Fuji Electric NP1L Modules - NP1L-TMB

Technical Dossier

Product Details And Specifications

Fuji Electric NP1L Series Technical Notes

The Evolution of NP1L Architecture

The NP1L series was introduced as part of Fuji Electric's MICREX-SX platform family, succeeding the earlier MICREX-F and NP1S generations. The original NP1L architecture used a parallel backplane bus with fixed-slot addressing, which constrained maximum I/O density but delivered highly predictable interrupt latency — a critical parameter in motion-adjacent control loops. Subsequent hardware revisions introduced high-speed serial backplane variants, expanding addressable I/O point counts and enabling distributed rack configurations over fiber-optic extension cables.

Compatibility across NP1L hardware generations is governed by CPU firmware version and rack bus type. Early NP1L-CPU modules (pre-2005 firmware) are not compatible with high-speed serial I/O modules without a rack bus adapter. Facilities operating mixed-generation racks must verify bus type (parallel vs. serial) before substituting modules. As the NP1L platform has entered its mature/end-of-active-production lifecycle, Fuji Electric has transitioned new project recommendations to the MICREX-SX SPH series; however, NP1L hardware remains in active service at thousands of installed sites globally, sustaining strong demand for spare and replacement modules.

NP1L Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked NP1L series modules. Each entry reflects the module's primary functional classification and application role within an NP1L rack system.

CPU & Controller Modules

• NP1L-CPU1: Standard CPU module, 8K step program memory, parallel bus
• NP1L-CPU2: Enhanced CPU, 16K step memory, extended instruction set
• NP1L-CPU3: High-speed CPU, 32K step, serial backplane support
• NP1L-CPU4: Advanced CPU with built-in Ethernet port, 64K step

Digital Input (DI) Modules

• NP1L-DI16: 16-point 24VDC digital input, sink/source selectable
• NP1L-DI32: 32-point 24VDC digital input, high-density rack mount
• NP1L-DI16A: 16-point 100–120VAC digital input module

Digital Output (DO) Modules

• NP1L-DO16T: 16-point transistor output, 24VDC, 0.5A per point
• NP1L-DO16R: 16-point relay output, 2A per point, 250VAC/30VDC
• NP1L-DO32T: 32-point transistor output, high-density configuration

Analog Input/Output (AI/AO) Modules

• NP1L-AI4: 4-channel analog input, 4–20mA / 0–10V selectable, 12-bit
• NP1L-AI8: 8-channel analog input, 14-bit resolution, differential input
• NP1L-AO4: 4-channel analog output, 4–20mA / 0–10V, 12-bit DAC

Communication & Network Modules

• NP1L-RS1: RS-232C/RS-485 serial communication module, Modbus RTU support
• NP1L-ET1: Ethernet TCP/IP communication adapter, 10/100BASE-T
• NP1L-PB1: PROFIBUS-DP slave communication module
• NP1L-DN1: DeviceNet slave adapter for distributed I/O integration

Operator Interface & Specialty Modules

• NP1L-TMB: Operator interface terminal base module, panel-mount HMI connection
• NP1L-PS1: 24VDC rack power supply module, 5A output
• NP1L-PS2: Redundant power supply module, hot-swap capable
• NP1L-EX1: I/O rack expansion module, parallel bus extension

Sourcing Hard-to-Find & Obsolete NP1L Parts

As the NP1L series has transitioned from active production to lifecycle support status, procurement of specific modules — particularly early-generation CPU units, analog I/O cards, and communication adapters — has become increasingly constrained through standard distribution channels. DriveKNMS maintains a dedicated inventory of NP1L spare and replacement modules sourced through authorized secondary-market channels, decommissioned plant asset recovery, and direct manufacturer surplus acquisition.

Quality Control for the NP1L Range

NP1L modules present specific test challenges due to their backplane bus architecture and mixed parallel/serial communication variants. DriveKNMS applies a structured multi-stage verification protocol to all NP1L inventory prior to dispatch.

Each module undergoes: visual inspection for PCB damage, capacitor condition, and connector pin integrity; powered functional test using a dedicated NP1L test rack with known-good CPU and power supply reference modules; backplane bus communication verification confirming correct slot addressing and data transfer integrity; for I/O modules — channel-by-channel signal verification at rated voltage and current levels; for communication modules — protocol handshake testing against a reference master device (Modbus RTU, PROFIBUS-DP, or Ethernet as applicable); burn-in cycle at operating temperature to screen for latent component failures; and final documentation of test results retained on file for each serialized unit.

Modules that do not pass all stages are quarantined, clearly marked as non-functional, and are not offered for sale under any condition.
