Parker PA Series HMI Panels PA08T-133

Technical Dossier

Product Details And Specifications

Parker PA Series HMI Panels Technical Notes

The Parker PA Series operator interface terminals represent one of Parker Hannifin's core human-machine interface (HMI) product lines, deployed extensively across global heavy industry sectors including petrochemical refineries, offshore oil & gas platforms, nuclear auxiliary systems, pulp and paper mills, and continuous process manufacturing. The PA Series panels are engineered to interface directly with Parker's AC and DC drive families—including the AC10, AC30, AC890, and SSD series—as well as third-party PLCs via standard industrial protocols. Their ruggedized enclosures, wide operating temperature ranges, and long-term firmware support made them a preferred choice for facilities requiring 10–20 year operational lifecycles without platform migration.

The Evolution of PA Series Architecture

The Parker PA Series evolved through several distinct hardware generations. Early units in the PA Series used resistive touchscreen technology with monochrome or limited-color STN LCD displays, targeting basic parameter entry and drive status monitoring. These panels communicated via RS-232 and RS-485 serial links using Parker's proprietary ASCII command set.

Mid-generation PA panels introduced TFT color displays, expanded memory for recipe and data logging, and added support for Modbus RTU and CANopen fieldbus protocols. This generation—including the PA08T and PA10T families—became the dominant installed base in European and Asian process industries through the 2000s and early 2010s.

PA Series Full Catalog & Functionalities (SKU List)

The following SKUs represent the verified PA Series product range. Units are classified by display size, touch technology, and communication configuration:

PA08T-133: 8-inch TFT color resistive touchscreen HMI, 320×240 resolution, RS-232/RS-485, Parker drive native protocol
PA08T-135: 8-inch TFT panel with expanded I/O port configuration, dual serial ports, Modbus RTU slave support
PA08T-500: 8-inch panel variant with USB host port and 128MB onboard flash for recipe storage
PA10T-133: 10.4-inch TFT color touchscreen, 640×480 VGA resolution, RS-232/RS-485, Parker native protocol
PA10T-135: 10.4-inch panel with Modbus RTU and CANopen dual-protocol support
PA10T-500: 10.4-inch panel with USB host, extended memory, and Ethernet RJ45 port
PA12T-133: 12.1-inch TFT color touchscreen HMI, SVGA 800×600, RS-485 native Parker protocol
PA12T-135: 12.1-inch panel with Modbus RTU slave and master capability
PA12T-500: 12.1-inch panel with full connectivity suite: USB, Ethernet, dual serial
PA15T-133: 15-inch TFT color touchscreen, XGA 1024×768, RS-232/RS-485, Parker drive protocol
PA15T-135: 15-inch panel with Modbus RTU and CANopen fieldbus support
PA15T-500: 15-inch panel with USB host, Ethernet, and extended data logging capacity
PA05T-133: 5.7-inch compact TFT touchscreen, RS-485 serial, Parker native protocol, panel-mount
PA05T-135: 5.7-inch compact panel with Modbus RTU support, suitable for drive door mounting
PA08M-133: 8-inch membrane keypad variant (non-touch), RS-232/RS-485, Parker native protocol
PA10M-133: 10.4-inch membrane keypad HMI, RS-485, Parker drive parameter interface
PA-PGMCBL-001: Programming and configuration cable for PA Series panels, USB-A to proprietary connector
PA-PWRSPLY-001: 24VDC DIN-rail power supply accessory for PA Series panel installations

Quality Control for the PA Series Range

PA Series panels present specific test challenges due to their integrated touchscreen digitizer assemblies, backlight inverter circuits, and serial communication ASICs. DriveKNMS applies the following verification procedures to all PA Series units prior to dispatch:
