GE Series 6 IC600BF843L Modules

Name: GE Series 6 IC600BF843L Modules
Brand: GE Fanuc

Model: IC600BF843L

Brand GE Fanuc

Series Series 6 IC600BF843L

Model IC600BF843L

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

GE Fanuc Series 6 Series Technical Notes

Installations of Series 6 hardware remain operational in facilities where the cost and risk of a full DCS migration outweigh the expense of maintaining legacy spare parts inventory. The IC600BF843L — a 16-channel analog input module with 12-bit resolution — is one of the most frequently sourced components in this platform due to its role in process variable acquisition (temperature, pressure, flow).

The Evolution of Series 6 Architecture

The Series 6 platform was engineered around a parallel backplane bus architecture that predates the fieldbus and Ethernet-based I/O standards now dominant in modern DCS environments. Early revisions (circa 1982–1988) used the IC600 base chassis family with proprietary coaxial remote I/O links. Mid-cycle revisions introduced enhanced CPU modules with expanded memory addressing and faster scan rates. Late-production variants added limited support for Genius Bus (GBC) communication, bridging Series 6 installations toward the Series 90 migration path.

Compatibility constraints are a primary maintenance concern: Series 6 I/O modules are not electrically or mechanically interchangeable with Series 90-30 or Series 90-70 hardware. Firmware revisions within the Series 6 family also introduced slot-addressing dependencies — replacement modules must match the original firmware suffix (e.g., the "L" suffix on IC600BF843L denotes a specific production revision). Substituting a non-matching suffix without verifying backplane compatibility can result in configuration faults or data integrity errors.

Series 6 Full Catalog & Functionalities (SKU List)

The following represents a verified cross-section of the GE Fanuc Series 6 module catalog, organized by functional category.

Analog Input Modules (AI)

IC600BF843L: 16-channel analog input, 12-bit resolution, 4–20 mA / 0–10 V configurable per channel
IC600BF841: 8-channel analog input, voltage/current selectable, standard rack mount
IC600BF844: 16-channel analog input, high-density, thermocouple/RTD compatible
IC600BF845: 8-channel isolated analog input, 16-bit resolution, precision process measurement

Analog Output Modules (AO)

IC600BF852: 8-channel analog output, 12-bit DAC, 4–20 mA current loop output
IC600BF853: 4-channel analog output, voltage mode, ±10 V range, valve positioner control

Digital Input Modules (DI)

IC600BF901: 32-channel 24 VDC digital input, sinking type, standard density
IC600BF902: 16-channel 120 VAC digital input, optically isolated, field wiring terminal block
IC600BF903: 32-channel 120 VAC digital input, high-density, large I/O count applications
IC600BF911: 16-channel 24 VDC digital input, sourcing type, CE-marked revision

Digital Output Modules (DO)

IC600BF921: 16-channel relay output, Form C contacts, 2 A per channel, motor starter control
IC600BF922: 32-channel 24 VDC transistor output, sinking, high-speed switching
IC600BF923: 16-channel 120 VAC triac output, zero-crossing switching, resistive loads

CPU & Controller Modules

IC600CPU772: Series 6 CPU, 16 KB user memory, standard scan rate controller
IC600CPU774: Enhanced CPU, 32 KB memory, floating-point coprocessor, extended I/O addressing
IC600CPU776: High-performance CPU, 64 KB memory, sub-10 ms scan cycle, time-critical loops

Power Supply Modules

IC600PS501: 5 VDC rack power supply, 10 A output, standard 10-slot chassis
IC600PS502: Redundant power supply, hot-swap capable, high-availability configurations

Communication & Bus Adapters

IC600CB501: Genius Bus Controller, Series 6 to Genius I/O network interface, 153.6 kbps
IC600CB502: Remote I/O scanner, coaxial bus, supports up to 7 remote drop chassis

Quality Control for the Series 6 Range

Series 6 modules present specific test challenges due to their parallel backplane bus architecture and analog signal conditioning circuitry. DriveKNMS applies the following verification protocol to all Series 6 inventory prior to dispatch:

Backplane bus continuity test: All edge connector pins verified against GE Fanuc IC600 bus specification for open circuits and shorts.
Analog channel calibration check: For AI/AO modules including IC600BF843L, each channel is exercised across the full input range (0–20 mA, 0–10 V) and output values compared against factory tolerance (±0.1% full scale).
Firmware revision verification: EPROM/EEPROM contents read and compared against known-good reference images for the specific suffix variant.
Thermal soak test: Modules operated at rated temperature for a minimum of 4 hours to screen for latent failures in aged electrolytic capacitors.
Visual inspection: PCB examined under magnification for corrosion, cold solder joints, damaged traces, and component substitution indicators.
