Schneider Electric Modicon M340 BMX Modules - BMXDDI3202K

Name: Schneider Electric Modicon M340 BMX Modules - BMXDDI3202K
Brand: Schneider Electric

Model: BMXDDI3202K

Brand Schneider Electric

Series Modicon M340

Model BMXDDI3202K

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Schneider Electric Modicon M340 BMX Series Technical Notes

The Evolution of BMX Architecture

The Modicon M340 platform was introduced in 2006 as the successor to the Modicon TSX Quantum (140-prefix) and TSX Premium (TSX-prefix) families, consolidating their I/O philosophies into a unified Ethernet-native backplane. The BMX architecture introduced the X Bus (local rack extension) and Ethernet I/O Bus (distributed I/O via BMXNOE/BMXNOC adapters), replacing the earlier Modbus Plus topology used in Quantum systems.

Key architectural milestones: the BMXP341000 (original Unity Pro v2.x CPU) established the base instruction set; the BMXP342020 introduced dual Ethernet ports and web server diagnostics; the BMXP3420302 added Ethernet redundancy (Hot Standby) capability. Firmware compatibility between CPU generations is version-gated — Unity Pro XL v13+ is required for BMXP342020H Hot Standby configurations. Modules from the original 2006 release remain electrically compatible with current racks but require firmware alignment for diagnostic transparency.

As of 2024, Schneider Electric has designated the M340 platform as Active — Mature, with the Modicon M580 (BMENOC/BMEP-prefix) positioned as the strategic successor. Long-term spare parts availability for BMX modules is confirmed through Schneider's Green Premium program to 2030, with third-party MRO suppliers extending effective availability beyond that horizon.

Modicon M340 BMX Full Catalog & Functionalities (SKU List)

CPU / Controller Modules

BMXP341000: M340 CPU, 256KB application memory, single Ethernet port, Unity Pro v2+
BMXP342000: M340 CPU, 512KB application memory, dual Ethernet, Modbus TCP/IP master
BMXP342010: M340 CPU, 1MB application, CANopen master port, dual Ethernet
BMXP342020: M340 CPU, 4MB application, dual Ethernet, web server, data logging
BMXP3420302: M340 Hot Standby CPU, 4MB, dual Ethernet, redundancy management

Discrete Input (DI) Modules

BMXDDI1602: 16-channel 24VDC discrete input, sink/source, standard density
BMXDDI3202K: 32-channel 24VDC discrete input, connector block terminal, high density
BMXDDI6402K: 64-channel 24VDC discrete input, high-density, HE10 connector

Discrete Output (DO) Modules

BMXDDO1602: 16-channel 24VDC discrete output, 0.5A per channel, transistor source
BMXDDO3202K: 32-channel 24VDC discrete output, connector block, 0.1A per channel
BMXDRA0805: 8-channel relay output, 5A per channel, 24–240VAC/VDC

Analog Input (AI) Modules

BMXAMI0410: 4-channel analog input, ±10V / 0–20mA / 4–20mA, 12-bit resolution
BMXAMI0800: 8-channel analog input, 0–10V / 4–20mA, 12-bit, single-ended
BMXART0414: 4-channel RTD/thermocouple input, Pt100/Pt1000/TC types, 16-bit

Analog Output (AO) Modules

BMXAMO0210: 2-channel analog output, ±10V / 0–20mA, 12-bit resolution
BMXAMO0410: 4-channel analog output, ±10V / 4–20mA, 12-bit, short-circuit protected

Communication & Network Adapters

BMXNOE0100: Ethernet TCP/IP communication module, 10/100 Mbps, Modbus TCP server
BMXNOE0110: Ethernet module with web server, FTP, SNMP, email notification
BMXNOC0401: CANopen master module, 127 nodes, 1Mbps, DS301/DS401 profiles

Power Supply Modules

BMXCPS2000: 20W rack power supply, 24VDC input, for 4/8-slot racks
BMXCPS3500: 35W rack power supply, 100–240VAC input, universal voltage
BMXCPS3540T: 35W power supply, 100–240VAC, conformal coating, extended temperature

Continue The Model Path

Use system, brand and series routes to compare related published models.

Move from this exact model into the matching system hub, brand archive, model-family archive or lifecycle sourcing route before sending a final RFQ list.
