GE Fanuc IC698 Series Modules: IC698CRE030 Central Processing Unit

Technical Dossier

Product Details And Specifications

GE Fanuc IC698 Series Technical Notes

The GE Fanuc Series 90-70 (IC698 platform) is a rack-based programmable logic controller system deployed extensively across global heavy industry, including petrochemical refineries, nuclear power generation facilities, offshore platforms, and continuous-process chemical plants. First introduced in the late 1980s and expanded through the 1990s and early 2000s, the IC698 backplane architecture supports high-density I/O configurations and deterministic scan-cycle execution that remain operational in thousands of installed base sites worldwide. The platform's longevity in safety-instrumented and process-critical environments has created sustained demand for spare parts, replacement CPUs, and legacy I/O modules — particularly as OEM support has transitioned to lifecycle management status.

IC698 Full Catalog & Functionalities (SKU List)

CPU / Controller Modules

• IC698CRE030: Series 90-70 CPU, 512KB user memory, Ethernet port, redundancy-capable, 0.1ms/K logic scan
• IC698CPE030: Standard CPU, 512KB user memory, serial port, non-redundant single-rack controller
• IC698CPE040: Enhanced CPU, 2MB user memory, dual Ethernet, supports hot-standby redundancy
• IC698CPE058: High-performance CPU, 8MB user memory, extended instruction set, fault-tolerant rack support
• IC698CPX935: Legacy first-generation CPU, 256KB memory, ISA-bus architecture, no Ethernet native
• IC698CPX928: Entry-level legacy CPU, 128KB user memory, serial comms only, obsolete

Discrete Input (DI) Modules

• IC698MDL230: 16-point 120VAC discrete input, isolated, 10ms filter, DIN rail compatible
• IC698MDL240: 32-point 24VDC discrete input, source/sink configurable, 1ms filter
• IC698MDL241: 32-point 24VDC fast discrete input, 0.1ms filter, interrupt-capable
• IC698MDL632: 16-point 24VDC discrete input, individually isolated, diagnostics per channel

Discrete Output (DO) Modules

• IC698MDL330: 16-point 120VAC discrete output, relay contact, 2A per point
• IC698MDL340: 32-point 24VDC discrete output, transistor sourcing, 0.5A per point
• IC698MDL740: 16-point relay output, Form C contacts, 5A per point, mixed voltage

Analog I/O Modules

• IC698ALG230: 16-channel analog input, 4–20mA / 0–10V selectable, 12-bit resolution
• IC698ALG233: 8-channel analog input, high-resolution 16-bit, thermocouple/RTD compatible
• IC698ALG390: 8-channel analog output, 4–20mA, 12-bit, simultaneous update

Communications & Network Adapters

• IC698ETM001: Ethernet TCP/IP communications module, 10/100 Mbps, SRTP/Modbus TCP support
• IC698CMX016: Genius Bus Controller, supports up to 32 Genius I/O blocks per bus
• IC698PCM300: Programmable coprocessor module, C-language execution, 1MB RAM

Power Supply Modules

• IC698PSA100: 120/240VAC input power supply, 90W output, single-slot, rack-mount
• IC698PSA350: High-capacity power supply, 120/240VAC, 150W, supports expanded I/O racks
