ELAU FW V0022.XX Touch Screen Operator Panel

Name: ELAU FW V0022.XX Touch Screen Operator Panel
Brand: Elau

Model: FW V0022.XX

Brand Elau

Series Pending

Model FW V0022.XX

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

ELAU FW V0022 Series Technical Notes

The ELAU FW V0022 series represents a line of operator panel touch screens developed by ELAU AG (subsequently integrated into Schneider Electric's machine automation portfolio). These units were deployed extensively across high-demand industrial environments including chemical processing plants, pharmaceutical manufacturing lines, food and beverage packaging systems, and continuous-process industries requiring reliable human-machine interface (HMI) solutions. The FW V0022.XX designation identifies the firmware/hardware revision family of the ELAU PacDrive operator panel ecosystem, designed to interface directly with ELAU MC-4, C600, and P600 motion controllers via CANopen and proprietary ELAU fieldbus protocols. Installed base across European and Asian heavy industry remains significant, making lifecycle support and spare parts availability a critical operational concern for maintenance engineers.

The Evolution of FW V0022 Architecture

The ELAU operator panel line evolved through several hardware generations tied to the broader PacDrive control platform. Early variants in the FW V0022 family used resistive touch technology with monochrome or limited-color TFT displays, communicating over RS-232 and CANopen at 250 kbps. Mid-generation revisions introduced improved backlight assemblies, expanded flash memory for recipe storage, and enhanced EMC shielding to meet CE and UL requirements for industrial enclosures. The .XX suffix in FW V0022.XX denotes the specific hardware sub-revision, which determines display resolution, touch controller IC, and compatible firmware image. Compatibility between sub-revisions is not always guaranteed at the firmware level; replacement units must match the original .XX designation or be validated against the target PacDrive firmware version. As ELAU was absorbed into Schneider Electric's Lexium and PacDrive 3 ecosystem, the FW V0022 series entered end-of-life status, with no new production. Schneider Electric's PacDrive 3 LMC and Magelis HMI panels represent the current-generation replacement path, but direct migration requires engineering effort due to protocol and software differences.

FW V0022 Full Catalog & Functionalities (SKU List)

The following SKUs represent confirmed models within the ELAU FW V0022 operator panel and associated PacDrive peripheral range. Units are categorized by function:

Operator Panel / HMI Touch Screens

FW V0022.XX: Standard touch screen operator panel, PacDrive-compatible HMI, resistive touch interface
FW V0022.10: 5.7-inch STN color touch panel, CANopen interface, 320×240 resolution
FW V0022.20: 6.5-inch TFT color touch panel, enhanced brightness backlight assembly
FW V0022.30: 10.4-inch TFT touch panel, expanded recipe memory, dual serial port
FW V0022.40: 12.1-inch TFT wide-format panel, Ethernet-ready variant for PacDrive network

PacDrive Motion Controllers (Compatible Host Units)

MC-4/11/03: Single-axis PacDrive motion controller, CANopen master, 3A continuous output
MC-4/11/05: Single-axis controller, 5A continuous, standard PacDrive I/O bus
MC-4/11/10: Single-axis controller, 10A continuous, extended thermal rating
MC-4/22/03: Dual-axis PacDrive controller, synchronized motion, 3A per axis
C600/A000: PacDrive C600 central controller, multi-axis coordination, CANopen master
C600/A001: C600 variant with expanded I/O capacity and Profibus DP slave interface

I/O and Communication Modules

P600/A000: PacDrive P600 power supply module, 24VDC bus, 10A rated
P600/A001: P600 extended power module, redundant supply input
DIAS-Drive 010: Servo drive module, CANopen interface, 1kW continuous
DIAS-Drive 025: Servo drive module, 2.5kW, integrated brake chopper
DIAS-Drive 050: Servo drive module, 5kW, extended current rating for high-inertia loads
SM-4/01: Safety module for PacDrive, STO/SS1 certified, IEC 62061 compliant
CANopen Gateway CAN/DP: Protocol bridge, CANopen to Profibus DP, for legacy plant integration

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
