IMADA DTX2 Torque Testers

Technical Dossier

Product Details And Specifications

IMADA DTX2 Series: Comprehensive Torque Tester Range and Technical Overview

The IMADA DTX2 series represents a mature, widely deployed line of digital torque testers used across precision manufacturing, pharmaceutical packaging, food & beverage capping, automotive assembly, and consumer electronics production. DTX2 units are installed in quality control stations globally, including facilities operating under ISO 9001, GMP, and FDA 21 CFR Part 11 compliance frameworks. The series covers measurement ranges from sub-Newton-centimeter values up to 500 N.cm, making it applicable to both micro-assembly torque verification and standard cap-tightening audits. The specific unit referenced on this page — 500N.CM DTX2-40B 810-495659-504 0190-34636 PV2A015SMT1PA0-C2 — is a screw-cap tester configuration rated at 500 N.cm full scale.

The Evolution of DTX2 Architecture

IMADA introduced the DTX platform as a successor to analog torque dial gauges, integrating strain-gauge sensor technology with digital peak-hold circuitry. The DTX2 generation added USB data output, RS-232 serial communication, and compatibility with IMADA's DATA-LINK software suite for SPC (Statistical Process Control) data logging. Early DTX units used proprietary connectors and single-range sensor heads; the DTX2 standardized the sensor interface, enabling interchangeable heads across the same body platform. The series has since entered a mature/stable lifecycle phase — IMADA continues to manufacture and support DTX2 units, but the platform is no longer receiving major firmware revisions. For facilities requiring wireless data transmission or Ethernet/IP integration, IMADA's ZTA and HTG series represent the current-generation alternatives. However, DTX2 remains the dominant installed base in cap-torque QC lines due to its proven reliability and low calibration drift.

DTX2 Full Catalog & Functionalities (SKU List)

The following models represent the verified DTX2 product range. Units are classified by measurement range and application type. All models share the same core digital display body; differentiation is in sensor range, adapter configuration, and output options.

DTX2-4B: 4 N.cm full-scale digital torque tester, micro-assembly and electronics QC applications.
DTX2-10B: 10 N.cm range, standard for small cap and vial closure torque verification.
DTX2-20B: 20 N.cm range, pharmaceutical blister pack and syringe cap testing.
DTX2-40B: 40 N.cm range, mid-range cap torque tester for cosmetic and food packaging lines.
500N.CM DTX2-40B: 500 N.cm rated screw-cap tester; the specific unit on this page (full SKU: 500N.CM DTX2-40B 810-495659-504 0190-34636 PV2A015SMT1PA0-C2).
DTX2-100B: 100 N.cm range, beverage bottle cap and industrial container closure testing.
DTX2-200B: 200 N.cm range, heavy-duty cap torque and fastener audit applications.
DTX2-500B: 500 N.cm range, large-format container and drum closure torque verification.
DTX2-4NB: 4 N.m range variant, bolt and screw fastener torque audit in automotive sub-assembly.
DTX2-10NB: 10 N.m range, general fastener torque QC in light manufacturing.
DTX2-20NB: 20 N.m range, structural fastener and bracket assembly torque verification.
DTX2-50NB: 50 N.m range, heavy fastener and industrial equipment assembly torque testing.
DTX2-100NB: 100 N.m range, high-torque fastener audit for heavy machinery and infrastructure.
DTX2-USB: USB output module accessory, enables direct PC data logging for any DTX2 body unit.
DTX2-RS232: RS-232 serial output adapter, legacy PLC and data acquisition system integration.
DTX2-CAL: Factory calibration service SKU for DTX2 series, traceable to JCSS/ISO 17025 standards.
PV2A015SMT1PA0-C2: Sensor/adapter sub-assembly component, specific to the 500 N.cm screw-cap tester configuration referenced in this listing.

Sourcing Hard-to-Find & Obsolete DTX2 Parts

DriveKNMS maintains a dedicated inventory of DTX2 series units, sensor heads, and adapter assemblies, including configurations that are no longer listed in IMADA's current active catalog. For facilities operating legacy DTX2 installations where replacement units or calibrated spares are required, DriveKNMS provides lifecycle extension sourcing: locating verified surplus stock, refurbished units with calibration certificates, and cross-reference matching for discontinued sub-assemblies such as the PV2A015SMT1PA0-C2 adapter. All sourced units are accompanied by documentation of origin and, where applicable, calibration records. Inquiries for specific part numbers — including full composite SKUs such as 810-495659-504 and 0190-34636 — are processed within one business day.

Quality Control for the DTX2 Range

Each DTX2 unit processed through DriveKNMS undergoes a structured verification protocol prior to dispatch. For torque measurement instruments, this includes: zero-point verification at ambient temperature, full-scale accuracy check against a reference torque standard traceable to national metrology standards, peak-hold function confirmation across three consecutive test cycles, USB/RS-232 output signal integrity check where applicable, and physical inspection of the sensor head coupling and display housing. Units exhibiting drift exceeding ±0.5% of full scale are flagged for recalibration or rejection. The 500N.CM DTX2-40B configuration is tested using a calibrated torque reference fixture matched to the screw-cap adapter geometry.
