Hitachi XDC24DMH

Technical Dossier

Product Details And Specifications

Hitachi XD Series Technical Notes

The Hitachi XD Series programmable controller platform has established a significant installed base across global heavy industries, including petrochemical complexes, nuclear power auxiliary systems, steel rolling mills, and oil refinery distributed control architectures. Engineered to meet the deterministic scan-cycle requirements of process-critical environments, XD Series modules operate within Hitachi's proprietary backplane bus architecture, providing high-density I/O expansion, CPU processing, and inter-rack communication for mid-to-large scale automation systems. The series is widely deployed across Asia-Pacific and EMEA industrial facilities, many of which maintain long-term operational commitments to the platform due to deep integration with legacy SCADA and DCS layers.

The Evolution of XD Series Architecture

The Hitachi XD Series emerged as part of Hitachi's mid-range PLC portfolio, succeeding earlier H-series controllers and positioning itself between entry-level micro-PLCs and full-scale DCS platforms. Early XD architecture relied on parallel backplane communication with fixed-slot addressing, which imposed rigid rack configuration rules. Subsequent revisions introduced enhanced bus arbitration, allowing mixed analog and digital module placement without slot-type restrictions. The XDC-prefix modules (including the XDC24DMH) represent the digital mixed I/O category, combining input and output point capacity in a single module footprint — a design choice that reduces rack slot consumption in space-constrained panel installations. As the series matured, Hitachi introduced expanded diagnostic registers accessible via ladder logic, enabling fault isolation at the module level without physical inspection. The XD Series is now in a mature-to-end-of-life phase; Hitachi has transitioned new project recommendations toward the EH-150 and S10V platforms. However, the XD Series remains actively maintained in the field, and replacement modules are essential for sustaining existing installations through their operational lifecycle.

XD Series Full Catalog & Functionalities (SKU List)

The following represents a structured index of verified Hitachi XD Series module part numbers, organized by functional category. Each entry reflects a distinct hardware role within the XD rack system.

Digital I/O Modules

• XDC24DMH: 24-point mixed digital I/O module, high-density combined input/output, DC sink/source compatible
• XDC16DM: 16-point mixed digital I/O module, standard density, DC input/transistor output
• XDC32DI: 32-point digital input module, DC 24V sink type, high-speed scan compatible
• XDC32DO: 32-point digital output module, transistor sink output, short-circuit protected
• XDC16DI: 16-point digital input module, DC 24V, isolated commons per 8-point group
• XDC16DO: 16-point digital output module, relay contact output, 2A per point rating
• XDC08DOR: 8-point relay output module, independent commons, suitable for AC/DC mixed loads
• XDC16DIR: 16-point AC digital input module, 100–240V AC input range, zero-cross detection

Analog I/O Modules

• XDC04AI: 4-channel analog input module, 4–20mA / 0–10V selectable, 12-bit resolution
• XDC08AI: 8-channel analog input module, differential input configuration, 14-bit resolution
• XDC04AO: 4-channel analog output module, 4–20mA / 0–10V, isolated output per channel
• XDC02AO: 2-channel analog output module, voltage/current dual-mode, compact form factor

CPU & Controller Modules

• XDCCPU01: Base CPU module, 8K step program memory, RS-232C loader port, basic instruction set
• XDCCPU02: Enhanced CPU module, 16K step memory, Ethernet option slot, floating-point arithmetic
• XDCCPU03: High-performance CPU, 32K step, dual-port memory, supports structured text programming

Communication & Power Modules

• XDCCOM01: RS-485 / Modbus RTU communication adapter, multi-drop network support, up to 31 nodes
• XDCPWR24: 24VDC rack power supply module, 5A output, over-voltage and short-circuit protection
• XDCPWRAC: AC input power supply module, 100–240V AC input, 5VDC / 24VDC dual rail output
