Honeywell 8C-PAIMA1 & 8C-TAIMA1 Analog Input Modules - 8C-PAIMA1 8C-TAIMA1

Technical Dossier

Product Details And Specifications

Honeywell HC900 Series Technical Notes

HC900 Full Catalog & Functionalities (SKU List)

Analog Input Modules

• 8C-PAIMA1: 8-channel analog input module, 4–20 mA / 0–10 V, 12-bit resolution, HC900 rack-mount
• 8C-TAIMA1: 8-channel analog input module with thermocouple/RTD input capability, multi-sensor type selection per channel
• 8C-PAIMA2: 16-channel analog input module, high-density configuration for large-scale process loops
• 8C-TAIMA2: 16-channel thermocouple/RTD analog input, extended sensor type library

Analog Output Modules

• 8C-PAOMA1: 4-channel analog output, 4–20 mA, 12-bit resolution, loop-powered field devices
• 8C-PAOMA2: 8-channel analog output module, high-density AO for valve positioner and actuator control

Digital Input Modules

• 8C-PDIDA1: 32-channel 24 VDC digital input module, sink/source configurable
• 8C-PDIDA2: 32-channel 120 VAC digital input module, isolated field wiring
• 8C-PDIDS1: 16-channel digital input, high-speed pulse counting capability

Digital Output Modules

• 8C-PDODA1: 16-channel 24 VDC digital output, sourcing type, 0.5 A per channel
• 8C-PDODA2: 16-channel relay output module, Form C contacts, 2 A per channel
• 8C-PDODS1: 8-channel high-current relay output, 5 A per channel, motor starter applications

Controller / CPU Modules

• 900C50-0100-00: HC900 C50 Controller, single Ethernet port, 2 MB memory, standard process applications
• 900C70-0100-00: HC900 C70 Controller, dual Ethernet, enhanced memory, peer-to-peer communication
• 900C70R-0100-00: HC900 C70R Redundant Controller module, hot-standby redundancy, bumpless transfer

Communication & Power Modules

• 900RIO-0001: Remote I/O Scanner module, fiber optic or copper link to remote expansion racks
• 900PSU-0001: HC900 24 VDC power supply module, rack-mount, 40 W output
