GEMS Sensors 2200 Series Pressure Transmitters — 2200BGA2501A3UA

Technical Dossier

Product Details And Specifications

GEMS Sensors 2200 Series: Comprehensive Module Range and Technical Overview

The GEMS Sensors 2200 Series is a family of industrial-grade pressure transmitters engineered for continuous-duty operation in process-critical environments. Deployed across chemical processing plants, petroleum refineries, nuclear auxiliary systems, and offshore platforms, the 2200 Series occupies a well-established position in global heavy industry instrumentation. Its 4–20 mA analog output architecture, combined with stainless steel wetted parts and configurable pressure ranges, makes it a standard reference in DCS and PLC-based control loops where long-term signal stability is non-negotiable. The series covers gauge, absolute, and sealed gauge measurement modes, with pressure ranges spanning from 0–15 PSI to 0–10,000 PSI depending on variant configuration. Electrical connections, process connections, and output options are encoded directly in the model number, enabling precise cross-referencing against OEM bills of materials.

The Evolution of 2200 Series Architecture

The GEMS Sensors 2200 Series was introduced as a successor to earlier millivolt-output transducer families, transitioning the product line to loop-powered 4–20 mA two-wire transmission — the dominant signal standard in industrial process control from the 1980s onward. Early 2200 variants used thin-film sensing elements bonded to 316L stainless steel diaphragms, providing chemical compatibility with a broad range of process media without requiring isolating diaphragm assemblies.

Mid-generation revisions introduced expanded pressure range options and alternative process connection geometries (1/4 NPT, 1/2 NPT, G1/4) to address European and Asian market requirements. Electrical connector options were extended to include DIN 43650 (Hirschmann), M12 (4-pin), and flying lead configurations, reflected in the suffix coding of the model number.

The 2200 Series is now considered a mature product line. GEMS Sensors (a Fortive / Sensing Brands company) continues to manufacture and support the series, but engineering resources are concentrated on next-generation digital-output and IO-Link variants. For facilities running legacy DCS platforms (Honeywell TDC 3000, Foxboro I/A, ABB Advant) that require 4–20 mA loop compatibility, the 2200 Series remains the preferred like-for-like replacement. Long-term maintenance sourcing is a primary use case for this catalog.

2200 Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly sourced models within the GEMS Sensors 2200 Series. Each model number encodes pressure range, output type, process connection, and electrical termination. Models are grouped by functional category.

Gauge Pressure Transmitters — Standard Range

• 2200BGA0015A3UA: 0–15 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA0030A3UA: 0–30 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA0060A3UA: 0–60 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA0100A3UA: 0–100 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA0200A3UA: 0–200 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA0500A3UA: 0–500 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA1000A3UA: 0–1000 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA2501A3UA: 0–2500 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector — primary listing SKU
• 2200BGA5000A3UA: 0–5000 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BGA10KA3UA: 0–10,000 PSI gauge, 4–20 mA, 1/4 NPT male, DIN connector

Absolute Pressure Transmitters

• 2200BAA0015A3UA: 0–15 PSIA absolute, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BAA0100A3UA: 0–100 PSIA absolute, 4–20 mA, 1/4 NPT male, DIN connector
• 2200BAA0500A3UA: 0–500 PSIA absolute, 4–20 mA, 1/4 NPT male, DIN connector

Alternative Electrical Termination Variants

• 2200BGA0100A3MA: 0–100 PSI gauge, 4–20 mA, 1/4 NPT male, M12 4-pin connector
• 2200BGA0500A3MA: 0–500 PSI gauge, 4–20 mA, 1/4 NPT male, M12 4-pin connector
• 2200BGA1000A3LA: 0–1000 PSI gauge, 4–20 mA, 1/4 NPT male, flying lead (pigtail)
• 2200BGA2501A3LA: 0–2500 PSI gauge, 4–20 mA, 1/4 NPT male, flying lead (pigtail)

Sourcing Hard-to-Find & Obsolete 2200 Series Parts

DriveKNMS maintains a dedicated inventory program for GEMS Sensors 2200 Series transmitters, with particular focus on variants that have been discontinued from standard distribution channels or carry extended lead times through OEM supply chains. For facilities operating under planned maintenance schedules — particularly in refinery turnaround cycles or nuclear outage windows — lead time unpredictability on instrumentation spares is a direct operational risk.

Our sourcing process covers: (1) new-old-stock (NOS) units from verified industrial surplus channels; (2) factory-reconditioned units with full calibration certificates traceable to NIST standards; (3) cross-reference matching for superseded model numbers where GEMS has issued a replacement part number under a revised catalog structure. All units are individually verified against the original model number suffix coding before dispatch. Customers requiring documentation packages (calibration certificates, material certifications, country-of-origin declarations) for regulated industries should specify requirements at the time of inquiry.

Quality Control for the 2200 Series Range

Each 2200 Series unit processed through DriveKNMS undergoes a structured verification protocol prior to shipment. The procedure addresses the primary failure modes documented for this series in long-term field service: diaphragm fatigue at high-cycle pressure applications, connector seal degradation in high-humidity environments, and zero/span drift in units stored beyond manufacturer-recommended shelf life.

Verification steps include: static pressure application at 100% of rated full scale using a calibrated dead-weight tester or digital pressure calibrator (Fluke 700 series or equivalent); 4–20 mA output linearity check at 0%, 25%, 50%, 75%, and 100% of span; insulation resistance test between circuit and housing; visual inspection of wetted surfaces, process connection threads, and electrical connector seating. Units exhibiting output deviation exceeding ±0.5% of full scale are quarantined and not offered for sale.
