The Evolution of Series Six Architecture

The GE Series Six platform was introduced in the early 1980s as a successor to the Series One and Series Three controllers, targeting mid-to-large scale discrete and process control applications. The IC600 designation covers the full hardware ecosystem: CPUs, I/O modules, memory cartridges, power supplies, communication adapters, and programming interfaces.

Early Generation (IC600 Core Architecture): The original Series Six used a parallel backplane bus with proprietary GE Fanuc I/O protocol. CPU modules such as the IC600CP502 and IC600CP503 supported ladder logic execution with fixed scan cycles. Memory was cartridge-based (EPROM/EEPROM), requiring physical module swaps for program updates — a design reflected in modules like the IC600LX624 and IC600LX624L.

Mid-Generation Expansion: GE Fanuc expanded the I/O catalog significantly through the late 1980s, adding analog input/output modules, high-speed counter interfaces, and ASCII communication modules. The IC600FP series introduced enhanced faceplate and programming terminal compatibility.

Compatibility Consideration: Series Six modules are not cross-compatible with Series 90-30 or Series 90-70 hardware. Rack, backplane, and power supply specifications are platform-specific. Procurement teams must verify the exact IC600 part number and revision level before ordering to avoid installation incompatibilities.

GE Series Six IC600 Full Catalog & Functionalities (SKU List)

The following represents a structured reference index of commonly sourced IC600 series modules, organized by functional category. All models listed are genuine GE Fanuc Series Six components.

CPU & Controller Modules

• IC600CP502: Series Six CPU, 2K word user memory, basic ladder logic execution
• IC600CP503: Series Six CPU, 4K word user memory, enhanced instruction set support
• IC600CP530: High-performance CPU module, extended memory addressing, process control optimized
• IC600CP540: Advanced CPU with floating-point math capability, analog loop control support

Memory Modules

• IC600LX624: EEPROM memory cartridge, program storage for Series Six CPU modules
• IC600LX624L: Extended-capacity EEPROM memory module, compatible with IC600CP530/540 CPUs
• IC600FP608K: Faceplate/programming interface memory module, Series Six programmer compatibility
• IC600LX616: 16K EPROM memory cartridge, early-generation Series Six program storage
• IC600LX632: 32K EEPROM cartridge, expanded user program capacity

Digital Input (DI) Modules

• IC600BF901: 115VAC discrete input module, 8-channel, rack-mount
• IC600BF902: 24VDC discrete input module, 16-channel, high-density I/O
• IC600BF831: TTL-level digital input module, 32-channel, logic interface

Digital Output (DO) Modules

• IC600BF941: 115VAC discrete output module, relay contact type, 8-channel
• IC600BF942: 24VDC transistor output module, 16-channel, fast switching

Analog I/O Modules

• IC600BF810: Analog input module, 4–20mA / 0–10V, 8-channel, 12-bit resolution
• IC600BF820: Analog output module, 4–20mA, 4-channel, process loop control

Communication & Interface Modules

• IC600CM747: Genius Bus Controller, Series Six to Genius I/O network interface
• IC600CM752: ASCII/BASIC communication module, serial port interface, RS-232/RS-422
• IC600YB840: Series Six backplane bus terminator and rack interface module

Sourcing Hard-to-Find & Obsolete IC600 Series Parts

2. Counterfeit Risk: The high unit value of obsolete IC600 modules — particularly CPU and memory cartridges — makes them targets for remarking and counterfeiting. Procurement teams sourcing from unverified distributors risk receiving non-functional or misrepresented units that pass visual inspection but fail under operational load.

Quality Control for the IC600 Series Range

The Series Six platform's backplane bus architecture and cartridge-based memory design require specialized test procedures that differ from modern PLC module validation. Standard bench power-up tests are insufficient for confirming IC600 module serviceability.

DriveKNMS applies the following verification protocol to IC600 series modules:
