Schneider Electric Modicon M340 Series Technical Notes

The Evolution of Modicon M340 Architecture

The M340 platform was formally launched circa 2006, built around the BMX backplane bus architecture — a proprietary high-speed parallel bus that differentiates it from the earlier Modicon Premium (TSX) series which used the ISA-derived X-Bus. The M340 rack accepts 4, 6, 8, or 12-slot configurations (BMXXBP0400, BMXXBP0600, BMXXBP0800, BMXXBP1200) and communicates internally at speeds sufficient for deterministic real-time control loops down to 1 ms cycle times.

Early M340 CPUs (BMX P34 1000/2000 series) supported Modbus TCP and CANopen natively. Subsequent firmware revisions added IEC 61131-3 structured text enhancements, redundancy options via the BMXCRA31200/31210 RIO drop adapters, and expanded Ethernet/IP compatibility. The platform reached technical maturity around 2012–2015. As of 2020, Schneider Electric has positioned the Modicon M580 as the strategic successor for new installations, placing the M340 in a sustained-support lifecycle phase. This means OEM replacement parts, particularly communication adapters and specialty I/O modules, are increasingly sourced through specialist distributors rather than standard channels.

Compatibility note: M340 modules are not cross-compatible with Modicon Quantum (140-prefix) or Modicon M580 (BMENOC/BMEP58x) racks. All BMX-prefix modules are exclusive to the M340 backplane.

Modicon M340 Full Catalog & Functionalities — SKU List

CPU / Controller Modules

BMXP341000: M340 CPU, 256 KB application memory, Modbus/CANopen, no Ethernet
BMXP342000: M340 CPU, 512 KB application memory, integrated Ethernet Modbus TCP
BMXP342010: M340 CPU, 512 KB, Ethernet + web server, enhanced diagnostics
BMXP342020: M340 CPU, 1 MB application memory, dual Ethernet ports, IEC 61850 ready
BMXP3420302: M340 CPU, 4 MB memory, Safety-capable variant, SIL2 certified

RIO Drop Adapters / Communication Modules

BMXCRA31200: Ethernet RIO drop adapter, 100 Mbps, standard rack integration
BMXCRA31210: Ethernet RIO drop adapter with enhanced diagnostics, supports hot-standby RIO topology — this listing
BMXNOE0100: Ethernet network module, 10/100 Mbps, Modbus TCP / EtherNet/IP
BMXNOE0110: Ethernet network module with web server and FTP data logging
BMXNRP0200: Fiber optic repeater module for extended RIO segment distances

Digital Input Modules

BMXDDI1602: 16-channel 24 VDC digital input, sink/source, standard density
BMXDDI3202K: 32-channel 24 VDC digital input, high-density, conformal coated
BMXDAI1602: 16-channel 100–120 VAC digital input module

Digital Output Modules

BMXDDO1602: 16-channel 24 VDC transistor output, 0.5 A per channel
BMXDRA0805: 8-channel relay output, 5 A per channel, 24–240 VAC/VDC
BMXDDO3202K: 32-channel 24 VDC transistor output, high-density, conformal coated

Analog Input / Output Modules

BMXAMI0410: 4-channel analog input, ±10 V / 0–20 mA, 12-bit resolution
BMXAMI0800: 8-channel analog input, voltage/current, 16-bit resolution
BMXAMO0210: 2-channel analog output, ±10 V / 0–20 mA, 12-bit
BMXAMO0410: 4-channel analog output, voltage/current, 12-bit resolution

Power Supply Modules

BMXCPS2000: 24 VDC rack power supply, 20 W, standard M340 rack
BMXCPS3500: 100–240 VAC / 125 VDC power supply, 35 W, wide input range
BMXCPS3540T: 100–240 VAC power supply, 35 W, extended temperature (-25°C to +70°C)

Sourcing Hard-to-Find & Obsolete Modicon M340 Parts

DriveKNMS provides documented traceability for all M340 modules, including firmware version records where applicable, to support plant change-management and safety audit requirements.

Quality Control for the Modicon M340 Range

The M340 platform's BMX backplane bus and RIO communication architecture require specialized validation procedures beyond standard power-on testing. DriveKNMS applies the following protocols to all M340 modules prior to dispatch:

Backplane bus integrity test: Each module is seated in a live M340 rack and polled via Unity Pro / EcoStruxure Control Expert to confirm correct module recognition and I/O map registration.
RIO drop adapter validation (BMXCRA31200/31210): Full Ethernet RIO topology simulation, including hot-standby switchover test where applicable, with logged cycle-time measurements.
Analog module calibration check: Input/output accuracy verified against NIST-traceable reference instruments at 0%, 50%, and 100% of rated range.
Firmware version audit: CPU and communication modules are checked for minimum compatible firmware versions per Schneider Electric compatibility matrices.
Thermal burn-in: Modules operated at rated load for minimum 4 hours to screen early-life failures before dispatch review.
