Generic MFP Series: Comprehensive Module Range and Technical Overview

The Generic MFP Series represents a standardized line of industrial Human-Machine Interface (HMI) touch screen panels deployed across heavy-process industries including petrochemical refining, power generation, water treatment, and discrete manufacturing. MFP Series units serve as operator interface terminals (OITs) integrated with PLCs, DCS controllers, and SCADA systems. Their resistive and capacitive touch architectures, combined with wide-temperature-range operation (-10°C to +60°C), have made them a reference-grade component in facilities requiring continuous 24/7 uptime. Installed base spans facilities in Southeast Asia, the Middle East, and Eastern Europe, where long product lifecycle and backward-compatible communication protocols are operational requirements.

The Evolution of MFP Series Architecture

The MFP Series originated as a fixed-function operator panel platform designed for serial RS-232/RS-485 communication with early-generation PLCs. Initial variants (MFP3000–MFP4000 range) featured monochrome LCD displays with membrane keypad overlays and limited tag capacity (under 500 tags). The transition to the MFP5000 generation introduced color TFT displays, expanded memory, and Ethernet TCP/IP connectivity alongside legacy serial ports, enabling hybrid integration in brownfield plants where both legacy and modern controllers coexist.

The MFP6000 generation — of which the MFP6610 is a primary representative — standardized on 7-inch to 10-inch widescreen TFT panels, ARM-based processors, USB host ports for data logging, and multi-protocol driver libraries covering Modbus RTU/TCP, Mitsubishi MC Protocol, Siemens S7 MPI/PPI, Allen-Bradley DF1/EtherNet/IP, and Omron FINS. This generation remains the most widely deployed in active facilities. Compatibility with legacy MFP4000/5000 project files requires protocol driver remapping but is achievable via the MFP Designer configuration software.

As the MFP6000 series enters its mature/end-of-active-production phase, procurement teams increasingly rely on authorized distributors and specialist spare parts suppliers for replacement units, repair services, and long-term maintenance inventory (LMI) stocking programs.

MFP Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified models within the Generic MFP Series. Units are categorized by display size, interface type, and primary communication capability.

4-inch Compact Panels

• MFP4300: 4.3" TFT color, RS-232/RS-485, 65K colors, 128MB Flash, basic Modbus RTU driver.
• MFP4310: 4.3" TFT color, RS-232/RS-485 + USB host, expanded tag capacity to 2,000 tags.
• MFP4320: 4.3" TFT color, dual RS-485 ports, supports Mitsubishi FX and Siemens S7-200 PPI natively.

7-inch Standard Panels

• MFP6600: 7" widescreen TFT, RS-232/RS-485/Ethernet, 800×480 resolution, 256MB RAM, ARM Cortex-A8.
• MFP6610: 7" widescreen TFT, RS-232/RS-485/Ethernet + USB host/device, 800×480, enhanced multi-protocol library, SD card slot for recipe/data logging. Primary SKU of this listing.
• MFP6620: 7" widescreen TFT, dual Ethernet ports, supports EtherNet/IP and PROFINET IO simultaneously, IP65 front panel.
• MFP6630: 7" widescreen TFT, stainless steel bezel variant, NEMA 4X rated, designed for food & beverage and pharmaceutical washdown environments.

10-inch Mid-Range Panels

• MFP6100: 10.1" widescreen TFT, 1024×600, RS-232/RS-485/Ethernet, 512MB RAM, supports up to 8,000 tags.
• MFP6110: 10.1" widescreen TFT, dual RS-485 + dual Ethernet, extended temperature -20°C to +70°C, DIN rail mount option.
• MFP6120: 10.1" widescreen TFT, integrated 4G LTE modem, remote monitoring via MQTT/cloud gateway, suitable for distributed field installations.
• MFP6130: 10.1" widescreen TFT, ATEX Zone 2 / IECEx certified variant for hazardous area installations in oil & gas upstream facilities.

12-inch Large Format Panels

• MFP6120L: 12.1" XGA TFT, 1024×768, RS-232/RS-485/Ethernet, 1GB RAM, supports PDF viewer and video playback for operator training integration.
• MFP6150: 15" SXGA TFT, 1280×1024, quad-core ARM, dual Ethernet, designed for central control room operator stations.

Accessories & Expansion Modules

• MFP-COM1: RS-232 to RS-485 isolated converter module, DIN rail mount, compatible with all MFP6000 series panels.
• MFP-PWR24: 24VDC regulated power supply module, 2A output, panel-mount, designed for MFP series power input requirements.
• MFP-USB-WIFI: USB Wi-Fi dongle, 802.11 b/g/n, certified for use with MFP6600/6610/6620 USB host port.

Sourcing Hard-to-Find & Obsolete MFP Series Parts

DriveKNMS maintains a dedicated inventory program for Generic MFP Series components that have transitioned to end-of-active-production (EOAP) status. For facilities operating MFP4000 and early MFP5000 generation panels, original replacement units are no longer available through standard distribution channels. DriveKNMS sources these components through authorized secondary market channels, factory-refurbished stock, and direct manufacturer surplus programs.

Services available for obsolete MFP Series units include: board-level repair and component replacement, firmware restoration to last-known-good versions, display assembly replacement (TFT panel + backlight), and touchscreen digitizer recalibration. For customers requiring long-term maintenance inventory, DriveKNMS offers LMI stocking agreements with guaranteed unit availability for 24–36 month periods, reducing unplanned downtime risk in facilities where panel replacement lead times would otherwise exceed acceptable maintenance windows.
