Schneider Electric XBTF Series HMI Modules XBTF024610 Membrane Keypad Switch Keyboard

Technical Dossier

Product Details And Specifications

Schneider Electric XBTF Series Technical Notes

The Schneider Electric XBTF series belongs to the Magelis XBT family of Human-Machine Interface (HMI) terminals, widely deployed across global heavy industry sectors including petrochemical refineries, nuclear power auxiliary systems, offshore platforms, and continuous-process chemical plants. The XBTF range occupies the operator panel and membrane keypad segment of the Magelis portfolio, providing tactile input interfaces for SCADA and PLC-driven control systems. Installed base figures across these industries remain substantial, making lifecycle support and spare parts availability a critical operational concern for plant maintenance engineers and automation system integrators worldwide.

The Evolution of XBTF Architecture

The XBTF series was introduced as part of Schneider Electric's consolidation of the legacy Telemecanique XBT operator terminal range into the unified Magelis brand. Early XBTF units were designed around membrane keypad overlays interfacing with dedicated XBT display modules, operating on proprietary Uni-Telway and Modbus serial communication protocols. As industrial automation migrated toward Ethernet-based architectures and open fieldbus standards (Profibus, CANopen, EtherNet/IP), the XBTF keypad modules retained backward compatibility with legacy XBT controllers while newer Magelis XBTGT, XBTGK, and HMIGTO series assumed primary HMI roles. The XBTF series is now classified as a mature-to-end-of-life product line. Schneider Electric has formally migrated new project specifications toward the Magelis GTU and iPC ranges. However, the installed base of XBTF-dependent systems in brownfield facilities ensures continued demand for original replacement parts, particularly membrane keypads, which are subject to mechanical wear under continuous industrial operation. Long-term maintenance support for XBTF components is a defined requirement for facilities operating under IEC 61511 functional safety management frameworks.

XBTF Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly sourced components within the Schneider Electric XBTF and closely associated XBT membrane keypad and operator panel range. Each entry reflects a distinct functional role within the HMI terminal architecture.

XBTF024610: Membrane keypad switch keyboard assembly for XBTF02 series HMI terminals; tactile dome-switch matrix, 24-key layout.
XBTF024110: Membrane keypad overlay for XBTF024 base unit; function key strip with LED indicator windows.
XBTF024210: Replacement front panel membrane for XBTF024 operator terminal; chemical-resistant polyester face.
XBTF034610: Membrane keypad assembly for XBTF03 series; extended 34-key matrix with numeric and function zones.
XBTF034110: Function key membrane strip for XBTF034 terminal; 8 configurable F-keys with tactile feedback.
XBTF034210: Front panel overlay for XBTF034; IP65-rated sealing gasket integrated.
XBTF064610: Membrane keypad for XBTF06 large-format operator panel; 64-key full alphanumeric matrix.
XBTF064110: Function key assembly for XBTF064 terminal; 16 F-keys, backlit legends.
XBTF064210: Replacement front bezel membrane for XBTF064; UV-stable polycarbonate overlay.
XBTF084610: Membrane keypad switch assembly for XBTF08 series; 84-key extended layout for complex process entry.
XBTF084110: Function key strip for XBTF084 terminal; dual-row F-key arrangement.
XBTF084210: Front panel membrane for XBTF084; rated for continuous industrial environment exposure.
XBTF104610: Membrane keypad for XBTF10 operator panel; 104-key full-travel matrix, QWERTY and process key zones.
XBTF104110: Function key overlay for XBTF104; 20 F-keys with silk-screened legends.
XBTF104210: Front panel overlay for XBTF104; anti-glare surface treatment, IP65 gasket seal.
XBTF124610: Membrane keypad assembly for XBTF12 large-panel terminal; 124-key matrix, suitable for complex SCADA operator stations.
XBTF124110: Extended function key strip for XBTF124; 24 F-keys, dual-color LED indicators.
XBTF124210: Replacement front membrane for XBTF124; reinforced overlay for high-cycle industrial use.
