Novellus PVD300 17-307113-00 Shield Pedestal AL Grit CU – Obsolete PVD System Spare Part

Technical Dossier

Product Details And Specifications

Novellus PVD300 17-307113-00 Shield Pedestal AL Grit CU – Obsolete PVD System Spare Part

When a Shield Pedestal fails inside a Novellus PVD300 chamber, the consequences extend far beyond a single component. The PVD300 platform — a workhorse in copper and aluminum thin-film deposition for semiconductor fabs — is no longer manufactured. Sourcing a direct OEM replacement through standard channels is no longer possible. A single unplanned downtime event on a PVD300 line can halt wafer output for days. When that downtime forces a full platform migration, the capital expenditure — new tool qualification, process re-validation, facility retrofitting, and engineering labor — routinely reaches seven figures. Against that backdrop, a verified spare Shield Pedestal is not a consumable. It is a production continuity asset.

DriveKNMS maintains a limited inventory of this exact component. If your facility is still running Novellus PVD300 tools, securing this part now is a straightforward risk mitigation decision.

Technical Specifications

Note: Electrical parameters specific to this mechanical chamber component are not applicable. All specifications listed are verified against OEM documentation. No parameters have been estimated or inferred.

Solving the Discontinued Hardware Crisis

The Novellus PVD300 was deployed extensively across 200mm and early 300mm semiconductor fabs during the late 1990s and 2000s. Many facilities that built their process baseline on this platform have found that the cost and disruption of migrating to a current-generation PVD tool — re-qualifying processes, retraining operators, recertifying to customer specifications — far exceeds the cost of maintaining the existing installed base for another 5 to 10 years.

The Shield Pedestal is a direct-contact chamber component. It protects the pedestal assembly from deposition buildup during the PVD process and is subject to scheduled replacement as part of preventive maintenance cycles. Without a verified replacement on hand, a routine PM becomes a production risk. Facilities that have allowed their spare inventory of this part to reach zero are one maintenance cycle away from an unplanned outage with no clear resolution timeline.

The strategic case for maintaining a buffer stock of this component is straightforward: the cost of one spare pedestal shield is a fraction of one day of lost fab output. For facilities managing 200mm legacy lines serving automotive, industrial, or analog semiconductor customers — markets where process stability and long product lifecycles are contractual requirements — the ability to execute a scheduled PM without supply chain uncertainty is a measurable competitive advantage.

Facilities that have extended PVD300 platform life by 5 to 10 years beyond OEM support typically share three practices: they maintain a documented critical spare list for all chamber consumables and wear parts, they source verified OEM-equivalent spares from specialist distributors rather than waiting for a failure event, and they treat chamber component inventory as a capital asset rather than an operating expense. DriveKNMS exists specifically to support this model.

Condition & Reliability Assurance

All obsolete and legacy spare parts supplied by DriveKNMS pass a structured 5-step quality verification process before shipment:

• Step 1 – Visual and Dimensional Inspection: Physical examination for surface damage, corrosion, deformation, and dimensional conformance against OEM drawings where available.
• Step 2 – Surface Condition Assessment: Grit-blasted aluminum surfaces are inspected for coating adhesion integrity and contamination that could affect deposition uniformity or particle generation in the chamber.
• Step 3 – Pin and Interface Check: All mating surfaces, alignment features, and mechanical interfaces are verified for fit and freedom from corrosion or mechanical damage.
• Step 4 – Cleanliness Protocol: Components are cleaned and packaged to semiconductor-grade cleanliness standards to prevent contamination upon installation.
• Step 5 – Documentation and Traceability: Each unit is logged with inspection records. Part number, condition grade, and any observed history are documented and provided with shipment.

Key Features for System Maintenance

• Drop-in replacement: Direct OEM part number match. No engineering modification required for installation.
• No reprogramming required: This is a mechanical chamber component. Replacement does not affect tool recipes, process parameters, or software configuration.
• Avoids engineering reconstruction costs: Using a verified OEM-equivalent spare eliminates the need for process re-qualification that would be triggered by a platform change.
• Supports scheduled PM execution: Having this part in inventory allows maintenance teams to execute planned PM cycles on schedule, avoiding the risk of running beyond safe service intervals.
• Protects process baseline: Maintaining the existing PVD300 platform preserves a validated process baseline — a critical consideration for fabs with long-term customer process agreements.

FAQ

What warranty applies to this discontinued part?
DriveKNMS provides a 90-day warranty covering verified conformance to the part number specification and the condition grade stated at time of sale. Warranty claims are handled directly and promptly. Terms are confirmed in writing prior to shipment.

How do I know the part is genuine OEM or a quality-verified equivalent?
We supply only parts that can be verified against the OEM part number. Condition grade (new surplus, refurbished, or tested used) is disclosed transparently before purchase. We do not supply parts of unknown origin or unverifiable provenance.

Should I buy more than one unit?
For any facility running active PVD300 tools, holding a minimum of one spare Shield Pedestal per active chamber is a standard risk management practice. Given that this part is discontinued and inventory across the market is finite, purchasing a buffer quantity now is a lower-cost decision than sourcing under emergency conditions later.

Can you support other PVD300 chamber components?
Yes. DriveKNMS specializes in legacy semiconductor equipment spares. Contact us with your full BOM or critical spare list and we will advise on availability.
