Honeywell LY-2594V0 Power Supply Board

Technical Dossier

Product Details And Specifications

Honeywell LY Series: Comprehensive Power Supply Module Range and Technical Overview

The LY-2594V0 is a power supply board unit designed for internal backplane power distribution within Honeywell DCS cabinets. It provides stable regulated voltage rails to downstream modules and is a direct maintenance-critical component in legacy TDC 3000 and early Experion R-series installations.

The Evolution of LY Series Architecture

The LY series power supply boards were introduced as part of Honeywell's TDC 3000 platform in the early 1980s, designed to meet the stringent power integrity requirements of process automation backplanes. Early variants operated on linear regulation topologies, providing low-noise DC rails essential for analog I/O accuracy. Through the 1990s, the series transitioned to support the High-Performance Process Manager (HPPM) and Logic Manager (LM) subsystems, with revised board layouts to accommodate higher current demands and improved thermal management.

LY Series Full Catalog & Functionalities (SKU List)

Power Supply Boards

• LY-2594V0: Backplane power supply board unit; regulated DC rail distribution for TDC 3000 I/O cabinets.
• LY-2594V1: Revised revision of LY-2594V0; updated capacitor specification for extended thermal life.
• LY-2594V2: Third-revision power board; improved EMI filtering for high-noise plant environments.
• LY-2594V3: Final production revision; enhanced over-voltage protection circuit.
• LY-2594V4: High-current variant; supports expanded I/O backplane configurations up to 16 slots.

Auxiliary & Redundancy Power Modules

• LY-2595V0: Redundant power supply board; hot-standby configuration for critical process loops.
• LY-2595V1: Updated redundancy board with improved switchover response time (<10ms).
• LY-2596V0: Power distribution board; secondary rail splitter for multi-backplane cabinet wiring.
• LY-2596V1: Revised distribution board; added diagnostic LED indicators for field troubleshooting.
• LY-2597V0: Bulk power input board; AC-to-DC conversion stage for TDC 3000 main cabinet.

Associated I/O & Controller Power Interface Boards

• LY-2598V0: Controller power interface board; dedicated supply rail for Process Manager (PM) modules.
• LY-2599V0: I/O power interface board; isolated supply for analog input modules to reduce ground loop interference.
• LY-2600V0: Communication module power board; dedicated rail for Data Hiway and UCN interface cards.
• LY-2601V0: Fan and cooling power board; controls cabinet thermal management subsystem.
• LY-2602V0: Termination power board; provides loop power for 4–20mA field instrument circuits.
• LY-2603V0: Expansion chassis power board; used in extended I/O enclosures remote from main cabinet.

Quality Control for the LY Series Range
