Siemens SIMATIC TP170 HMI Panels – 6AV6545-0BA15-2AX0

Name: Siemens SIMATIC TP170 HMI Panels – 6AV6545-0BA15-2AX0
Brand: Siemens

Model: 6AV6545-0BA15-2AX0

Brand Siemens

Series 6AV6545-0BA15-2AX0

Model 6AV6545-0BA15-2AX0

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Siemens SIMATIC TP170 Series Technical Notes

The Evolution of SIMATIC TP170 Architecture

The SIMATIC TP170 series was introduced in the late 1990s as a successor to the OP/TP 170A monochrome panel range. It introduced resistive color touchscreen technology, MPI/PROFIBUS-DP and RS-422/485 serial interfaces, and compatibility with STEP 7 and ProTool configuration environments. The architecture evolved through two primary sub-families:

TP170A — Monochrome STN LCD, 4-line text display, MPI interface only. Targeted at cost-sensitive discrete automation. TP170B — STN color or monochrome LCD (5.7"), expanded tag count, support for WinCC flexible 2004 and later, MPI/PROFIBUS-DP dual interface. The TP170B became the dominant variant in process industries due to its graphical capability and protocol flexibility.

Siemens officially declared the TP170 series end-of-life (EOL), with mainstream support discontinued. Replacement migration paths lead to the SIMATIC HMI KTP700 Basic (6AV2123-2GB03-0AX0) and KTP900 Basic panels under the Basic Panel 2nd Generation portfolio. However, due to the installed base volume and the cost of full SCADA migration, the TP170 series remains in active spare parts demand across maintenance-driven industries.

SIMATIC TP170 Full Catalog & Functionalities (SKU List)

Touch Panels — TP170B Color & Monochrome

6AV6545-0BA15-2AX0: TP170B, 5.7" STN color 256-color, MPI/PROFIBUS-DP, RS-422/485, 24VDC, WinCC flexible compatible
6AV6545-0BC15-2AX0: TP170B, 5.7" STN monochrome, MPI/PROFIBUS-DP, RS-422/485, 24VDC, standard process HMI variant
6AV6545-0AA15-2AX0: TP170A, 5.7" monochrome STN, MPI only, 4-line text/graphics, entry-level discrete automation
6AV6545-0AG10-0AX0: TP170A, 5.7" monochrome, MPI, ProTool/Lite configuration, reduced tag count
6AV6545-0BB15-2AX0: TP170B, 5.7" STN color, PROFIBUS-DP only, panel-mount, process industry variant
6AV6545-0CA10-0AX0: TP170B micro, compact form factor, MPI, reduced I/O tag capacity, OEM integration
6AV6545-0DA10-0AX0: TP170B, extended temperature range (-20°C to +60°C), outdoor/harsh environment deployment
6AV6545-0EA15-2AX0: TP170B, INOX stainless steel front bezel, IP65 front protection, food & pharma industry
6AV6545-0FA10-0AX0: TP170B, ATEX Zone 2 certified variant, hazardous area HMI, petrochemical use
6AV6640-0CA11-0AX0: TP177A, 5.7" successor variant, MPI/PROFIBUS-DP, WinCC flexible 2005+, direct TP170A migration target
6AV6640-0DA11-0AX0: TP177B, 5.7" color, MPI/PROFIBUS-DP/Ethernet, WinCC flexible 2007, TP170B migration target
6AV6545-0AG10-2AX0: TP170A, 5.7" monochrome, MPI, firmware v2.x, legacy ProTool project compatible
6AV6545-0BC10-0AX0: TP170B, 5.7" monochrome, MPI, early production batch, firmware v3.x baseline
6AV6545-0BA10-0AX0: TP170B, 5.7" color, MPI only, early revision, no PROFIBUS-DP, pre-2002 production
6AV6545-0BB10-0AX0: TP170B, 5.7" color, PROFIBUS-DP, early revision, firmware v3.x, pre-WinCC flexible era
6AV6545-0CA15-2AX0: TP170B micro, 5.7" color, MPI/PROFIBUS-DP, compact panel-mount, machine builder OEM

Quality Control for the SIMATIC TP170 Range

Each TP170 unit processed by DriveKNMS undergoes a structured inspection and functional test protocol specific to the panel architecture:

Touchscreen calibration verification: Resistive matrix tested across full active area using automated grid-point contact simulation
Display backlight output measurement: CCFL or LED backlight luminance measured against OEM specification (minimum 70% of rated nit value accepted)
MPI/PROFIBUS-DP communication test: Panel connected to S7-300 test rack; tag read/write cycle executed at 1.5 Mbps and 12 Mbps
Serial port integrity check: RS-422/RS-485 loopback test at 19200 and 115200 baud
Power supply input range test: 24VDC input verified at 18V, 24V, and 30V to confirm regulator tolerance
Firmware version documentation: Firmware revision recorded and disclosed in shipment documentation
Physical inspection: Bezel, connector pins, and rear housing inspected for mechanical damage; IP rating integrity assessed
