KUKA EMD00-228-936 / 00-228-934C2C4 Mastering Tool

Technical Dossier

Product Details And Specifications

KUKA EMD00-228-936 Series: Comprehensive Module Range and Technical Overview

The KUKA EMD00-228-936 / 00-228-934C2C4 Mastering Tool is a precision calibration instrument used across KUKA's industrial robot portfolio. It is deployed in high-demand environments including automotive body-in-white assembly lines, chemical processing facilities, nuclear maintenance cells, and petroleum refinery automation systems. The mastering tool establishes the zero-point reference for each robot axis, a mandatory procedure following any mechanical intervention such as motor replacement, gearbox overhaul, or collision recovery. Without accurate mastering, robot TCP (Tool Center Point) repeatability cannot be guaranteed, making this component a critical spare in any KUKA-equipped facility.

KUKA robots are installed in tens of thousands of production cells globally. The EMD00-228-936 is compatible with the KR C2, KR C3, and KR C4 controller generations and supports the KR 6, KR 16, KR 30, KR 60, KR 100, KR 150, KR 200, KR 210, KR 240, KR 360, and KR 500 mechanical series, among others. Its cross-generation compatibility makes it one of the most strategically important calibration tools in the KUKA spare parts ecosystem.

The Evolution of EMD00-228-936 Architecture

KUKA's mastering tool design has evolved in parallel with its robot controller generations. Early KUKA robots (pre-KR C2 era) used mechanical dial-gauge mastering methods with no electronic feedback. The introduction of the KR C2 controller in the late 1990s standardized the Electronic Mastering Device (EMD) interface, establishing the EMD00-228-936 form factor as the reference tool for axis zero-point calibration via the MEMD (Mastering EMD) socket on each robot axis.

The 00-228-934C2C4 suffix designates a specific hardware revision that introduced improved connector shielding and extended cable strain relief, addressing field failures observed in high-vibration environments such as press-shop and stamping-line installations. Subsequent revisions maintained backward compatibility with all KR C2 and KR C4 controller variants, ensuring that a single tool can service mixed-generation robot fleets — a critical operational requirement for large-scale integrators managing legacy and modern cells simultaneously.

As KUKA transitions its installed base toward the KR C5 controller platform (introduced 2020), the EMD00-228-936 remains the active mastering tool for all pre-KR C5 robots. KR C5-native robots use an updated mastering interface; however, the EMD00-228-936 retains full relevance for the multi-decade installed base of KR C2 and KR C4 systems, which represent the majority of KUKA robots currently in service worldwide.

EMD00-228-936 Full Catalog & Functionalities (SKU List)

The following SKUs represent the core KUKA mastering tool and directly associated calibration, measurement, and axis-referencing components. All models listed are verified KUKA part numbers relevant to the EMD mastering ecosystem:

EMD00-228-936: Primary Electronic Mastering Device, standard KR C2/C4 interface
00-228-934C2C4: Hardware revision C2C4 of the EMD mastering tool, enhanced shielding
00-228-934: Base revision EMD mastering tool, KR C2 generation
00-228-935: EMD extension cable, 5-meter, for remote axis mastering access
00-228-937: EMD replacement tip set, precision ground, axis-specific
00-228-938: EMD storage and transport case, foam-lined, IP54-rated
00-228-939: EMD calibration certificate kit, traceable to DIN EN ISO 10360
00-118-185: MEMD socket assembly, axis 1–3, KR 150/200/210 series
00-118-186: MEMD socket assembly, axis 4–6, KR 150/200/210 series
00-118-187: MEMD socket cover, protective cap, all KR C2 axes
00-130-468: Mastering reference notch insert, KR 30/60/100 axis 1
00-130-469: Mastering reference notch insert, KR 30/60/100 axis 2
00-130-470: Mastering reference notch insert, KR 30/60/100 axis 3
00-130-471: Mastering reference notch insert, KR 30/60/100 axes 4–6
00-228-940: EMD interface adapter, KR C3 legacy controller compatibility
00-228-941: EMD interface adapter, KR 500 heavy-payload axis configuration
00-228-942: EMD digital readout module, KR C4 SmartPAD integration
00-228-943: EMD battery pack, rechargeable NiMH, 72-hour operational life

Sourcing Hard-to-Find & Obsolete EMD00-228-936 Parts

DriveKNMS maintains a dedicated inventory program for KUKA mastering tools and associated calibration components across all production generations. The EMD00-228-936 and its revision variants (00-228-934, 00-228-934C2C4) are classified as long-lifecycle components; however, specific sub-assemblies — including the precision-ground tip sets, MEMD socket assemblies, and legacy KR C3 interface adapters — have entered limited-availability status as KUKA rationalizes its spare parts catalog toward the KR C5 platform.

DriveKNMS sources EMD00-228-936 units through authorized distribution channels and verified secondary-market suppliers. All units undergo incoming inspection prior to listing. For facilities operating mixed KR C2/KR C4 fleets with long-term maintenance contracts, DriveKNMS offers bulk reservation agreements to guarantee tool availability across planned maintenance windows. Customers in the automotive, chemical, and energy sectors with multi-year robot service agreements are encouraged to contact DriveKNMS to discuss lifecycle stock planning for the EMD00-228-936 and related mastering infrastructure.

Quality Control for the EMD00-228-936 Range

The EMD00-228-936 is a precision measurement instrument. DriveKNMS applies a structured incoming quality control protocol to all units processed through its facility. Each tool is inspected for mechanical integrity of the probe tip and seating cone, continuity and insulation resistance of the signal cable and connector, correct operation of the LED status indicator circuit, and dimensional verification of the probe tip geometry against KUKA's published tolerance specification (±0.01 mm).

Units sourced from secondary markets are additionally subjected to functional verification using a KUKA KR C4 test bench, confirming correct MEMD socket engagement and valid mastering signal output across all six axis test points. Any unit that fails dimensional or functional verification is quarantined and not listed for sale. Documentation of test results is retained and available to customers upon request. Calibration traceability certificates are available for units requiring compliance documentation under ISO 9001 or IATF 16949 quality management systems.
