SEW-EURODRIVE MOVIDRIVE MDX60B/61B Inverters: MDX60A0055-5A3-4-00

Technical Dossier

Product Details And Specifications

SEW-EURODRIVE MOVIDRIVE MDX60B/61B Series: Comprehensive Module Range and Technical Overview

The SEW-EURODRIVE MOVIDRIVE MDX60B and MDX61B series represents one of the most widely deployed variable-speed drive platforms in global heavy industry. Installed across petrochemical refineries, nuclear auxiliary systems, cement plants, steel mills, and offshore platforms, the MDX60B/61B line covers output power from 0.55 kW to 315 kW in 400 V and 500 V supply variants. Its modular architecture — separating the power section (MDX60B) from the application controller (MDX61B) — allows independent replacement of drive electronics without disturbing the mechanical installation, a critical factor in continuous-process environments where unplanned downtime carries direct production cost.

The Evolution of MOVIDRIVE MDX60B/61B Architecture

SEW-EURODRIVE introduced the MOVIDRIVE B generation as the successor to the MOVIDRIVE A (MDV60A/61A) platform, with production of the B-series commencing in the early 2000s. The architectural shift from A to B introduced a unified parameter structure (MOVITOOLS MotionStudio), improved EMC filtering, and a standardized fieldbus option card slot (SBus, PROFIBUS, DeviceNet, CANopen, EtherNet/IP, PROFINET) that replaced the fixed-protocol variants of the A-series.

The MDX60B designates the basic inverter unit (without integrated application controller), while MDX61B adds the onboard IEC 61131-3 application controller with 512 KB user program memory. Both share identical power hardware, enabling field upgrades from MDX60B to MDX61B by controller board replacement only. The series entered its mature/end-of-active-production phase, with SEW-EURODRIVE transitioning new designs toward the MOVI-DRIVE modular (MDX91A) platform. However, the MDX60B/61B installed base remains extensive, and SEW-EURODRIVE continues to supply spare parts and repair services. Third-party distributors such as DriveKNMS maintain independent stock of both current and discontinued variants to support long-term maintenance contracts.

MOVIDRIVE MDX60B/61B Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked models within the MDX60B and MDX61B series. Units are classified by function and power rating.

Basic Inverter Units — MDX60B (No Application Controller)

• MDX60A0055-5A3-4-00: 0.55 kW, 400 V 3-phase, IP20, basic inverter without fieldbus option
• MDX60B0015-5A3-4-00: 1.5 kW, 400 V 3-phase, IP20, standard basic inverter unit
• MDX60B0022-5A3-4-00: 2.2 kW, 400 V 3-phase, IP20, basic inverter, no integrated controller
• MDX60B0037-5A3-4-00: 3.7 kW, 400 V 3-phase, IP20, basic inverter unit
• MDX60B0055-5A3-4-00: 5.5 kW, 400 V 3-phase, IP20, basic inverter unit
• MDX60B0075-5A3-4-00: 7.5 kW, 400 V 3-phase, IP20, basic inverter unit
• MDX60B0110-5A3-4-00: 11 kW, 400 V 3-phase, IP20, basic inverter unit
• MDX60B0150-5A3-4-00: 15 kW, 400 V 3-phase, IP20, basic inverter unit

Application Controller Units — MDX61B (Integrated IEC 61131-3 Controller)

• MDX61B0015-5A3-4-0T: 1.5 kW, 400 V, MDX61B with integrated application controller, SBus
• MDX61B0022-5A3-4-0T: 2.2 kW, 400 V, MDX61B with application controller
• MDX61B0037-5A3-4-0T: 3.7 kW, 400 V, MDX61B with application controller
• MDX61B0055-5A3-4-0T: 5.5 kW, 400 V, MDX61B with application controller
• MDX61B0075-5A3-4-0T: 7.5 kW, 400 V, MDX61B with application controller
• MDX61B0110-5A3-4-0T: 11 kW, 400 V, MDX61B with application controller
• MDX61B0150-5A3-4-0T: 15 kW, 400 V, MDX61B with application controller
• MDX61B0220-5A3-4-0T: 22 kW, 400 V, MDX61B with application controller
• MDX61B0300-5A3-4-0T: 30 kW, 400 V, MDX61B with application controller

Option Cards & Fieldbus Adapters (Compatible with MDX60B/61B)

• DFP21B: PROFIBUS DP option card for MDX60B/61B fieldbus slot
• DFE24B: EtherNet/IP and Modbus TCP option card
• DFE33B: PROFINET IO option card
• DFC21B: CANopen option card
• DEH21B: Encoder evaluation option card (HTL/TTL)

Sourcing Hard-to-Find & Obsolete MOVIDRIVE MDX60B/61B Parts

As the MDX60B/61B series transitions from active production to long-term support status, procurement of specific power ratings, voltage variants, and option card combinations becomes progressively more difficult through standard distribution channels. SEW-EURODRIVE's own spare parts program covers the most common variants, but low-volume or regionally discontinued SKUs — particularly sub-1.5 kW units such as the MDX60A0055-5A3-4-00 and early A-suffix production runs — are frequently unavailable through OEM channels with lead times of 8–20 weeks.

DriveKNMS maintains an independent inventory of MDX60B/61B units sourced from decommissioned plant equipment, surplus OEM stock, and authorized repair channels. All units are tested to functional specification before dispatch. For facilities operating under long-term maintenance agreements or requiring guaranteed spare availability for 5–10 year horizons, DriveKNMS offers consignment stocking arrangements for critical MDX60B/61B variants.

Quality Control for the MOVIDRIVE MDX60B/61B Range

The MDX60B/61B power section integrates IGBT modules, DC bus capacitor banks, gate driver boards, and a control PCB communicating over an internal backplane. Each of these subsystems requires independent verification before a unit is classified as serviceable.
