series Modules

Name: GE DS200TBQDG1AFF Extension Terminal Board – Mark VI DS200 Series Modules
Brand: General Electric

Model: DS200TBQDG1AFF

Brand General Electric

Series Mark VI

Model DS200TBQDG1AFF

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

GE DS200 Series Technical Notes

The Evolution of DS200 Architecture

The DS200 series was introduced alongside the Mark VI platform in the mid-1990s as a replacement for the earlier Mark V (DS3800 / DS5000 series) hardware. The architecture is built around a high-density backplane bus (JA1/JB1/JC1 connectors) that carries both power and serial communication signals between terminal boards and the VCMI/VCRC controller cards seated in the VME rack.

DS200 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked DS200 series components. Each entry reflects a distinct functional role within the Mark VI control architecture.

Terminal & Extension Boards

DS200TBQDG1AFF: Extension terminal board for quad I/O expansion, JA1 backplane interface
DS200TBCAG1AAA: Contact input terminal board, 24 VDC discrete input conditioning
DS200TBCBG1AAA: Contact input terminal board, high-density 48-channel discrete input
DS200TBASG1A: Analog signal terminal board, 4–20 mA / 0–10 V input conditioning
DS200TBRAG1AAA: RTD input terminal board, 3-wire PT100 signal conditioning
DS200TBPAG1A: Pulse/speed input terminal board, magnetic pickup and proximity probe interface
DS200TBQCG1A: Quad contact output terminal board, relay-driven discrete outputs

I/O Modules

DS200IOCAG1A: I/O controller adapter, primary rack communication bridge
DS200SDCIG1A: DC power input module, 125 VDC bus interface
DS200SDCCG1A: DC power conditioning card, redundant supply arbitration
DS200DSPCH1A: Digital signal processor card, high-speed event capture
DS200ADGIH1A: Analog-to-digital conversion module, 16-bit resolution
DS200DTBCG1AAA: Discrete terminal board with current limiting, 24 VDC output

Communication & CPU Modules

DS200VCMIG2A: VME communication interface card, primary Mark VI network node
DS200VCRCG1A: VME controller card, real-time turbine control execution
DS200EXPSG1ADA: Expansion power supply module, auxiliary rack power distribution
DS200PCCAG1A: Process control communication adapter, Ethernet/serial gateway

Quality Control for the DS200 Range

DS200 series boards present specific test challenges due to their backplane-dependent architecture: most boards cannot be functionally verified in isolation without a live Mark VI rack environment or a dedicated test fixture that replicates the JA1/JB1/JC1 bus signals. DriveKNMS employs the following test protocol for DS200 inventory:

Visual inspection: component-level examination for corrosion, cracked solder joints, damaged connectors, and capacitor degradation
Powered bench test: boards are seated in a test rack with active Mark VI backplane simulation to verify bus communication handshake and register-level response
Signal-path verification: for terminal boards, each I/O channel is exercised with calibrated signal sources to confirm within-specification response
Firmware revision check: EEPROM firmware version is recorded and compared against OEM revision history to flag boards requiring update before deployment
Burn-in: boards are operated under load for a minimum of 24 hours to screen for early-life failures prior to shipment
