Honeywell BX Series Explosion-Proof Limit Switches – BXA3K-1A BXM4N

Name: Honeywell BX Series Explosion-Proof Limit Switches – BXA3K-1A BXM4N
Brand: Honeywell

Model: BXA3K-1A BXM4N

Brand Honeywell

Series BXA3K-1A BXM4N

Model BXA3K-1A BXM4N

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Honeywell BX Series Explosion-Proof Limit Switches Technical Notes

The Evolution of BX Series Architecture

The BX Series was introduced by Honeywell (formerly Micro Switch division) as a direct response to NEC Article 501 and IEC 60079 requirements for intrinsically safe and explosion-proof switching in Zone 1 / Zone 2 classified areas. Early production units used silver-alloy snap-action contacts rated at 10A / 600VAC, housed in a two-piece cast aluminum enclosure with NPT conduit entries. The BXA sub-family introduced modular actuator heads (BXM4N, BXM4R, BXM4L) that could be field-swapped without disturbing conduit wiring — a critical maintainability feature for turnaround-constrained refineries.

BX Series Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked models within the Honeywell BX Series. Units are classified by actuator type and contact configuration.

Explosion-Proof Limit Switches — Plunger & Roller Actuator

BXA3K-1A BXM4N: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, neutral roller lever actuator, 10A/600VAC, Class I Div 1 Groups C&D
BXA3K-2A BXM4N: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, neutral roller lever, 10A/600VAC, dual-circuit interlock applications
BXA3K-1A BXM4R: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, right-hand roller lever actuator, valve position feedback
BXA3K-1A BXM4L: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, left-hand roller lever actuator, mirror-image mounting
BXA3K-2A BXM4R: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, right-hand roller lever, SIS interlock duty
BXA3K-2A BXM4L: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, left-hand roller lever, SIS interlock duty
BXA4K-1A BXM4N: Explosion-proof limit switch, 1NO+1NC SPDT, 1" NPT dual entry, neutral roller lever, heavy-duty actuator torque
BXA4K-2A BXM4N: Explosion-proof limit switch, 2NO+2NC DPDT, 1" NPT dual entry, neutral roller lever, high-cycle valve duty
BXA3K-1A BXM2N: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, short neutral plunger actuator, compact installation envelope
BXA3K-2A BXM2N: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, short neutral plunger, dual-output position sensing
BXA3K-1A BXM6N: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, adjustable roller lever, variable cam geometry applications
BXA3K-2A BXM6N: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, adjustable roller lever, multi-position detection
BXA3K-4A BXM4N: Explosion-proof limit switch, 4-circuit (4NO+4NC), 3/4" NPT, neutral roller lever, complex interlock matrix duty
BXA3K-1A BXM8N: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, fork lever actuator, rotating shaft position detection
BXA3K-2A BXM8N: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, fork lever actuator, dual-output shaft sensing
BXA3K-1A BXM10N: Explosion-proof limit switch, 1NO+1NC SPDT, 3/4" NPT, wobble stick actuator, omnidirectional actuation geometry
BXA3K-2A BXM10N: Explosion-proof limit switch, 2NO+2NC DPDT, 3/4" NPT, wobble stick actuator, omnidirectional dual-circuit output

Quality Control for the BX Series Range

Inspection steps include: (1) visual examination of enclosure casting for cracks, corrosion, and conduit entry thread integrity; (2) continuity and insulation resistance testing on all contact circuits at 500VDC megohm test voltage; (3) snap-action mechanism verification — operating force, release force, and differential travel measured against Honeywell factory specification sheets; (4) actuator head alignment check and roller bearing condition assessment; (5) IP67 seal integrity verification via pressurized air test on enclosure joints; (6) functional cycle test — minimum 50 actuations under rated load to confirm contact bounce and wipe characteristics. Units that do not meet all acceptance criteria are quarantined and not offered for sale.

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
