GE DS200 Modules: DS200SHVMG1ACC

Name: GE DS200 Modules: DS200SHVMG1ACC
Brand: General Electric

Model: DS200SHVMG1ACC

Brand General Electric

Series DS200

Model DS200SHVMG1ACC

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

GE DS200 Series Technical Notes

The GE DS200 series represents one of the most widely deployed control module families in global heavy industry. Originally developed as part of GE's Mark V, Mark VI, and EX2100 turbine control platforms, DS200-series boards are installed across gas turbine power plants, combined-cycle facilities, petrochemical refineries, offshore oil & gas platforms, and nuclear auxiliary systems worldwide. Their ruggedized backplane architecture, deterministic I/O scanning, and compatibility with GE's Speedtronic control philosophy have made them a long-term standard in critical process environments where replacement cycles span 15–25 years.

The DS200SHVMG1ACC is a Voltage M-Frame Interface Board within this series, responsible for conditioning and routing voltage measurement signals within the Mark V/VI control rack. It interfaces directly with the SHVM backplane and is a non-redundant single-board assembly requiring exact revision matching for drop-in replacement.

The Evolution of DS200 Architecture

The DS200 board family was introduced alongside GE's Mark V Speedtronic platform in the early 1990s. Mark V established a triple-redundant (TMR) control architecture using three independent control paths (R, S, T) with a dedicated voter module. DS200-series boards were designed to slot into standardized panel frames — the P, Q, R, and S frame configurations — each with defined backplane pinouts and bus protocols.

With the transition to Mark VI (circa 2000–2005), GE introduced the MKVI I/O pack architecture, which retained backward-compatible signal conditioning boards but migrated the communication layer from parallel backplane to Ethernet-based IONet. Many DS200 boards remained in service within hybrid Mark V/VI installations. The EX2100 excitation control system introduced a further subset of DS200-compatible interface boards for generator excitation and AVR functions.

By 2010, GE formally classified the majority of DS200 Mark V hardware as mature/end-of-life, with Mark VIe (IS200 series) designated as the forward migration path. However, installed base density ensures continued demand for DS200 spares through at least 2035 in facilities that have not undergone full control system upgrades.

Compatibility note: DS200 boards are not interchangeable with IS200-series (Mark VIe) boards. Revision suffixes (e.g., G1A, G1B, G2A) denote hardware revisions with differing component populations; always verify the full part number including revision code before substitution.

DS200 Full Catalog & Functionalities (SKU List)

Controllers & Processor Boards

DS200TCQAG1BHF: Mark V TMR controller quad-core processor, R/S/T path arbitration board
DS200TCDAG1AHF: Turbine control diagnostic processor, fault logging and watchdog interface
DS200TCEAG1BHF: Mark V TMR executive controller, primary scan cycle management board

Analog & Voltage Interface Boards

DS200SHVMG1ACC: Voltage M-Frame interface board, signal conditioning for voltage measurement inputs
DS200SLCCG3AHF: Analog I/O terminal board, 16-channel current/voltage input conditioning
DS200SDCCG1AHF: DC analog signal conditioning board, 4–20 mA loop interface
DS200SHCAG1BHF: High-current analog interface board, generator current signal scaling
DS200EXPAG1ADF: Excitation power amplifier interface, EX2100 AVR signal routing board

Digital I/O Boards

DS200DSPCH1ADA: Digital signal processor I/O board, high-speed discrete input capture
DS200DIBBG1AHF: 24 VDC digital input board, 32-channel isolated discrete input module
DS200DOBEG1ADF: Digital output board, 16-channel relay-driven discrete output module
DS200DTBCG1AAA: Digital terminal board, field wiring interface for discrete I/O marshalling

Communication & Network Adapters

DS200CPCAG1AHF: Communication processor board, Mark V to DCS gateway, Modbus/UCSC interface
DS200LDCCH1AHF: Local display controller board, HMI panel interface for Mark V operator station
DS200TCCAG1BHF: Turbine control communication adapter, IONet/serial bridge for hybrid Mark V/VI systems

Power Supply Boards

DS200PCCAG1AHF: Panel power conditioning board, 125 VDC to logic-level DC/DC conversion
DS200PSDAG1AHF: Power supply distribution board, multi-rail output for Mark V panel frame

Sourcing Hard-to-Find & Obsolete DS200 Parts

For end-of-life planning, DriveKNMS can provide multi-year supply agreements covering critical DS200 spares to support facilities operating Mark V systems beyond OEM support windows.

Quality Control for the DS200 Range

DS200-series boards present specific test challenges due to their backplane-dependent signal routing and TMR voting logic. DriveKNMS applies the following test protocols:
