GE 336A4940DNP5 Series Modules – 336A4940DNP516TX 16-Port Ethernet Network Switch

Technical Dossier

Product Details And Specifications

GE 336A4940DNP5 Series Technical Notes

The GE (General Electric) 336A4940DNP5 series represents a line of managed industrial Ethernet switches engineered for deployment in process-critical environments including chemical plants, oil refineries, nuclear power stations, and heavy manufacturing facilities. These switches are designed to operate within GE's broader DCS and SCADA infrastructure, providing deterministic, high-availability network communication between PLCs, HMIs, historian servers, and field devices. Their ruggedized construction, wide operating temperature tolerance, and support for redundant ring topologies (RSTP/MRP) make them a standard backbone component in brownfield industrial networks worldwide. The series has been widely installed across North American and European process industries since the mid-2000s and remains in active service at thousands of sites globally.

336A4940DNP5 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified models within the GE 336A4940DNP5 industrial Ethernet switch series, organized by port configuration and interface type:

Copper (TX) Port Variants

336A4940DNP508TX: 8-port 10/100 Mbps managed industrial Ethernet switch, DIN-rail mount, RSTP support.

336A4940DNP516TX: 16-port 10/100 Mbps managed industrial Ethernet switch, rack/panel mount, VLAN & SNMP v3.

336A4940DNP524TX: 24-port 10/100 Mbps managed switch, extended temperature range, suitable for outdoor enclosures.

Fiber (FX) Uplink Variants

336A4940DNP508FX: 8-port switch with 2× 100Base-FX multimode fiber uplinks, for inter-cabinet backbone runs.

336A4940DNP516FX: 16-port switch with 2× 100Base-FX fiber uplinks, ring topology redundancy (MRP).

336A4940DNP524FX: 24-port switch with dual fiber uplinks, IGMP snooping for multicast control traffic.

Gigabit Uplink Variants

336A4940DNP508GX: 8-port 10/100 Mbps + 2× Gigabit SFP uplink slots, aggregation layer deployment.

336A4940DNP516GX: 16-port 10/100 Mbps + 2× Gigabit SFP uplinks, high-bandwidth historian/SCADA server connectivity.

336A4940DNP524GX: 24-port 10/100 Mbps + 2× Gigabit SFP, top-of-rack aggregation for large control room networks.

PoE (Power over Ethernet) Variants

336A4940DNP508POE: 8-port PoE managed switch, powers IP cameras and wireless APs in field enclosures.

336A4940DNP516POE: 16-port PoE switch, IEEE 802.3af/at, 150W total PoE budget.

Redundant Power Supply Variants

336A4940DNP516TXRPS: 16-port TX switch with integrated redundant power supply module slot, SIL-2 compatible installations.

336A4940DNP524TXRPS: 24-port TX switch with dual PSU bays, hot-swap capable, for continuous process environments.

Extended Temperature Variants

336A4940DNP508TXET: 8-port switch, operating range −40°C to +75°C, conformal coated PCB, for harsh environment cabinets.

336A4940DNP516TXET: 16-port switch, extended temperature, IP30 rated enclosure, suitable for offshore and mining applications.

336A4940DNP524TXET: 24-port switch, extended temperature, full managed feature set, ATEX zone 2 compatible configurations available.
