Honeywell Safety Manager FC-TSDO-0824C: Safe Digital Output Module

Name: Honeywell Safety Manager FC-TSDO-0824C: Safe Digital Output Module
Brand: Honeywell

Model: FC-TSDO-0824C

Brand Honeywell

Series Pending

Model FC-TSDO-0824C

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Honeywell Safety Manager FC-TSxx Series Technical Notes

The Evolution of FC-TSxx Architecture

The Safety Manager platform succeeded Honeywell's earlier FSC (Fail-Safe Controller) product line, which was itself derived from the Quadlog architecture acquired through the Elsag Bailey integration. The FC-TSxx I/O module family was introduced alongside the SM controller chassis to provide a standardized, hot-swappable I/O layer compatible with the Safety Manager's redundant backplane bus. Early revisions of the FC-TSxx modules operated exclusively in simplex configurations; subsequent hardware revisions introduced dual-channel and TMR (Triple Modular Redundancy) support for critical output paths. The FC-TSDO-0824C represents the mature, field-proven revision of the 8-channel safe digital output class, incorporating enhanced self-test cycles and improved HART pass-through diagnostics compared to its predecessors. As the Safety Manager platform has entered its extended lifecycle phase, Honeywell has transitioned new SIS projects toward the Safety Manager SC (SMC) and Experion Safety Manager architectures, but the FC-TSxx installed base remains active across thousands of operating units worldwide, creating sustained demand for spare modules, repair services, and lifecycle extensions.

FC-TSxx Full Catalog & Functionalities (SKU List)

Controllers & Processors

FC-TSCP-0100: Safety Manager Central Processor, single-slot, SIL 3 rated
FC-TSCP-0200: Safety Manager Central Processor, redundant configuration module
FC-TSCM-0100: Communication Module, Ethernet/IP and Modbus TCP gateway

Safe Digital Input (SDI) Modules

FC-TSDI-1600: 16-channel safe digital input, 24 VDC, field-side isolated
FC-TSDI-0800: 8-channel safe digital input, configurable for NAMUR sensors
FC-TSDI-1601: 16-channel safe digital input, high-density, SIL 2 rated

Safe Digital Output (SDO) Modules

FC-TSDO-0824C: 8-channel safe digital output, 24 VDC, 0.5 A per channel, short-circuit protected — this listing
FC-TSDO-0824: 8-channel safe digital output, standard revision, predecessor to 0824C
FC-TSDO-1600: 16-channel safe digital output, high-density output module

Safe Analog Input (SAI) Modules

FC-TSAI-1620: 16-channel safe analog input, 4–20 mA, HART-enabled
FC-TSAI-0800: 8-channel safe analog input, configurable input ranges
FC-TSAI-1621: 16-channel safe analog input, enhanced diagnostics revision

Safe Analog Output (SAO) Modules

FC-TSAO-0800: 8-channel safe analog output, 4–20 mA, SIL 2 rated
FC-TSAO-0801: 8-channel safe analog output, HART pass-through enabled

Power Supply & Infrastructure

FC-TSPS-0100: Safety Manager power supply module, 24 VDC input, redundant-capable
FC-TSBP-0100: Backplane module, 8-slot chassis for FC-TSxx I/O expansion
FC-TSCB-0100: Communication bus terminator for FC-TSxx chassis
