GE Fanuc VersaMax IC200 Modules - IC200CHS022L

Name: GE Fanuc VersaMax IC200 Modules - IC200CHS022L
Brand: GE Fanuc

Model: IC200CHS022L

Brand GE Fanuc

Series Versamax

Model IC200CHS022L

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

GE Fanuc VersaMax IC200 Series Technical Notes

The GE Fanuc VersaMax IC200 series is a modular programmable logic controller (PLC) platform deployed across global heavy industry, including petrochemical plants, nuclear power facilities, oil refineries, and continuous process manufacturing. Introduced in the late 1990s as a successor to the Series 90-30 architecture, the VersaMax system established itself as a mid-range automation backbone capable of handling distributed I/O, high-speed discrete control, and analog process loops within a single unified backplane ecosystem. Its compact carrier-based form factor reduced panel footprint while maintaining the I/O density required for large-scale process installations. Installed base counts in the tens of thousands of nodes globally, with active deployments in North America, Europe, and Asia-Pacific. The IC200 series remains a critical spare parts target for facilities operating legacy DCS/PLC hybrid architectures where full system migration is not economically viable.

The Evolution of VersaMax IC200 Architecture

The VersaMax IC200 platform was formally released by GE Fanuc Automation in 1998, designed to bridge the gap between the high-end Series 90-70 rack systems and the entry-level Micro PLC line. The architecture is built around a carrier-based I/O bus: I/O modules plug into dedicated carriers (CHS series), which connect via a local bus to a CPU or Network Interface Unit (NIU). This modular topology allowed engineers to configure systems from 8 to 64+ I/O points per local station without rewiring.

Compatibility note: IC200 modules are not cross-compatible with IC693 (Series 90-30) or IC695 (RX3i) backplanes. Carrier type (standard vs. compact) must match the module form factor. Firmware versions on CPUs must be validated against the programming software (Proficy Machine Edition) version in use at the site.

IC200 Full Catalog & Functionalities (SKU List)

CPU & Controller Modules

IC200CPUE05: VersaMax CPU, 32KB user memory, RS-232 port, standalone or NIU-hosted control.
IC200CPUE05-AE: VersaMax CPU with embedded Ethernet port, 32KB memory, supports SRTP and Modbus TCP.
IC200CPU001: Entry-level VersaMax CPU, 16KB memory, serial programming interface only.
IC200CPU002: Mid-range CPU, 32KB memory, expanded instruction set for floating-point math.

I/O Carriers (CHS Series)

IC200CHS001: Standard I/O carrier, 4-slot, supports full-size IC200 I/O modules.
IC200CHS002: Standard I/O carrier, 8-slot, primary expansion carrier for large I/O counts.
IC200CHS022: Compact I/O carrier, 4-slot, reduced depth for space-constrained panels.
IC200CHS022L: Compact I/O carrier, 4-slot, left-side bus connection variant for daisy-chain expansion.
IC200CHS014: Standalone carrier with integrated power supply connector, 4-slot.

Discrete Input Modules (DI)

IC200MDL640: 120VAC discrete input, 8-point, optically isolated, for field device status monitoring.
IC200MDL650: 24VDC discrete input, 16-point, positive logic, high-density field wiring.
IC200MDL660: 24VDC discrete input, 32-point, compact module for high I/O density applications.

Discrete Output Modules (DO)

IC200MDL740: 120VAC discrete output, 8-point, relay contact, for motor starter and valve control.
IC200MDL750: 24VDC discrete output, 16-point, transistor sourcing, fast switching for solenoids.
IC200MDL760: 24VDC discrete output, 32-point, high-density transistor output module.

Analog Input Modules (AI)

IC200ALG230: Analog input, 4-channel, 4–20mA / 0–10V configurable, 12-bit resolution.
IC200ALG240: Analog input, 8-channel, 4–20mA, 12-bit, for multi-loop process variable acquisition.
IC200ALG260: Analog input, 4-channel, thermocouple/RTD, for temperature measurement in process loops.

Analog Output Modules (AO)

IC200ALG320: Analog output, 2-channel, 4–20mA, 12-bit, for control valve and positioner drive.
IC200ALG330: Analog output, 4-channel, 4–20mA / 0–10V, for multi-loop setpoint output.

Communications & Network Adapters

IC200PBI001: PROFIBUS-DP slave adapter, connects VersaMax I/O station to PROFIBUS master networks.
IC200DNM002: DeviceNet slave adapter, integrates VersaMax I/O into Allen-Bradley and Rockwell DeviceNet systems.
IC200ETM001: Ethernet TCP/IP network interface unit (NIU), supports SRTP, Modbus TCP, and EGD protocols.

Power Supply Modules

IC200PWR002: 24VDC input power supply, 30W, for standard VersaMax carrier power rail.
IC200PWR101: 120/240VAC input power supply, 30W, universal input for global installations.

Quality Control for the IC200 Range

VersaMax IC200 modules present specific test challenges due to their carrier-based bus architecture and mixed analog/discrete I/O configurations. DriveKNMS applies the following verification protocol to all IC200 units processed through our facility:
