Motion Science MP3-404HR2

Technical Dossier

Product Details And Specifications

Motion Science MP3 Series Technical Notes

The Motion Science MP3 Series servo drives are deployed across global heavy industry sectors including petrochemical refineries, nuclear power generation facilities, offshore oil & gas platforms, and continuous-process chemical plants. The MP3 platform is a brushless AC servo drive family engineered for closed-loop torque, velocity, and position control in demanding multi-axis motion applications. Its modular architecture and wide voltage input range (single-phase and three-phase, 100–240 VAC) made it a standard specification in OEM machine tool, packaging, and material handling systems throughout the 1990s and 2000s. Installed base remains significant in legacy automation infrastructure where replacement with modern drives requires full mechanical and electrical re-engineering, making original-specification spare parts the preferred maintenance strategy.

The Evolution of MP3 Series Architecture

The MP3 Series was introduced by Motion Science as a successor to earlier analog servo amplifier platforms. Early revisions (MP3-2xx and MP3-3xx sub-families) used discrete analog command interfaces (±10 VDC velocity/torque reference) with resolver feedback. Mid-generation units introduced encoder feedback compatibility and RS-232/RS-485 serial communication for parameter configuration. The MP3-4xx sub-family, which includes the MP3-404HR2, represents the mature revision of the platform: it incorporates enhanced current loop bandwidth, improved EMI filtering, and a more robust power stage rated for higher continuous output current. The suffix HR2 denotes a high-resolution encoder interface variant with a second-generation firmware revision. As the broader servo drive market transitioned to EtherCAT and CANopen fieldbus-native architectures in the 2010s, the MP3 Series entered its end-of-life phase. Motion Science ceased active production of the MP3 line; however, the installed base in legacy systems sustains demand for spare and replacement units. Modern functional equivalents require adaptation of mechanical mounting, connector pinout, and feedback wiring — making direct MP3 replacements the lowest-risk maintenance path for plant engineers.

MP3 Series Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified MP3 Series product range, classified by function and power rating:

MP3-202: 200W continuous, ±10 VDC analog command, resolver feedback input
MP3-204: 200W, encoder feedback variant, RS-232 parameter interface
MP3-302: 300W continuous output, single-phase 100–240 VAC, analog velocity mode
MP3-304: 300W, dual feedback (resolver/encoder selectable), torque/velocity modes
MP3-402: 400W continuous, three-phase input, analog ±10 VDC, standard encoder
MP3-404: 400W, encoder feedback, RS-485 serial communication, position mode capable
MP3-404HR: 400W, high-resolution encoder interface (first revision), enhanced current loop
MP3-404HR2: 400W, high-resolution encoder interface (second revision), improved EMI filter, firmware Rev.2
MP3-502: 500W continuous, three-phase 200 VAC, analog command, standard resolver
MP3-504: 500W, encoder feedback, RS-485, multi-mode (torque/velocity/position)
MP3-504HR2: 500W, high-resolution encoder, second-generation firmware, enhanced power stage
MP3-752: 750W continuous, three-phase input, analog velocity/torque command
MP3-754: 750W, encoder feedback, serial communication, position loop capable
MP3-1002: 1.0 kW continuous, three-phase 200 VAC, analog command interface
MP3-1004: 1.0 kW, encoder feedback, RS-485, full torque/velocity/position control
MP3-1504: 1.5 kW continuous, three-phase input, encoder feedback, serial interface
MP3-2004: 2.0 kW continuous, three-phase 200 VAC, encoder feedback, RS-485 communication
