Emerson Ovation KJ2101X1-BA 12P2690X012 Modules

Technical Dossier

Product Details And Specifications

Emerson Ovation Series Technical Notes

Ovation Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked modules within the Emerson Ovation KJ-series platform. Each entry is classified by functional category.

I/O Interface & Processor Modules

• KJ2101X1-BA 12P2690X012: Ovation I/O interface module; bridges field I/O signals to controller backplane bus.
• KJ2003X1-BA1: Analog input module; 16-channel, 4–20 mA / 1–5 V DC, with HART pass-through capability.
• KJ2005X1-MQ1: Analog output module; 8-channel isolated, 4–20 mA, suitable for valve positioner control loops.
• KJ3001X1-BG1: Digital input module; 32-channel 24 V DC, optically isolated, for discrete field device status monitoring.
• KJ3002X1-BA1: Digital output module; 16-channel relay output, rated 2 A per channel, for solenoid and motor starter control.
• KJ3101X1-BA1: Digital input module; 16-channel 120 V AC, for high-voltage field signal acquisition in switchgear panels.
• KJ3203X1-BA1: Thermocouple input module; 16-channel, supports J, K, T, E, R, S, B type thermocouples with cold-junction compensation.
• KJ3204X1-BA1: RTD input module; 8-channel, supports PT100/PT1000, 2-wire and 3-wire configurations.
• KJ3221X1-BA1: Pulse input module; 8-channel, for turbine speed, flow meter, and encoder signal acquisition.
• KJ3222X1-BA1: Frequency/pulse output module; 4-channel, for variable-speed drive reference signal generation.

Controller & CPU Modules

• KJ4001X1-CA1: Ovation controller module; primary CPU for I/O subsystem management, supports redundant configuration.
• KJ4001X1-CB1: Ovation controller module; updated firmware revision of CA1, improved scan cycle performance.
• KJ4001X1-NA1: Ovation controller module; North American market variant with UL/CSA certification markings.
• KJ4010X1-BG1: Ovation network interface controller; manages Ovation Plant Bus communication for distributed I/O drops.
• KJ4110X1-CE1: Ovation redundant controller module; hot-standby failover, bumpless transfer on primary controller fault.

Power Supply & Backplane Modules

• KJ1501X1-BC1: Ovation I/O power supply module; 24 V DC regulated output, 10 A capacity, for I/O drop power distribution.
• 5X00119G01: Ovation backplane assembly; 8-slot I/O drop chassis, compatible with KJ2xxx and KJ3xxx series modules.
• 1C31234G01: Ovation communication adapter; legacy WDPF-to-Ovation network bridge for mixed-generation installations.

Sourcing Hard-to-Find & Obsolete Ovation Parts

A significant portion of the global Ovation installed base operates on hardware that Emerson has classified as End-of-Active-Support or End-of-Life. Power generation facilities with 20–40 year operational horizons cannot execute full DCS migrations on short notice; the capital expenditure, engineering validation, and regulatory approval cycles for nuclear and refinery applications routinely span 5–10 years. During this interval, facilities require a reliable supply of original hardware to maintain system integrity.

Quality Control for the Ovation Range

Ovation KJ-series modules present specific test challenges due to their integrated backplane communication logic and multi-layer PCB construction. DriveKNMS applies a structured verification protocol to all Ovation modules prior to dispatch:
