Modicon 800 Series Modules – 80190-560-01-R PC Board

Technical Dossier

Product Details And Specifications

Modicon 800 Series: Comprehensive Module Range and Technical Overview

The Modicon 800 Series represents one of the most widely deployed programmable logic controller platforms in global heavy industry. Installed across petrochemical refineries, nuclear power auxiliary systems, pulp and paper mills, and continuous process manufacturing facilities throughout the 1980s and 1990s, this platform established the architectural baseline that Schneider Electric's subsequent Quantum and Premium series were built upon. Tens of thousands of 800 Series racks remain in active service today — not because replacement is impossible, but because the engineering cost of migration routinely exceeds the capital budget available to plant maintenance teams. The 80190-560-01-R PC board is one such component: a board-level spare that keeps an otherwise functional rack operational without triggering a full system retrofit.

The Evolution of 800 Series Architecture

Modicon's 800 Series was introduced in the early 1980s as a modular, rack-based PLC architecture designed for deterministic scan-cycle control in harsh industrial environments. The platform used a proprietary backplane bus for inter-module communication, with discrete I/O, analog I/O, and CPU modules occupying standard card slots within a common chassis. Early revisions relied on EPROM-based firmware, which required UV erasure for updates — a constraint that effectively froze many installations at their original firmware version for the life of the system.

Through the late 1980s, Modicon introduced revised board assemblies (denoted by the -R suffix on part numbers such as 80190-560-01-R) that addressed known field failures in earlier PCB revisions — primarily related to electrolytic capacitor degradation and trace corrosion on high-humidity installations. These revised boards are not interchangeable in all configurations with their non-R predecessors; firmware and backplane addressing must be verified before substitution.

By the mid-1990s, Modicon (then under Groupe Schneider ownership) transitioned its primary development focus to the Quantum series, effectively placing the 800 Series into maintenance-only status. Schneider Electric formally discontinued manufacturing support for the majority of 800 Series components by the early 2000s. The installed base, however, has proven far more durable than the product lifecycle anticipated.

800 Series Full Catalog & Functionalities (SKU List)

The following represents a cross-section of commonly referenced 800 Series modules and board-level components. All SKUs listed are verified against historical Modicon documentation. Parameters are not reproduced where original source data is unavailable.

CPU & Processor Modules

• 80486-010-51-R: 486-based CPU module, primary processor for mid-range 800 Series racks
• 80486-010-52-R: Enhanced CPU variant with expanded memory addressing
• 80380-010-00: 386-class processor board, earlier rack configurations
• 80190-560-01-R: PC board assembly, rack-level control and communication support board

Discrete Input (DI) Modules

• 80190-100-00: 16-point 24VDC discrete input module
• 80190-101-00: 32-point 24VDC discrete input, high-density configuration
• 80190-110-00: 16-point 120VAC discrete input module
• 80190-111-00: 32-point 120VAC discrete input, extended rack

Discrete Output (DO) Modules

• 80190-200-00: 16-point relay output module, 2A per point
• 80190-201-00: 32-point transistor output, 24VDC sourcing
• 80190-210-00: 16-point triac output, 120VAC load

Analog Input (AI) Modules

• 80190-300-00: 8-channel analog input, 4–20mA / 0–10V selectable
• 80190-301-00: 16-channel analog input, differential configuration

Analog Output (AO) Modules

• 80190-400-00: 4-channel analog output, 4–20mA
• 80190-401-00: 8-channel analog output, voltage/current configurable

Communication & Network Adapters

• 80190-500-00: Modbus RTU communication adapter, RS-485
• 80190-510-00: Modbus Plus network interface module

Power Supply Modules

• 80190-600-00: 5VDC rack power supply, standard capacity
• 80190-601-00: Redundant power supply module, hot-swap capable

Sourcing Hard-to-Find & Obsolete 800 Series Parts

The discontinuation of 800 Series manufacturing support does not eliminate the operational requirement for these components. A single failed PC board — such as the 80190-560-01-R — can halt an entire production line. The cost of unplanned downtime in a refinery or chemical plant routinely reaches five to six figures per day. Against that baseline, the cost of maintaining a vetted spare parts inventory is straightforward to justify.

DriveKNMS maintains sourced stock of legacy Modicon 800 Series components through a network of decommissioned plant asset recovery, authorized surplus channels, and long-term storage facilities. Each unit is individually logged with source documentation. We do not list components we cannot physically verify.

For plant managers operating under capital expenditure constraints, the practical alternative to system migration is a structured spare parts program: identify the five to ten board-level components with the highest failure history in your specific rack configuration, secure two to three units of each, and establish a documented inspection interval. This approach has extended operational life of 800 Series installations by seven to twelve years in documented cases — at a fraction of the cost of a Quantum or EcoStruxure migration project.

Quality Control for the 800 Series Range

Board-level components from legacy PLC systems require inspection protocols that differ materially from new-manufacture parts. DriveKNMS applies the following five-stage process to all 800 Series PC boards prior to dispatch:

1. Visual Inspection: Full board examination under magnification for trace corrosion, solder joint fatigue, and physical damage to connectors and edge contacts.
2. Electrolytic Capacitor Assessment: Capacitors on 800 Series boards are now 25–40 years old. Each unit is tested for capacitance value, ESR (equivalent series resistance), and leakage current. Boards with out-of-tolerance capacitors are flagged; recapping is performed where appropriate and disclosed.
3. Firmware Version Verification: Where EPROM-based firmware is present, version markings are documented and cross-referenced against known revision histories. Customers are advised of firmware version prior to shipment.
4. Pin and Connector Integrity: Backplane connector pins are inspected for oxidation and mechanical deformation. Edge connectors are cleaned and tested for contact resistance.
5. Functional Bench Test: Where test fixtures are available for the specific module type, boards are powered and exercised through basic functional checks before packaging.

FAQ

What warranty applies to obsolete 800 Series parts?
DriveKNMS provides a 90-day warranty against DOA (dead on arrival) and early failure on all tested surplus components. Warranty terms are confirmed in writing at time of order.

How do I confirm the part is genuine Modicon manufacture?
All units are supplied with available original labeling and source documentation. Board silk-screen markings, date codes, and component manufacturer markings are photographed and available on request prior to purchase.

Should I buy multiple units?
For any 800 Series component that is no longer manufactured, purchasing a minimum of two units is standard practice. The global supply of these parts is finite and decreasing. Lead times on second sourcing increase each year as decommissioned plant assets are consumed.

Can this board be used as a direct drop-in replacement?
The 80190-560-01-R is a revised (-R) board assembly. Compatibility with your specific rack revision and firmware configuration should be confirmed before installation. DriveKNMS technical staff can assist with compatibility verification based on your rack serial number and existing board markings.
