Schneider Electric 171CCC78010 Modicon Momentum Processor Adapter

Technical Dossier

Product Details And Specifications

Schneider Electric 171CCC Series Technical Notes

The Schneider Electric Modicon Momentum 171CCC series represents one of the most widely deployed distributed control architectures in global heavy industry. Installed across petrochemical refineries, nuclear power generation facilities, offshore platforms, and large-scale chemical processing plants, the 171CCC processor adapter family serves as the central intelligence layer of the Momentum I/O platform. These units interface directly with Momentum I/O bases (170 series) and execute ladder logic, function block, and structured text programs under IEC 61131-3 compliance. Their modular, DIN-rail-mounted form factor and support for multiple fieldbus protocols — including Modbus, Modbus Plus, Ethernet TCP/IP, and INTERBUS — made the 171CCC series a standard specification in automation projects from the mid-1990s through the 2010s. The series remains operational in thousands of installed base sites globally, driving sustained demand for spare parts and lifecycle support.

The Evolution of 171CCC Architecture

The Modicon Momentum platform was introduced by Schneider Electric (then AEG Schneider Automation) in the mid-1990s as a response to the industry demand for compact, distributed I/O with embedded processing capability. The 171CCC processor adapter was designed to mount directly onto Momentum I/O bases, eliminating the need for a separate rack and backplane — a significant departure from the Modicon 984 and Quantum architectures that preceded it.

Early 171CCC variants (circa 1996–2000) supported Modbus RTU and Modbus Plus as primary communication protocols, with program memory limited to 32 KB. Subsequent revisions introduced Ethernet TCP/IP connectivity (171CCC980020, 171CCC980030), expanding integration capability with SCADA systems and enabling peer-to-peer communication without a dedicated network bridge. The 171CCC78010 specifically implements the INTERBUS fieldbus protocol, positioning it for installations in European automotive and manufacturing environments where INTERBUS was the dominant standard.

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.

171CCC Full Catalog & Functionalities (SKU List)

The following represents the core 171CCC series processor adapter range, classified by communication protocol and functional capability. All models mount on Momentum I/O bases and are programmed via Concept, ProWORX, or Unity Pro (compatibility varies by firmware revision).

Modbus / Modbus Plus Processors

• 171CCC76000: Standalone processor, Modbus RTU, 32 KB user memory, no network port
• 171CCC76010: Standalone processor, Modbus Plus, 32 KB user memory, peer-to-peer messaging
• 171CCC76020: Standalone processor, Modbus Plus, 64 KB user memory, enhanced data table
• 171CCC76030: Standalone processor, Modbus Plus, 128 KB user memory, extended I/O mapping
• 171CCC76100: Standalone processor, Modbus RTU, 64 KB user memory, compact variant

Ethernet TCP/IP Processors

• 171CCC980020: Ethernet TCP/IP processor, 10 Mbps, 64 KB user memory, Modbus TCP server
• 171CCC980030: Ethernet TCP/IP processor, 10/100 Mbps, 128 KB user memory, web server, SNMP
• 171CCC980040: Ethernet TCP/IP processor, 10/100 Mbps, 256 KB user memory, FTP data logging
• 171CCC980050: Ethernet TCP/IP processor, enhanced security, 256 KB user memory, HTTPS support

INTERBUS Processors

• 171CCC78010: INTERBUS master processor adapter, 64 KB user memory, ring topology support, IEC 61131-3 compliant — the subject SKU of this page
• 171CCC78020: INTERBUS master processor, extended memory, 128 KB user memory, multi-ring configuration

FIPIO / CANopen Processors

• 171CCC96020: FIPIO master processor, 64 KB user memory, compatible with Telemecanique FIPIO devices
• 171CCC96030: FIPIO master processor, 128 KB user memory, extended variable table
• 171CCC96040: CANopen master processor, 64 KB user memory, DS301/DS401 profile support

DeviceNet Processors

• 171CCC97020: DeviceNet scanner processor, 64 KB user memory, explicit and I/O messaging
• 171CCC97030: DeviceNet scanner processor, 128 KB user memory, Group 2 only server support

Quality Control for the 171CCC Range

Each 171CCC processor adapter processed by DriveKNMS undergoes a structured multi-stage inspection protocol before dispatch. Given the complexity of the Momentum backplane communication bus and the sensitivity of the processor adapter's fieldbus interface circuitry, standard visual inspection is insufficient.
