Siemens SIMATIC HMI IPC477 Modules – 6AV7870-0HA20-0AA0

Name: Siemens SIMATIC HMI IPC477 Modules – 6AV7870-0HA20-0AA0
Brand: Siemens

Model: 6AV7870-0HA20-0AA0

Brand Siemens

Series SIMATIC HMI

Model 6AV7870-0HA20-0AA0

RFQ-ready model route Obsolete and surplus sourcing Export follow-up by model list

Product Overview

Commercial availability is handled through direct RFQ, model verification and export-oriented follow-up rather than public cart checkout.

Submit RFQ Email This Model

Datasheet Preview

Use attached product manuals when available. If the manual is not public yet, request the full file directly through RFQ.

Request Full Manual

Commercial Path

Use This Page To Confirm The Model, Then Move To RFQ

Product pages on DRIVEKNMS are designed to verify model, brand and series first, then move the buyer into one clean quotation path.

Technical Dossier

Product Details And Specifications

Siemens SIMATIC HMI IPC477 Series Technical Notes

SIMATIC HMI IPC477 Full Catalog & Functionalities (SKU List)

The following SKUs represent verified, commonly stocked models within the SIMATIC HMI IPC477 product family, classified by display size and generation.

Panel PC Units - 12" Display

6AV7870-0HA20-0AA0: IPC477C 12" Touch, Celeron M 1.0 GHz, 1 GB RAM, CF storage, Windows XP Embedded
6AV7870-0HA30-0AA0: IPC477C 12" Touch, Celeron M 1.0 GHz, 2 GB RAM, CF storage, Windows 7 Embedded
6AV7872-0BA10-0AA0: IPC477D 12" Touch, Core i5-2510E, 4 GB DDR3, SSD 80 GB, Windows 7 Pro
6AV7872-0BA20-0AA0: IPC477D 12" Touch, Core i5-2510E, 4 GB DDR3, SSD 160 GB, Windows 7 Pro

Panel PC Units - 15" Display

6AV7881-0AA00-0AA0: IPC477C 15" Touch, Celeron M 1.0 GHz, 1 GB RAM, CF storage, Windows XP Embedded
6AV7881-0AA10-0AA0: IPC477C 15" Touch, Celeron M 1.0 GHz, 2 GB RAM, CF storage, Windows 7 Embedded
6AV7882-0BA10-0AA0: IPC477D 15" Touch, Core i5-2510E, 4 GB DDR3, SSD 80 GB, Windows 7 Pro
6AV7882-0BA20-0AA0: IPC477D 15" Touch, Core i5-2510E, 8 GB DDR3, SSD 160 GB, Windows 7 Pro
6AV7882-0DA10-1DA0: IPC477E 15" Touch, Core i5-6300U, 8 GB DDR4, SSD 240 GB, Win 10 IoT Enterprise
6AV7882-0DA20-1DA0: IPC477E 15" Touch, Core i7-6600U, 16 GB DDR4, SSD 240 GB, Win 10 IoT Enterprise

Panel PC Units - 19" Display

6AV7884-0AA10-0AA0: IPC477C 19" Touch, Celeron M 1.0 GHz, 2 GB RAM, CF storage, Windows 7 Embedded
6AV7884-0BA10-0AA0: IPC477D 19" Touch, Core i5-2510E, 4 GB DDR3, SSD 80 GB, Windows 7 Pro
6AV7884-0BA20-0AA0: IPC477D 19" Touch, Core i5-2510E, 8 GB DDR3, SSD 160 GB, Windows 7 Pro
6AV7884-0DA10-1DA0: IPC477E 19" Touch, Core i5-6300U, 8 GB DDR4, SSD 240 GB, Win 10 IoT Enterprise
6AV7884-0DA20-1DA0: IPC477E 19" Touch, Core i7-6600U, 16 GB DDR4, SSD 480 GB, Win 10 IoT Enterprise

Spare and Accessory Modules

6AV7671-1AA00-0AA0: Replacement front panel assembly for IPC477C 15" series
6AV7674-1AA00-0AA0: Replacement touchscreen digitizer for IPC477D 15" series
6ES7648-0DC60-0AA0: BIOS update module, compatible with IPC477D/E platforms

Sourcing Hard-to-Find & Obsolete SIMATIC HMI IPC477 Parts

Q: How is condition confirmed before quotation?
A: Available condition, photos, test records and documentation are checked according to the requested model and sourcing channel before a formal RFQ response.

Quality Control for the SIMATIC HMI IPC477 Range

Q: How are RFQ terms confirmed?
A: Quantity, required condition, documentation needs, destination and sourcing route are confirmed during RFQ review before quotation.
