Model: 400100-100-02
Product Overview
Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.
Datasheet Preview
Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.
Commercial Path
Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.
Technical Dossier
The Bently Nevada 400100 Series Gap Proximitor Sensor is a precision eddy-current proximity transducer system designed for continuous, non-contact measurement of shaft radial vibration, axial position, and differential expansion in rotating machinery. Deployed across global heavy industry — including petrochemical refineries, nuclear power stations, offshore platforms, and LNG processing facilities — the 400100 Series forms a critical sensing layer within Bently Nevada's 3300 and 3500 machinery protection frameworks. Its field-proven architecture supports API 670 compliance requirements and is certified for use in hazardous area classifications including ATEX and IECEx zones. The series operates on the standard Bently Nevada proximitor signal conditioning principle: a probe tip generates a radio-frequency electromagnetic field; as a conductive target approaches, eddy currents are induced, altering the field impedance and producing a DC voltage output proportional to the gap distance. This output is directly compatible with 3300 and 3500 series monitor input cards without signal conversion.
The following SKUs represent the documented 400100 Series product range, classified by configuration (gap range, cable length, connector type, and area classification):
400100-100-02: Standard gap proximitor, 5mm range, 2m integral cable, general purpose
400100-100-05: Standard gap proximitor, 5mm range, 5m integral cable, general purpose
400100-100-09: Standard gap proximitor, 5mm range, 9m integral cable, general purpose
400100-100-02-CN: Standard gap proximitor, 5mm range, 2m cable, CE/ATEX certified
400100-100-05-CN: Standard gap proximitor, 5mm range, 5m cable, CE/ATEX certified
400100-200-02: Extended gap proximitor, 10mm range, 2m integral cable, general purpose
400100-200-05: Extended gap proximitor, 10mm range, 5m integral cable, general purpose
400100-200-09: Extended gap proximitor, 10mm range, 9m integral cable, general purpose
400100-200-02-CN: Extended gap proximitor, 10mm range, 2m cable, CE/ATEX certified
400100-300-02: High-temperature gap proximitor, 5mm range, 2m cable, rated to 120°C
400100-300-05: High-temperature gap proximitor, 5mm range, 5m cable, rated to 120°C
400100-350-02: High-temperature extended gap proximitor, 10mm range, 2m cable, 120°C
400100-350-05: High-temperature extended gap proximitor, 10mm range, 5m cable, 120°C
400100-400-02: Intrinsically safe gap proximitor, 5mm range, 2m cable, IECEx/ATEX Zone 0
400100-400-05: Intrinsically safe gap proximitor, 5mm range, 5m cable, IECEx/ATEX Zone 0
400100-400-09: Intrinsically safe gap proximitor, 5mm range, 9m cable, IECEx/ATEX Zone 0
400100-500-02: Intrinsically safe extended gap proximitor, 10mm range, 2m cable, Zone 0
400100-500-05: Intrinsically safe extended gap proximitor, 10mm range, 5m cable, Zone 0
Each 400100 Series unit processed by DriveKNMS undergoes a structured inspection and functional verification protocol specific to eddy-current proximity transducer systems. Verification steps include: DC output voltage linearity check across the full gap range (0–5mm or 0–10mm depending on variant) using a calibrated non-ferrous target fixture; oscillator frequency stability measurement at nominal supply voltage (−24 VDC); cable continuity and insulation resistance test at 500 VDC; connector pin integrity inspection under 10× magnification; and housing seal integrity check per IP67 criteria. For ATEX/IECEx-certified variants (400100-400 and 400100-500 sub-series), certification label legibility and entity parameter compliance are verified against the original certificate of conformity. Units that do not meet Bently Nevada factory output specifications are quarantined and not offered for sale.
