Semikron SKKT106/16E Dual Thyristor Module – Obsolete SEMIPACK2 Spare Part

When a thyristor module fails in a legacy rectifier bridge or DC drive system, the consequences extend far beyond the cost of the component itself. A single SKKT106/16E failure can halt an entire production line — and if the module is no longer manufactured, the path of least resistance becomes a full system retrofit. Conservative estimates place the engineering, downtime, and revalidation costs of such a retrofit between $200,000 and $2,000,000 USD, depending on system complexity and production criticality. DriveKNMS maintains verified stock of the Semikron SKKT106/16E specifically to prevent that outcome.

This is not a commodity part. It is a precision power semiconductor that has reached end-of-life status with the original manufacturer. Every unit we hold represents a direct alternative to a capital expenditure your facility should not have to make.

Technical Specifications

Solving the Discontinued Hardware Crisis

The SKKT106/16E was a standard building block in three-phase fully-controlled rectifier bridges throughout the 1990s and 2000s. It is commonly found in legacy DC drive platforms from manufacturers including Siemens, ABB, and Eurotherm, as well as in custom-engineered power conversion cabinets that were designed around the SEMIPACK2 footprint.

Semikron has discontinued this part. No direct equivalent with an identical footprint, gate trigger characteristics, and thermal interface geometry is currently in production. This means that any facility still operating equipment built around the SKKT106/16E faces a binary choice when a module fails: source a verified replacement unit, or commit to a drive system replacement project.

The case for maintaining a strategic spare inventory is straightforward. A DC drive system that has been in service for 15–25 years has already been fully depreciated on the balance sheet. Its replacement cost — including new drive hardware, installation, commissioning, and process revalidation — is a capital expenditure that most maintenance budgets are not structured to absorb on short notice. A stockpile of two to four SKKT106/16E modules, held in controlled storage conditions, extends the operational life of that asset by a further 5 to 10 years at a fraction of the replacement cost.

For plant managers operating under pressure to defer capital expenditure while maintaining production reliability, this is not a workaround. It is a defensible asset protection strategy.

Condition & Reliability Assurance

Every SKKT106/16E unit processed through DriveKNMS undergoes a structured 5-step inspection protocol before it is offered for sale:

• Step 1 – Visual and mechanical inspection: Housing integrity, terminal condition, and SEMIPACK2 mounting surface flatness are verified. Units with cracked housings or deformed terminals are rejected.
• Step 2 – Electrolytic capacitor assessment: Where applicable in associated assemblies, capacitor aging is evaluated. For bare modules, gate-cathode junction integrity is tested.
• Step 3 – Pin and terminal corrosion check: Gate, cathode, and anode terminals are inspected under magnification for oxidation, pitting, or contamination that could affect contact resistance or gate trigger reliability.
• Step 4 – Firmware and date code verification: Lot traceability and date codes are recorded. Units from suspect date ranges or unverifiable supply chains are quarantined.
• Step 5 – Functional parameter verification: Forward blocking voltage and gate trigger threshold are tested against published datasheet limits prior to shipment.

Units are stored in anti-static packaging in a temperature and humidity-controlled environment. Condition grade is disclosed in full at the time of quotation.

Key Features for System Maintenance

• Drop-in replacement: The SKKT106/16E retains the original SEMIPACK2 mounting footprint and terminal layout. Installation requires no mechanical modification to the existing heatsink or busbar assembly.
• No reprogramming required: Thyristor modules do not carry firmware. Replacement restores the original circuit function without any control system reconfiguration.
• Avoids engineering redesign costs: Substituting a verified OEM-equivalent module eliminates the need for drive system re-engineering, UL/CE re-certification, and process revalidation — costs that routinely exceed the value of the original equipment.
• Supports long-term spares strategy: Purchasing two to four units now, while verified stock is available, provides a multi-year maintenance buffer against future supply disruption.

FAQ

What warranty applies to discontinued parts?
DriveKNMS provides a 90-day warranty against defects in material and workmanship on all units shipped. Warranty terms are confirmed in writing at the time of order.

How do I know the unit is genuine and not counterfeit?
All units are sourced through documented supply chains. Date codes, lot numbers, and physical markings are verified against known-good references. We do not source from unverifiable grey-market channels. Full traceability documentation is available on request.

Should I buy more than one unit?
For any system where the SKKT106/16E is a single point of failure, holding a minimum of two spare units is the standard recommendation. Given that this part is no longer manufactured, current stock levels across the global market are finite and declining. Procurement decisions deferred today carry a measurable risk of unavailability at the point of need.

Can you source other Semikron SEMIPACK2 modules?
Yes. DriveKNMS specializes in obsolete and hard-to-find power semiconductors across the Semikron SEMIPACK, SEMITOP, and SKiiP families. Contact us with your full part number for availability.
