GE DS200 Modules: DS200TBQCC1AAA PC Board

Technical Dossier

Product Details And Specifications

GE DS200 Series Technical Notes

The GE DS200 series is a family of printed circuit boards and I/O modules developed for the SPEEDTRONIC Mark V and Mark VI turbine control systems. These systems are deployed across gas turbines, steam turbines, and combined-cycle power plants in chemical processing facilities, nuclear power stations, oil refineries, and LNG terminals worldwide. The DS200 platform represents GE's primary control hardware for heavy-duty Frame 6, Frame 7, and Frame 9 gas turbines, with installed base spanning multiple decades across North America, the Middle East, and Asia-Pacific industrial infrastructure.

The DS200TBQCC1AAA is a PC Board (termination and signal conditioning board) within this series, designed to interface field wiring with the core control processors of the Mark V/VI architecture. Its role is to provide reliable signal routing between field instrumentation and the turbine control logic.

The Evolution of DS200 Architecture

The DS200 series originated as the hardware backbone of the SPEEDTRONIC Mark V system, introduced in the early 1990s as GE's successor to the Mark IV platform. Mark V introduced triple-redundant control (TCCA, TCCB, TCCC processors) with dedicated I/O boards for each control channel. The DS200 boards were engineered to operate within this redundant architecture, where each board communicates over the IONet serial bus.

With the transition to Mark VI (introduced circa 2000), GE retained backward-compatible DS200 form factors while migrating the communication backbone from IONet to Ethernet-based IONET and later to the Mark VIe platform using Ethernet I/O packs. Many DS200 boards remain in service in Mark V installations that have not been upgraded, creating sustained demand for spare parts and lifecycle support. The Mark V system reached end-of-production status, placing the entire DS200 catalog in the mature-to-obsolete lifecycle phase. Long-term maintenance support is now the primary use case for DS200 procurement.

DS200 Full Catalog & Functionalities (SKU List)

Controllers & Processors

• DS200TCQAG1BHF: SPEEDTRONIC Mark V TCQA turbine control processor board, primary control channel.
• DS200DSPCH1ADA: Digital signal processor board for turbine control computation and sequencing logic.
• DS200PCCAG1ACB: Process control card, interfaces control logic with I/O subsystems in Mark V architecture.
• DS200IMCPG1ACB: Intelligent motor control processor board for auxiliary drive management.

Analog I/O Modules

• DS200TBQCC1AAA: PC Board — termination and signal conditioning for analog field wiring interfaces.
• DS200TCPSG1AKE: Analog input termination board for thermocouple and RTD sensor signal processing.
• DS200AAHAH1AKD: Analog input board, 16-channel, for 4–20 mA process variable acquisition.
• DS200PTBAG1ACA: Pulse/frequency input termination board for speed and flow measurement signals.

Digital I/O Modules

• DS200CTBAG1ADD: Contact input termination board for discrete field device status monitoring.
• DS200TBCAG1AAA: Terminal board for contact input/output wiring in Mark V control panels.
• DS200TBQAG1ACC: Termination board for analog and digital mixed-signal field wiring.
• DS200SLCCG3AHH: Sequence logic control card for discrete output sequencing and interlock logic.

Communication & Interface Boards

• DS200SDCIG2AHC: Serial data communication interface board for IONet bus connectivity.
• DS200DMCBG1ARC: Data management and communication board for HMI and historian interface.
• DS200SHCAG1ABA: Serial host communication adapter for operator interface and SCADA connectivity.

Power Supply & Backplane

• DS200DCFBG1BEC: DC power filter board for noise suppression on control power distribution rails.
• DS200VPBLG1AEC: Voltage protection and backplane logic board for panel power management.

Quality Control for the DS200 Range

DS200 boards present specific testing challenges due to their multi-layer PCB construction, surface-mount component density, and dependence on proprietary GE bus protocols (IONet). DriveKNMS applies the following test procedures to all DS200 inventory:
