IXYS MCC95 Modules - MCC95-16IO1B

Technical Dossier

Product Details And Specifications

IXYS MCC95 Series Technical Notes

The IXYS MCC95 series comprises phase-controllable thyristor (SCR) modules rated at 95 A average on-state current, designed for deployment in heavy industrial power conversion systems. These modules are installed across global heavy industry sectors including chemical processing plants, nuclear power auxiliary systems, oil refineries, steel rolling mills, and marine drive systems. The MCC95 platform operates within the standard IXYS stud-and-flat-base package format, enabling direct interchangeability with legacy rectifier assemblies. Repetitive peak off-state voltage ratings span from 800 V to 1800 V depending on the specific variant, making the series applicable to both 400 V and 690 V AC bus architectures. The series is manufactured to IEC 60747-6 standards and is compatible with standard thyristor gate drive circuits operating at 100–200 mA gate trigger current.

The Evolution of MCC95 Architecture

The MCC95 series belongs to IXYS's second-generation stud-mount thyristor module family, succeeding earlier discrete stud-mount SCR devices that required individual heatsink mounting and external snubber networks. The MCC95 package integrates two thyristors in an anti-parallel (AC switch) or series (DC switch) configuration within a single isolated base module, reducing assembly footprint by approximately 40% compared to discrete implementations.

MCC95 Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified MCC95 series product range, classified by voltage rating and configuration. Each module is rated at 95 A (ITAV) average on-state current.

MCC95-08IO1B: 800 V, anti-parallel thyristor pair, isolated base, AC power control
MCC95-10IO1B: 1000 V, anti-parallel configuration, standard stud-mount package
MCC95-12IO1B: 1200 V, dual SCR anti-parallel, for 690 V AC bus phase control
MCC95-14IO1B: 1400 V, high-voltage AC switch module, refinery drive applications
MCC95-16IO1B: 1600 V, anti-parallel thyristor module, heavy industrial AC controllers
MCC95-18IO1B: 1800 V, maximum voltage grade, nuclear and marine auxiliary drives
MCC95-08IO1L: 800 V, low-profile variant, space-constrained panel assemblies
MCC95-12IO1L: 1200 V, low-profile package, retrofit drive cabinet installations
MCC95-16IO1L: 1600 V, low-profile, high-voltage AC switch for legacy converters
MCC95-08IO8B: 800 V, isolated base with enhanced creepage, coastal/humid environments
MCC95-12IO8B: 1200 V, enhanced isolation grade, offshore platform power systems
MCC95-16IO8B: 1600 V, enhanced isolation, high-humidity industrial environments
MCC95-08IO1B-S: 800 V, screened/selected grade, tighter parameter tolerance for precision firing
MCC95-12IO1B-S: 1200 V, screened grade, matched pair for balanced phase control
MCC95-16IO1B-S: 1600 V, screened grade, critical process control applications
MCC95-14IO1B-S: 1400 V, screened, used in high-reliability power conversion stages
MCC95-18IO1B-S: 1800 V, screened, maximum voltage with tightest leakage current spec

Quality Control for the MCC95 Range

MCC95 modules present specific test challenges due to their dual-thyristor internal topology and isolated copper base construction. DriveKNMS applies the following test protocol to all MCC95 units prior to dispatch:
